Summary of Contents for ADLINK Technology NuPRO-865

  • Page 1 NuPRO-865 Full-Size SBC User’s Manual Recycled Paper...
  • Page 3 © Copyright 2004 ADLINK Technology Inc. All Rights Reserved. Manual Rev. 1.00: July 23, 2004 Part No.: The information in this document is subject to change without prior notice in order to improve reliability, design, and function and does not represent a commitment on the part of the manufacturer.
  • Page 4 Getting Service from ADLINK Customer Satisfaction is top priority for ADLINK Technology Inc. If you need any help or service, please contact us. ADLINK TECHNOLOGY INC. Web Site http://www.adlinktech.com Sales & Service Service@adlinktech.com +886-2-82265877 +886-2-82265717 Address 9F, No. 166, Jian Yi Road, Chungho City, Taipei, 235 Taiwan Please email or FAX your detailed information for prompt, satisfactory, and consistent service.

  • Page 5: Table Of Contents

    Table of Contents Chapter 1 Introduction..............1 Unpacking Checklist................ 2 Features ..................4 System Block Diagram ..............5 Specifications .................. 6 Chapter 2 Installation..............9 System Installation ................9 Board Layout................. 14 Jumper setting................15 Connectors Description ..............16 Optional IP-ALCS20 Audio Card ........... 27 Chapter 3 Award BIOS Setup.............

  • Page 7: Chapter 1 Introduction

    Introduction The NuPRO-865 single board computer is optimized for socket 478 FC-PGA processors, supporting an 800/533MHz Front Side Bus. The memory can accommodate is up to 2GB DDR333/400 SDRAM. This board is based on the ® Intel 865G chipset and is fully designed for harsh industrial environment. The ®...

  • Page 8: Unpacking Checklist

    Unpacking Checklist 1. Take out the NuPRO-865 series unit from the carton box, check if the unit is properly secure in the plastic bag. 2. Check the contents of the carton box: Single Board Computer Installation guide ATA-66/100 HDD ribbon cable Floppy ribbon cable Print &...
  • Page 9 IP-ALCS20 Audio Card Audio 9-pins round cable Note: NuPRO-865 OEM versions with non-standard configurations may vary in function or contents according to request. CAUTION: This board must be protected from static discharge and physical shock. Never remove any of the socketed parts except at a static-free workstation.

  • Page 10: Features

    Features include the CPU temperature, voltage, and RPM of fan. I/O Shield Connector The SBC is equipped with an I/O bracket. Please use the appropriate I/O shield. Figure 1: I/O back panel layout NuPRO-865 Series Overview Function NuPRO-865 Chipset i865G...

  • Page 11: System Block Diagram

    System Block Diagram P4 Socket 478-pins Clock ADDR CTRL DATA DDR333/266 X1 AGP 8X DDR333/266 X1 GMCH (865G) 932 FC-BGA 10/100/1000 Base-TX 82547GI IDE Primary ATA100 IDE Secondary ICH5 460 uBGA USB Port 0/1 PCI BUS USB Port 2/3 SATA Port1 SATA ISA BUS iTE Bridge...

  • Page 12: Specifications

    Specifications • Processor: • Socket 478 processors, for Intel ® ® ™ Pentium 4/ Celeron processor • Up to 3.2GHz • Chipset: • Intel ® 865G + ICH5 AGPset • Front Side Bus: • 400 / 533 / 800 MHz •...
  • Page 13 • Four USB 2.0 ports (pin-header) • BIOS: • Award Plug and Play BIOS • Extended Function: • Hardware monitoring function • IrDA by pin-header • Form Factor: • 13.3” x 4.8” (338 x 122mm) • Weight: • 0.93lb (420g) - NuPRO-865 Introduction • 7...

