- Page 1 NuPRO-842 Full-Size PICMG 1.0 SBC with Intel® Pentium® 4 User’s Manual Manual Rev. 2.00 Revision Date: September 3, 2005 Part No.: 50-13033-102 Advance Technologies; Automate the World.
- Page 2 Copyright 2005 ADLINK TECHNOLOGY INC. All Rights Reserved. The information in this document is subject to change without prior notice in order to improve reliability, design, and function and does not represent a commitment on the part of the manufacturer.
- Page 3 Getting Service from ADLINK Customer Satisfaction is top priority for ADLINK Technology Inc. Please contact us should you require any service or assistance. ADLINK TECHNOLOGY INC. Web Site: http://www.adlinktech.com Sales & Service: Service@adlinktech.com TEL: +886-2-82265877 FAX: +886-2-82265717 Address: 9F, No. 166, Jian Yi Road, Chungho City,...
-
Page 5: Table Of Contents
Table of Contents Table of Contents..............i List of Tables................v List of Figures ................ vi 1 Introduction ................ 1 Unpacking Checklist ............1 Included Items ..............2 Features................3 Functional Blocks and Main Board ........3 Functional Block Diagram ..........4 Main Board Drawing ............ - Page 6 CPU Installation ..............31 Memory Installation............31 Memory Configuration Options ........32 Installing Memory Modules ........... 32 Connecting IDE Devices to the NuPRO-842 ..... 33 BIOS Configuration Overview ..........33 Operating System Installation ..........34 4 Device Driver Installation ..........35 Intel®...
- Page 7 System Requirements ..........35 Hardware Configuration File Installation ....... 35 Driver Installation ............... 36 VGA Driver Installation ..........36 LAN Driver Installation ..........38 5 Watchdog Timer ............... 41 Watchdog Timer Overview ..........41 Using the Watchdog in an Application ......41 6 DB-842DVI Display Interface ...........
- Page 8 Table of Contents...
-
Page 9: List Of Tables
List of Tables Table 2-1: NuPRO-842 Connectors ........16 Table 2-2: VGA Connector ............17 Table 2-3: COM1/COM2 Pin Header ........17 Table 2-4: LAN RJ-45 Connector ..........18 Table 2-5: Parallel Port Connector .......... 18 Table 2-6: Case Open Connector Pin Definition ...... 19 Table 2-7: Fan1/Fan2 Connector Pin Definition ...... - Page 10 Figure 1-1: Functional Block Diagram.......... 4 Figure 1-2: Main Board Drawing ..........5 Figure 2-1: NuPRO-842 Top View ..........15 Figure 3-1: DIMM Sockets ............32 Figure 3-2: Inserting DIMM into Socket........32 Figure 5-1: Watchdog Timer Architecture ........41 Figure 6-1: DB-842DVI Functional Block Diagram....
