Mircom TX3 Series Configurator Quick Start page 19

Phone number. Provide the resident's phone number. This selection
is available for ADC lines only.
Relay code. Enter the NSL unit relay code associated with the
resident. This selection is available for NSL lines only.
Ring pattern. Select the resident's phone ring pattern from the list.
Each panel may have its own unique ring. This selection is available
for NSL lines only.
Note: If the telephone entry ADC system is calling to a PBX system,
input the telephone number followed by a comma (for a one
second pause) and then the extension. If you need to dial 9 to
obtain an outside line simply input it before the telephone
number. If you are connected directly to a PBX system with a
loop-start feature and you need to dial 9 to get an outside line,
input 9 followed by two commas and then the number.
5. Select Entry. The Entry window appears.
LT-973
TX3 Configurator Software Guide
19