  • Page 15: Chapter 2 Installation

    Installation System Installation CPU Installation Carefully follow the steps below to install the CPU: Check and confirm that the jumpers are correctly set for the CPU being installed (figure 3). Lift the releasing lever of the Socket 478. Align the pins of the CPU with the pinholes of the Socket 478. Be sure to pay attention to the orientation of the CPU.
  • Page 16 To remove the CPU, reverse the installation steps. Heat Sink & Retention Module Installation It is highly recommended that only NuPRO-865 Heat sink and fan (Figure 4), designed for use in the chassis be used - the use of other heat sinks, including those boxed with CPUs, may damage the NuPRO-865 SBC.
  • Page 17 Heat Sink & Fan Retention Module Installation (For P4 processor only) (For P4 Heat Sink & Fan) Figure 4: Heat Sink Installation Memory Module Installation Figure 5 illustrates the notch marks and what they should look like on the DIMM memory module.
  • Page 18 Do not touch the connector of the DIMM. Dirt residues may cause malfunctions. Hold the DIMM with its notch to the front side of the NuPRO-865 Series and insert it completely into the socket. A DIMM should be inserted into the inner socket first.
  • Page 19 For three-pin jumpers (Figure 7), the jumper setting is 1-2 when the jumper connects pins 1 and 2. The setting is 2-3 when pins 2 and 3 are connected and so on. The pins are numbered “1“ and “3“ on the circuit board for identification purposes.

  • Page 20: Board Layout

    Board Layout CN11 COM1 CN17 VGA CN19 KB/MS CN18 CN14 COM2 KB/MS CN10 FLOPPY IDE2 IDE1 SATA1 CN12 ATX CTL. AC97 SATA2 BATT1 CN16 CN3 CN6 CN15 USB2/3 USB0/1 CN13 DIMM2 DIMM1 SYSTEM FAN CPU FAN 92003 Figure 8: Jumper and Connector Locations 14 •...

  • Page 21: Jumper Setting

    Jumper setting Jumper Location Description: Use the information in the following table to change the jumpers and the DIP switches. Jumpers Functions Clear CMOS Setting Select Watchdog Timer Setting Select A description on setting the jumpers to enable/disable or change functions is illustrated below.

  • Page 22: Connectors Description

    Connectors Description COM1 CN11 CN17 VGA CN19 KB/MS CN18 CN14 COM2 KB/MS CN10 FLOPPY IDE2 IDE1 SATA1 CN12 ATX CTL. SATA2 AC97 BATT1 CN16 CN3 CN6 CN15 USB0/1 USB2/3 CN13 DIMM2 DIMM1 SYSTEM FAN CPU FAN 92003 Figure 9: Connector Location 16 •...
  • Page 23 Table for Connector’s Location Description: Use the information in the following table to change the connector. Connectors Functions System Panel Indicate Connector ATX 12V Power Connector Secondary IDE Connector Floppy Disk Connector IrDA Connector Primary IDE Connector Parallel Port Connector CPU FAN Connector System FAN Connector CN10...
  • Page 24 System Panel Indicate Connector: CN1 Pin # Assignment Pin # Assignment PWR LED SPEAKER SPKR (Default) BUZZ (Default) PWLED KEYLOCK KBLOCK RESET RESET Ground ATX PWR ON Ground Ground HD_LED HDDLED PSON PWR ON 5VSB PWRBT+ PWRBT+ Location: ATX 12V Power Connector: CN2 Pin # Assignment Pin #...
  • Page 25 Secondary IDE Connector (40-pins 2.54mm Pitch Pin-Header with Housing): CN3 Pin # Assignment Pin # Assignment Reset IDE Ground Host Data 7 Host Data 8 Host Data 6 Host Data 9 Host Data 5 Host Data 10 Host Data 4 Host Data 11 Host Data 3 Host Data 12...
  • Page 26 Ground Drive Select 0 Ground Motor Enable 1 Ground Direction Ground Step Ground Write Data Ground Write Gate Ground Track 00 Ground Write Protect Ground Read Data Ground Head Select Ground Diskette Change Location: IrDA Connector: CN5 Pin # Assignment FIRTX IRRX Ground...
  • Page 27 Host Data 4 Host Data 11 Host Data 3 Host Data 12 Host Data 2 Host Data 13 Host Data 1 Host Data 14 Host Data 0 Host Data 15 Ground DRQ 0 Ground Host IOW Ground Host IOR Ground IOCHRDY Host ALE DACK 0...
  • Page 28 Location: CPU FAN Connector: CN8 Pin # Assignment Ground +12V Fan Status Signal Location: System FAN Connector: CN9 Pin # Assignment Ground +12V Fan Status Signal Location: COM2 RS-232 Serial Port Connector (10-pins 2.54mm Pitch Pin-Header with Housing): CN10 Pin # Assignment Pin # Assignment...
  • Page 29 Location: COM1 RS-232 Serial Port Connector (D-Sub 9-pins Male): CN11 Pin # Assignment Pin # Assignment DCD (Data Carrier Detect) DSR (Data Set Ready) RXD (Receive Data) RTS (Request to Send) TXD (Transmit Data) CTS (Clear to Send) DTR (Data Terminal Ready) RI (Ring Indicator) Ground Location:...
  • Page 30 Location: Gigabit LAN (82547GI) RJ-45 Connector (RJ-45 Phone-jacket): CN14 Pin # Assignment Pin # Assignment Transmit output (+) Transmit output (-) Receive input (-) Receive input (+) Location: USB2/3 Port Connector (9-pins Pin-Header): CN15 Pin # Assignment Pin # Assignment USB2 N USB3 N USB2 P...
  • Page 31 AC_BCLK Ground AC_RST# AC_SDIN0 Location: CRT VGA Port Connector (D-SUB 15-pins Female): CN17 Pin # Assignment Pin # Assignment Red Color Signal Green Color Signal Blue Color Signal Ground Ground Ground Ground Ground VGA DDA H-Sync. V-Sync. SPCLK Location: External Keyboard & Mouse Connector (5-pins): CN18 Pin # Assignment Keyboard Clock...
  • Page 32 PS/2 Keyboard & Mouse Connector (Mini Din 6 Pins): CN19 Pin # Assignment Pin # Assignment Keyboard Data Mouse Data Ground Keyboard Clock Mouse Clock Location: S-ATA1 Connector (9-pins): SATA1 Pin # Assignment Ground SATA1_TXP SATA1_TXN Ground SATA1_RXN SATA1_RXP Ground Ground Ground Location:...