-
Page 11: Introduction
Introduction The NuPRO-842 is a full-size PICMG 1.0 Pentium 4-based Single Board Computer (SBC) with Intel 845GV chipset. It supports both PCI and ISA buses. The CPU module supports a front side bus (FSB) of 533MHz and a maximum CPU clock of 3.06 GHz featuring 32-bit/33MHz PCI/ISA bus with up to 2GB high performance DDR host SDRAM support. -
Page 12: Included Items
Included Items The NuPRO-842 module (may be equipped with different speed or capacity CPU, RAM, and HDD) This User’s Manual ADLINK CD Y Cable for PS/2 Keyboard & Mouse Printer Port cables with bracket Com cables with bracket USB cables with bracket... -
Page 13: Features
Built-in system monitoring for CPU temperature, FAN speed, system temperature, CPU voltage, and DC voltages. Supports Intel® Pre-boot Execution Environment (PXE). 1.3 Functional Blocks and Main Board The NuPRO-842 functional block and main board diagrams are provided below: Introduction... -
Page 14: Functional Block Diagram
Functional Block Diagram Figure 1-1: Functional Block Diagram Introduction... -
Page 15: Main Board Drawing
Main Board Drawing Figure 1-2: Main Board Drawing Introduction... -
Page 16: Intel® Pentium® 4 Processor
Intel® Pentium® 4 Processor The NuPRO-842 is a full-sized single board computer (SBC) that supports a single mPGA478 Intel® Pentium® 4 processor or a 478-pin Micro Flip-Chip Pin Grid Array (Micro-FCPGA) Mobile Intel® Pentium® 4 Processor – M. The Pentium 4 processor runs at a core speed of up to 3.06GHz and the Mobile Intel®... -
Page 17: Watchdog Timer
MHz RAMDAC of the 845GV GMCH that can directly drive a stan- dard progressive scan monitor up to a resolution of 2048x1536 pixels with 32-bit color at 60 Hz. The NuPRO-842 has a high-speed interface to a digital display use daughter board DB-842DVI. -
Page 18: Ieee-1284 Parallel Port/Printer Interface
5V to the peripherals. IDE Controller and Floppy Interface Controller The NuPRO-842 includes an IDE Controller (in the ICH4) and a Floppy Disk Controller (in the W83627HF). The IDE Controller pro- vides support for internal or external IDE drives. Signals are avail- able at the IDE connectors CN14 and CN13 and are routed to a 40-pin header. -
Page 19: Software
The NuPRO-842 is compatible with all major PC operating sys- tems. ADLINK provides support for many popular operating sys- tems, including additional drivers for ADLINK peripherals. Software device drivers for the NuPRO-842 may be found on the ADLINK CD. 1.4 Specifications Compliant Specifications PICMG 1.0 Rev. -
Page 20: Host Memory
Host Memory Two DDR DIMM sockets Unbuffered, unregistered 184-pin non-ECC DDR SDRAM Supports up to 2GB BIOS Supports 4/8 Mbit Firmware Hub 82802AB(4Mb) or SST49LF004A Boot block, PNP, DMI, Write Protection and field upgrade- able Gigabit Ethernet Two Gigabit Ethernet ports with an Intel 82540EM Ethernet controller Support 1000Base-T, 100Base-TX and 10Base-T (IEEE 802.3, 802.3u, and 802.3ab). -
Page 21: Super I/O And Wdt
Super I/O and WDT Winbond W83627HF Two 16C550 UART compatible RS-232 COM ports, Com2 support RS-232/RS-422/485/485+. PS2 keyboard and mouse supported. W82782D built-in, monitoring CPU temperature, fan speed, system temperature, CPU voltage, and DC voltages. Watchdog timer: Programmable I/O port on addresses 02Eh and 02FH. - Page 22 Introduction...
-
Page 23: Jumpers And Connectors
Jumpers and Connectors This chapter will familiarize users with the NuPRO-842 interfaces and connections available before getting started. It will provide information about the board layout, connector definitions, and jumper setup, including the following information: NuPRO-842 board outline and illustration... -
