11 LED/Sounder Status Indications
LED or Sounder
Yellow LED
Bi-Color LED
Sounder
Page 36 of 38
Visual/Audible Condition
Slow blink
Rapid blink
Steady
Very rapid blink
Steady red
Steady green
Slow blinking green
Solid green with red flicker
Red/green alternating
Red blink
Short beep (100 ms) every 2 seconds
Sounder 1/2 second on, 1/2 second off
3 rapid beeps after code is entered or
card is presented
3 slow beeps (250 ms), then a single
beep
1 single beep
EntryProx User Manual, 4045-905, Rev. C.4
Description
Unit is in Program mode
Verify mode is active (checking that the
last
two values in sequence match)
Program error; to clear, press *
Memory (EEPROM) erase is in progress
commands 40/46, 58 loop-back)
Strike is locked
Strike is energized (timed or latched)
Obsolete. No longer supported.
Strike toggle is unlocked and used
lockout active
Awaiting second form of ID during "Card
AND Code" access attempt
User lockout is active and strike locked;
red LED drops out for 100 ms every
second; normal users cannot change the
state of the relay. This also indicates
Invalid Pin Lockout.
Propped door is active
Forced door is active
Code or Card is not found
Self-test is complete
Valid card access