  • Page 33: Optional Ip-Alcs20 Audio Card

    Location: 2.5 Optional IP-ALCS20 Audio Card Board Location: Thank you for choosing the IP-ALCS20 Audio Card, instructions on connecting the connector and phone jack for audio functions are described below. IP-ALCS20 Rev 1.0 CD_IN Figure 10: IP-ALCS20 Audio Card Award BIOS Setup • 27...
  • Page 34 1. Check the contents of the packing: IP-ALCS20 Audio Card Audio 9-pins round cable 2. Table for Audio Card Description of Connector: Connectors Functions CD_IN Connector Audio Line_In, Line_Out, MIC Phone Jack Audio Signal Connector 3. Description of Connector: CD_IN Connector: JP1 Pin # Assignment Left...

  • Page 35: Chapter 3 Award Bios Setup

    Award BIOS Setup BIOS Instructions Award’s ROM BIOS provides a built-in Setup program, which allows the user to modify the basic system configuration and hardware parameters. The modified data will be stored in a battery-backed CMOS, so that data will be retained even when the power is turned off.
  • Page 36 Esc: Quit ↑ ↓ →←: Select Item F10: Save & Exit Setup Time, Date, Hard Disk Type…. Note: A brief description of each highlighted selection appears at the bottom of the screen. Setup Items: The main menu includes the following main setup categories. Recall that some systems may not include all entries.

  • Page 37: Standard Cmos Features

    Load Fail-Safe Defaults: Use this menu to load the BIOS default values for the minimal/stable performance for the system to operate. Please refer to section 3.12 for further information. Load Optimized Defaults: Use this menu to load the BIOS default values that are factory settings for optimal performance system operations.
  • Page 38 Standard CMOS Features Date (mm:dd:yy): Item Help Mon, Aug 4 Time (hh:mm:ss): 2003 __________________________ 16:19:20 IDE Channel 0 Master Menu Level IDE Channel 0 Slave 13579 MB IDE Channel 1 Master Change the day, month, year and None IDE Channel 1 Slave century None IDE Channel 2 Master...
  • Page 39 IDE Channel 3 Master: Options are in its sub menu (described in 3.4) Press <Enter> to enter the sub menu of detailed options. Drive A: Options None 360K, 5.25 in/1.2M, 5.25 in/720K, 3.5 in/ 1.44M, 3.5 in/2.88M, 3.5 in Select the type of floppy disk drive installed in the system Video: Options EGA/VGA/CGA 40/CGA 80/MONO Select the default video device.