Page 24: Nupro-842 Board Outline And Illustration
2.1 NuPRO-842 Board Outline and Illustration NuPRO-842 Top View Jumpers and Connectors... -
Page 25: Figure 2-1: Nupro-842 Top View
Figure 2-1: NuPRO-842 Top View CPU P4/P4-M GMCH 82845GV ICH4 FW82801DB Clock Generator PCI to ISA Bridge IT8888 Intel GB Ethernet 82540EM Intel GB Ethernet 82540EM Firmware Hub 842PLD RS422/RS485 PLD CN23 ATX Power CONNECTOR CPU HEATSINK SKT Jumpers and Connectors... -
Page 26: Table 2-1: Nupro-842 Connectors
PRIMARY IDE CN14 SECONDARY IDE CN10 COM2 CN11 COM1 COM2 SETTING JUMPER USB2.0 CNN AC’97 CNN VGA CNN GB CNN GB CNN KB/MS COMBO EXTERNAL KB CNN CN17 EXTERNAL THERMAL CNN IRDA CNN Table 2-1: NuPRO-842 Connectors Jumpers and Connectors... -
Page 27: Vga Connector
VGA Connector Signal Function Analog RED Green Analog GREEN Blue Analog BLUE No Connect Ground Ground Ground Ground Ground Ground No connect DDCDAT DDC Data for CRT HSYNC Horizontal sync for Monitor VSYNC Vertical sync for Monitor DDCCLK DDC CLK for CRT Table 2-2: VGA Connector COM1/COM2 Pin Header Signal... -
Page 28: Lan Rj-45 Connector
LAN RJ-45 Connector Signal Function green LAN2_TDP1 Transmit Data1 + LAN2_TDN1 Transmit Data1 - LAN2_RDP2 Receive Data2 + LAN2_RDP3 Receive Data3 + LAN2_RDN3 Receive Data3 - LAN2_RDN2 Receive Data2 - LAN2_TDP4 Transmit Data4 + yellow LAN2_TDN4 Transmit Data4 - Table 2-4: LAN RJ-45 Connector Parallel Port Connector Signal Name Pin Pin Signal Name... -
Page 29: Case Open Connector
Case Open connector Signal is connected to a limit switch sensor of the chassis to detect if the case is opened or closed. SIGNAL FUNCTION CASEOPEN# Case Open Signal Ground Table 2-6: Case Open Connector Pin Definition CPU Fan1/Fan2 connector Pin # Signal Name Fan power Fan speed... -
Page 30: Floppy Disk Connector
Floppy Disk Connector Pin Function Pin Function Ground Extended Density Ground No Connect Data Rate Ground Index Ground Motor A Select Ground Drive B Select Ground Drive A Select Ground Motor B Select Ground Step Direction Ground Step Pulse Ground Write Data Ground Write Gate... -
Page 31: Primary/Secondary Ide Connector
Primary/Secondary IDE Connector Signal Pin Pin Signal BRSTDRVJ DDP7 DDP8 DDP6 DDP9 DDP5 DDP10 DDP4 10 DDP11 DDP3 12 DDP12 DDP2 14 DDP13 DDP1 16 DDP14 DDP0 18 DDP15 PDDREQ PDIOWJ PDIORJ PIORDY 28 PCSEL PDDACKJ IRQ14 DAP1 DIAG DAP0 DAP2 CS1P 38 CS3PJ... -
Page 32: Front Panel Pin Header
Front Panel Pin Header SIGNAL FUNCTION PIN GROUP Power WDTLED# Watch Dog LED Signal Power LED PLED Power LED Signal KEYLOCK Keyboard lock Key Lock Ground Ground No connect PWRON Power-on signal ATX Power Connector +5VSB Standby Power PME# Power Management Event WDSPK Speaker signal No connect... -
Page 33: Mini Pci Socket
Mini PCI Socket SIGNAL SIGNAL SIGNAL SIGNAL +3.3V FRAME# CLKRUN# TRDY# SERR# STOP# +3.3V PERR# DEVSEL# C/BE[1] AD[14] AD[15] 16 EX_INTC# AD[13] INTB# AD[12] AD[11] +3.3V INTA# AD[10] EX_CLK 22 EX_INTD# AD[9] +3.3VS AD[8] C/BE[0] RESET# AD[7] +3.3V +3.3V +3.3V AD[6] REQ# GNT#... -
Page 34: Usb Connector
SIGNAL SIGNAL SIGNAL SIGNAL AD[23] IDSEL# AC_ID1# AC_RST# AD[21] AD[22] AD[19] AD[20] AD[17] AD[18] C/BE[2] AD[16] 122 MPCIACT# IRDY# +5Analog +3.3VS Table 2-12: Mini PCI Socket Pin Definition USB Connector Pin Signal Name USB- USB+ Table 2-13: USB Connectors Pin Definition AC’97 Connector SIGNAL FUNCTION... -
Page 35: Usb Pin Header
KBDATA Keyboard Data Ground External Keyboard Conncetor Power Power Table 2-17: External KB/MS Connector 2.2 NuPRO-842 Jumper Setting The NuPRO-842 is designed for maximum flexibility with as few jumpers as possible. Most of the configuration options can be Jumpers and Connectors... -
