3. Select USB from the PC connection list. The connection
automatically establishes and no settings are required.
4. Click Advanced. The Advanced Network Setup window appears.
The settings are the same as in step 6 of "Connecting Using a
Modem".
5. Click on the "Connect" icon on the top picture menu to connect. It
will give you a connected message in green. If a connection was not
made, a red error message displays. Check your panel and network
settings if the connection fails.
6. When finished adding, editing and deleting within the job file select
the "Send" icon on the top picture menu to send the job to the panels
or download the configuration to the entry panel.
7. See Opening and Creating a Job File on page 12.

Connecting Through TCP/IP

If your TX3 system is connected to an ethernet TCP/IP network, you can
connect to the system using a TCP/IP connection.
In order for the TX3 system to be connected through TCP/IP, the following
ports must be available:
Touch Screens:
• 8080
Non-Touch Screens:
• 14000
• 14001
• 14002
• 14003
If you are having problems communicating through TCP/IP, make sure that
no other programs are using ports 8080 or 14000 to 14003.