  • Page 40: Ide Adaptors

    IDE Adaptors The IDE adapters control the hard disk drive. Use a separate sub menu to configure each hard disk drive. Phoenix - AwardBIOS CMOS Setup Utility IDE Channel 0 Master IDE HDD Auto-Detection Press Enter Item Help __________________________ IDE Channel 0 Master Auto Access Mode Auto...
  • Page 41 Cylinder: Options Min = 0, Max = 65535 Set the number of cylinders for this hard disk. Head: Options Min = 0, Max = 255 Set the number of read/write heads Precomp: Options Min = 0, Max = 65535 **** Warning: Setting a value of 65535 means no hard disk Landing zone: Options Min = 0, Max = 65535 **** Sector: Options Min = 0, Max = 255...

  • Page 42: Advanced Bios Features

    Advanced BIOS Features This section allows the user to configure their system for basic operation. The user can also select the system’s default speed, boot-up sequence, keyboard operation, shadowing, and security. Phoenix - AwardBIOS CMOS Setup Utility Advanced BIOS Features CPU Feature Press Enter Item Help...
  • Page 43 CPU Feature: Phoenix - AwardBIOS CMOS Setup Utility CPU Feature Delay Prior to Thermal 16Min Item Help Thermal Management Thermal Monitor 1 ___________________________ Menu Level ↑↓→←Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values F6: Fail-safe defaults F7: Optimized Defaults Delay Prior To Thermal:...
  • Page 44 Hyper-Threading Technology: Allows the user to choose the CPU Hyper-Threading Technology. Enabled - Enable CPU Hyper-Threading Disabled - Disabled CPU Hyper-Threading Quick Power On Self Test: This category speeds up Power On Self Test (POST) after powering up the computer. If it is set to Enable, BIOS will shorten or skip some check items during POST.
  • Page 45 Typematic Rate (Chars/Sec): Sets the number of times a second to repeat a keystroke when holding the key down. Options: 6, 8, 10, 12, 15, 20, 24, and 30. Typematic Delay (Msec): Sets the delay time after the key is held down before it begins to repeat the keystroke. Options: 250, 500, 750, and 1000.

  • Page 46: Advanced Chipset Features

    Agent Connect Via: Select Null lets agent connect directly. Option: NULL. Agent Wait Time (min): Select the time to allow agent connects when timeout. Options: 1, 2, 4, 8. Agent After Boot: This item allows the user to keep agent running after OS boot. Options: Enabled, Disabled.
  • Page 47 Phoenix - AwardBIOS CMOS Setup Utility Advanced Chipset Features DRAM Timing Selectable By SPD Item Help X CAS Latency Time __________________________ X Active to Precharge Delay X DRAM RAS# to CAS# Delay X DRAM RAS# Precharge Menu Level Memory Frequency For Auto System BIOS Cacheable Enabled...
  • Page 48 DRAM refresh, the refresh may be incomplete and the DRAM may fail to retain data. Fast gives faster performance; and Slow gives a more stable performance. This field applies only when synchronous DRAM is installed in the system. Options: 2, 3, 4. Memory Frequency For: Selects the operating frequency for the main system memory.