Page 36: Clear Cmos
JP1-3 COM2 RS-485+ Function Selection Table 2-18: Jumpers Definitions Clear CMOS RTC status JP6 NuPRO-842 JP6 Normal Clear CMOS 2-3 Table 2-19: Clear CMOS RTC RAM The CMOS RAM data for real time clock (RTC) contains the date / time and password information. The button cell battery powers the CMOS when the system is powered off. -
Page 37: Fsb Frequency
FSB Frequency FSB Frequency JP8 NuPRO-842 JP8 Auto 400 MHZ 533 MHZ Table 2-20: FSB Frequency The NuPRO-842 will automatically detect Front Side Bus speed, or you can manually force it with jumper JP8. Jumpers and Connectors... -
Page 38: Com2 Function Selection
COM2 Function Selection FUNCTION JP1 JP2 JP3 Jumper Setting RS-232 1-2 4-5 RS-422 2-3 5-6 RS-485 2-3 5-6 Table 2-21: COM2 Function Selection COM2 is configurable to act in accordance with the following stan- dards: RS-232, RS-422, and RS-485. Use jumpers J1, J2, and J3 to adjust as needed. -
Page 39: Com2 Mode Selection
COM2 Mode Selection Mode Jumper Setting RS-422 / RS-485 1-2 4-5 RS-485+ 2-3 5-6 Table 2-22: COM2 Mode Selection The mode of COM2 can be changed using jumper JP4. Jumpers and Connectors... - Page 40 Jumpers and Connectors...
-
Page 41: Getting Started
NuPRO-842. Hardware installation and BIOS overview is discussed. 3.1 CPU Installation The NuPRO-842 CPU module supports a single Intel mPGA478 Pentium 4 processor or 478-pin Micro Flip-Chip Pin Grid Array (Micro-FCPGA) Pentium 4 Processor-M. Users need to install a highly efficient CPU fan/cooler to guarantee the system stability. -
Page 42: Memory Configuration Options
Memory Configuration Options The NuPRO-842 has flexible memory configuration options, including support for 64MB, 128MB, 256MB, 512MB, and 1GB modules. Note that the modules must all be the same type and density and must be installed in pairs. If only one pair of DIMM modules is used, populate DM1 and DM2 first. -
Page 43: Connecting Ide Devices To The Nupro-842
To install an IDE drive, connect the drive to one of the drive con- nectors to a suitable ribbon cable. Plug the board end of the cable into one of the IDE connectors on the NuPRO-842. Make sure pin 1 of the ribbon cable connector is properly aligned with pin 1 of the IDE device connector. -
Page 44: Operating System Installation
Setup parameters are divided into different categories. The avail- able categories are listed in menus. The parameters within the highlighted (current) category are listed in the bottom portion of the Setup screen. Context sensitive help is displayed in the right portion of the screen for each parameter. -
Page 45: Device Driver Installation
Device Driver Installation To install drivers for the NuPRO-842, refer to the installation infor- mation in this chapter. Basic driver installation information for Win- dows 98/ME/NT4.0/2000/XP are outlined in this section. The drivers are located in the following directories of the CD-ROM:... -
Page 46: Driver Installation
1. Check System Requirements. Windows 98/ME/2000/XP must be fully installed and running on the system prior to running this software. 2. Close any running applications. 3. The files are stored in an integrated application setup program. This program is designed for a Windows 98/ME/2000/XP program that allows the INF files to be installed. - Page 47 Installing the Drivers for Windows 98/ME 1. Boot Windows 98/ME. 2. The driver is included in the ADLINK CD. Run win9x131.exe under directory: X:\CHIP- DRV\VGA\I845GV. 3. Click Next> on Welcome screen. And select Typical on Setup Type screen and click Next>. 4.
