2.3.5

Auto Power On (JP7)

If JP7 is enabled for AC power input, the system will be automatically power on without

pressing soft power button. If JP7 is disabled for AC power input, it is necessary to

manually press soft power button to power on the system.

Function

Disable auto power on (Default)

Enable auto power on

Board and Pin Assignments

Setting

1-2 close

2-3 close

CAPA840/843 Capa Board