  • Page 49: Integrated Peripherals

    On-Chip Frame Buffer Size: This can be used to select the frame buffer size. Options: 1MB, 8MB,16M Integrated Peripherals Phoenix - AwardBIOS CMOS Setup Utility Integrated Peripherals OnChip IDE Device Press Enter Item Help Onboard Device Press Enter __________________________ SuperI/O Device Press Enter Onboard Lan Boot ROM Enabled...
  • Page 50 IDE HDD Block Mode: Block mode is also called block transfer, multiple commands, or multiple sector read/write. If the IDE hard drive used supports block mode (most new drives do), select Enabled for automatic detection of the optimal number of block read/writes per sector the drive can support.
  • Page 51 Onboard Device: Onboard Device USB Controller Enabled Item Help USB 2.0 Controller Enabled __________________________ USB Keyboard Support Disabled USB Mouse Support Disabled AC97 Audio Auto Menu Level CSA LAN(Giga-LAN) Enabled ↑↓→←Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values F6: Fail-safe defaults F7: Optimized Defaults...
  • Page 52 Onboard I/O Chip Setup: Onboard I/O Chip Setup Onboard FDC Controller Enabled Item Help Onboard Serial Port 1 3F8/IRQ4 __________________________ Onboard Serial Port 2 2F8/IRQ3 UART Mode Select Normal X RxD, TxD Active Hi, Lo Menu Level X IR Transmission Delay Enabled X UR2 Duplex Mode Half...
  • Page 53 UR2 Duplex Mode: This item allows the user to select the IR half/full duplex function. Options: Half, Full. Use IR Pins: This item allows the user to select IR transmission routes Options: IR-Rx2Tx2, RxD2, and TxD2. Onboard Parallel Port: This allows the user to determine which onboard parallel port controller connects with which I/O address Options: 3BC/IRQ7, 378/IRQ7, 278/IRQ5, and Disabled.

  • Page 54: Power Management Setup

    Power Management Setup The Power Management Setup allows the user to configure the system to most effectively save energy while operating in a manner consistent with the individual’s computer operating style. Phoenix - AwardBIOS CMOS Setup Utility Power Management Setup ACPI Function Enabled Item Help...
  • Page 55 Min. Power Saving: Minimum power management. Doze Mode = 1 hr. Standby Mode = 1 hr., Suspend Mode = 1 hr., and HDD Power Down = 15 min. Max. Power Saving: Maximum power management – only available on SL CPU’s. Doze Mode = 1 min., Standby Mode = 1 min., Suspend Mode = 1 min., and HDD Power Down = 1 min.
  • Page 56 Suspend Mode: When “Enabled” and after the set time of system inactivity, all devices except the CPU will be shut off. Options: Disabled, 1, 2, 4, 8, 12, 20, 30, 40 Min, and 1Hour. HDD Power Down: When “Enabled” and after the set time of system inactivity, the hard disk drive will be powered down while all other devices remain active.

  • Page 57: Plug And Play / Pci Configurations

    Plug and Play / PCI Configurations This section describes the configuration of the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings.

  • Page 58: Pc Health Status

    3.10 PC Health Status Phoenix - AwardBIOS CMOS Setup Utility PC Health Status CPU Warning Temperature Disabled Item Help Current System Temp. 33°C / 91°F ___________________________ Current CPU1 Temperature 38°C / 100°F Current CPUFan1 Speed 3835 RPM Current System Fan Speed 4725RPM Menu Level VDIMM (V)

  • Page 59: Frequency/Voltage Control

    Vcore (V) Displays the voltage level of CPU (Vcore). VCC3.3V/+5V/+12V/-12V/-5V/5VSB(V): Displays the voltage of 3.3V/+5V/+12V/-12V/-5V. VBAT (V) Displays the voltage level of the battery. Shutdown Temperature: This allows the user to set up the CPU shutdown Temperature. This item is only effective ®...

  • Page 60: Load Fail-Safe Defaults

    3.12 Load Fail-Safe Defaults When pressing <Enter> on this item a confirmation dialog box would appear with a message similar to: Load Fail-Safe Defaults (Y/N)? N Pressing “Y” loads the BIOS default values for the most stable, minimal-performance system operations. 3.13 Load Optimized Defaults When pressing <Enter>...

  • Page 61: Exit Selecting

    password typed will now clear any previously entered password from CMOS memory. The user will then be prompted to confirm the password. Type the password again and press <Enter>. To abort, press <Esc> and do not enter a password. To disable a password, just press <Enter> when prompted to enter the password. A message will appear to confirm that the password will be disabled.
  • Page 62 Exit Without Saving Pressing <Enter> on this item asks for confirmation: Quit without saving (Y/N)? Y This allows the user to exit Setup without any changes in CMOS. The previous selections remain in effect. This exits the Setup utility and restarts the computer. 56 •...

  • Page 63: Warranty Policy

    Warranty Policy Thank you for choosing ADLINK. To understand your rights and enjoy all the after-sales services we offer, please read the following carefully: Before using ADLINK’s products please read the user manual and follow the instructions exactly. When sending in damaged products for repair, please attach an RMA application form.