-
Page 48: Lan Driver Installation
Installing the Drivers for Windows 2000/XP 1. Boot Windows 2000/XP. 2. The driver is included in the ADLINK CD. Run the win2k_xp131.exe under directory: X:\CHIP- DRV\VGA\I845GV. 3. Click Next> on Welcome screen. And select Typical on Setup Type screen and click Next>. 4. - Page 49 1. Boot Windows 2000. 2. The driver is included in the ADLINK CD. Run Setup.exe under directory: X:\CHIP- DRV\LAN\82540EM\pro2kxpm. 3. Click the Install now button on the Installation instruc- tions screen to install the drivers. 4. Click Finish button to finish the installation. Driver Installation on Windows 98/98SE/ME Windows 98 will install the LAN drivers automatically.
- Page 50 Device Driver Installation...
-
Page 51: Watchdog Timer
Sample programs are located at X:\CHIPDRV\WDT\DOS\NP842. 5.1 Watchdog Timer Overview The primary function of the watchdog timer is to monitor the NuPRO-842 operation and to reset the system if the software fails to function as programmed. The major features of the watchdog timer are:... - Page 52 Watchdog Reset An application using the reset feature enables the watchdog reset, sets the terminal count period, and periodically strobes the watchdog to keep it from resetting the system. If a strobe is missed, the watchdog times out and resets the system hard- ware.
-
Page 53: Db-842Dvi Display Interface
DB-842DVI Display Interface The DB-842DVI is a multi-display output daughter board add-on for the NuPRO-842. It supports DVI, LVDS, and TTL displays with resolutions of 800x600, and 1024x768 at 60Hz. Figure 6-1: DB-842DVI Functional Block Diagram DB-842DVI Display Interface... -
Page 54: Db-842Dvi Jumpers And Pinouts
6.1 DB-842DVI Jumpers and Pinouts FUNCTION +5V FPVDD +3.3V FPVDD 2-3 Table 6-1: Flat Panel Voltage Selection (JP1) FUNCTION Enable LVDS 1-2 Disable LVDS 2-3 Table 6-2: LVDS Panel Enable (JP2) DB-842DVI Display Interface... -
Page 55: Table 6-3: Dvi Panel Connector (Cn1)
SIGNAL FUNCTION SIGNAL FUNCTION DVITDC2- TMDS Data 2- DVITDC2+ TMDS Data 2+ Ground No Connect No Connect DDCCLK I2C Clock DDCDATA I2C Data No Connect DVITDC1- TMDS Data 1- 10 DVITDC1+ TMDS Data 1+ Ground No Connect No Connect Power +5V Ground HPDET Hot Plug Detect... -
Page 56: Table 6-5: Ttl Panel Connector
PIN SIGNAL FUNCTION SIGNAL FUNCTION No Connect No Connect Ground Ground FPVDD +5V/3.3V FPVDD +5V/3.3V No Connect Ground Blue Data 0 Blue Data 1 Blue Data 2 Blue Data 3 Blue Data 4 Blue Data 5 Blue Data 6 Blue Data 7 Green Data 0 18 Green Data 1 Green Data 2 20... -
Page 57: Warranty Policy
Warranty Policy Thank you for choosing ADLINK. To understand your rights and enjoy all the after-sales services we offer, please read the follow- ing carefully. 1. Before using ADLINK’s products please read the user man- ual and follow the instructions exactly. When sending in damaged products for repair, please attach an RMA appli- cation form which can be downloaded from: http:// rma.adlinktech.com/policy/. - Page 58 3. Our repair service is not covered by ADLINK's two-year guarantee in the following situations: Damage caused by not following instructions in the user's manual. Damage caused by carelessness on the user's part dur- ing product transportation. Damage caused by fire, earthquakes, floods, lightening, pollution, other acts of God, and/or incorrect usage of voltage transformers.
