2.4.5

Inverter Connector (CN7)

This is a 8-pin connector which is compliant with DF13-8S-1.25C for inverter. We
strongly recommend you to use the matching DF13-8S-1.25C connector to avoid
malfunction.
Pin
1
2
3
4
5
6
7
8
2.4.6

Internal USB 2.0 Port (CN8)

This is a 4-pin p=1.25mm wafer connector which is compliant with Molex 53047-0419 for
USB 2.0 port 1.
Pin
1
2
3
4
Board and Pin Assignments
Signal
VBL1 (+12V level)
VBL1 (+12V level)
VBL2 (+5V level)
VBL_ENABLE
GND
GND
GND
VBL Brightness Control
Signal
USB3_PWR23
D2+
D2-
GND
CAPA840/843 Capa Board
1
15
