  • Page 1 NuPRO-761 Full-Size Single Board Computer User’s Guide 6007002N761A0 PDF created with FinePrint pdfFactory Pro trial version www.pdffactory.com...
  • Page 2 Trademarks ® NuPRO is a registered trademark of ADLINK Technology Inc. Other product names mentioned herein are used for identification purposes only and may be trademarks and/or registered trademarks of their respective companies. PDF created with FinePrint pdfFactory Pro trial version...
  • Page 3 Getting service from ADLINK • Customer Satisfaction is the most important priority for ADLINK Tech Inc. If you need any help or service, please contact us. ADLINK Technology Inc. Web Site http://www.adlinktech.com Sales & Service Service@adlinktech.com NuDAQ + USBDAQ nudaq@adlinktech.com...

  • Page 4: Table Of Contents

    ONTENTS ECTION NTRODUCTION Unpacking NuPRO-761 Series Description Features 1.3.1 Hardware Monitoring 1.3.2 I/O Shield Connector 1.3.3 NuPRO-761 Series Overview 1.3.4 System Block Diagram Specifications ECTION NSTALLATIONS System Installation 2.1.1 CPU Installation 2.1.2 Heat Sink Installation 2.1.3 Memory Module Installation 2.1.4 Setting Jumper and DIP Switches...
  • Page 5 ONTENTS BIOS S ECTION WARD ETUP BIOS Instructions Main Menu Standard CMOS Features IDE Adapters Advanced BIOS Features Advanced Chipset Features Integrated Peripherals Power Management Setup PnP/PCI Configurations 3.10 PC Health Status 3.11 Frequency/Voltage Control 3.12 Load Fail-Safe Default 3.13 Load Optimized Defaults 3.14 Supervisor/User Password Setting 3.15 Exit Selecting Warranty Policy...
  • Page 6 PDF created with FinePrint pdfFactory Pro trial version www.pdffactory.com...

  • Page 7: Section 1 Introduction

    ECTION NTRODUCTION Unpacking NuPRO-761 Series 1. Take out the NuPRO-761 series unit from the carton box, check if the unit is properly secure in the plastic bag. 2. Check the contents of the carton box: ¿ Single Board Computer ¿ Installation Guide ¿...
  • Page 8 Introduction ¿ K/B-M/S extend to BP cable ¿ ATX power control cable (6-pins to 5-pins) (4-pins to 5-pins) ¿ COM2 ribbon cable ¿ Printer ribbon cable (14-pins to Dual 9-pins D-Sub) (26-pins to 25-pins D-Sub) 3. Optional cable: ¿ USB2.0 cable ¿...

  • Page 9: Description

    Introduction Description The NuPRO-761 Series all-in-one single board computer is optimized for socket 370 FC-PGA processor, supporting 100MHz and 133 MHz Front Side Bus, the memory can accommodate is up to 2 GB DDR SDRAM. This board ® is based on the VIA 8623 (CLE266) chipset and is fully designed for harsh industrial environment.

  • Page 10: Hardware Monitoring

    The SBC is equipped with an I/O bracket. Please use the appropriate I/O shield (figure 1). NuPRO-761 Series COM1 Figure 1: I/O bracket layout 1.3.3 NuPRO-761 Series Overview Function / Model NuPRO-761 ® ¿ Chipset VT8623 (CLE266) ¿ LCD Function ž...

  • Page 11: System Block Diagram

    Introduction 1.3.4 System Block Diagram P!!! Socket 370-pins Clock ADDR CTRL DATA 100/133MHZ FSB LVDS DVI / CRT DDR SDRAM Device VT8623 100/133 X2 IDE Primary ATA100 AC97 Realtek Audio RTL8100BL IDE Secondary Codec 10/100 T-Base VT8235 USB Port 1/2 USB2.0 USB Port 3/4 PCI BUS...

  • Page 12: Specifications

    Introduction Specifications NuPRO-761 Series: ¿ Processor: ® ™ ® ® ™ - Socket 370 Processor, for Intel Celeron / Pentium !!! / VIA Processor ¿ Chipset: ® - VIA VT8623 AGPset ¿ Front Side Bus: - 66/100/133 MHz ¿ DRAM Module:...
  • Page 13 ¿ Extended Function: ® - Hardware Monitoring function by Winbond ASIC - IrDA by pin-header ¿ Form Factor: - 13.3” x 4.8” (338 x 122mm) ¿ Weight: - 0.84lb (380g) --- NuPRO-761 PDF created with FinePrint pdfFactory Pro trial version www.pdffactory.com...

  • Page 14: Section 2 Installations

    ECTION NSTALLATIONS System Installation 2.1.1 CPU Installation Carefully follow the steps below in order to install the CPU: 1. Check and confirm that the jumpers are correctly set for the CPU you are going to install (figure 3). 2. Lift the releasing lever of the Socket 370. 3.

  • Page 15: Heat Sink Installation

    2.1.2 Heat Sink Installation It is highly recommended that only NuPRO-761 Heat Sink + Fan (Figure 4), designed for use in the chassis be used -- the use of other heat sinks, including those boxed with CPUs, may result in damage to the NuPRO-761 SBC.

  • Page 16: Memory Module Installation

    2. Do not touch the connector of the DIMM. Dirt residue may cause a malfunction. 3. Hold the DIMM with its notch to the front side of the NuPRO-761 Series and insert it completely into the socket. A DIMM should be inserted into the inner socket first.

  • Page 17: Setting Jumper And Dip Switches

    2.1.4 Setting Jumpers and DIP Switches There are jumpers and DIP-switches on the system board of the NuPRO-761 Series. You can set the jumpers to make the necessary operations. Figure 7: Jumper Connector For any three-pins jumpers (figure 7), the jumper setting is 1-2 when the jumper connects pin 1 and 2.

  • Page 18: Board Layout

    Board Layout Jumper & Connector Location CN11 CN19 CN21 CN15 CN16 CN20 JP 2 CN17 CN13 CN25 JP 3 BATT1 CN12 CN 9 DIMM1 DIMM2 C N18 NuPRO-761 Rev1.0 CN22 CN10 CN14 PDF created with FinePrint pdfFactory Pro trial version www.pdffactory.com...

  • Page 19: Jumper Setting

    Installations Jumper Setting Table for Jumper Location Description: Use the information in the following table to change the jumpers. Jumpers Functions LCD Power Setting Select COM Port Setting Select Clear CMOS Setting Select PDF created with FinePrint pdfFactory Pro trial version www.pdffactory.com...
  • Page 20 Installations In order to set up the correct configuration, here is the description about how to set the jumpers to enable/disable or change functions. All jumpers’ location please refer to jumper location diagram. ®LCD Power Setting Select: JP1 Function 3.3V (Default) —...
  • Page 21 Installations ® Clear CMOS Setting Select: JP3 Function Normal (Default) Clear CMOS — Location: PDF created with FinePrint pdfFactory Pro trial version www.pdffactory.com...

  • Page 22: Connector's Description

    Installations Connector’s Description Connector Location CN11 CN19 CN21 CN15 CN16 CN20 JP 2 CN17 CN13 CN25 JP 3 BATT1 CN12 CN 9 DIMM1 DIMM2 C N18 NuPRO-761 Rev1.0 CN22 CN10 CN14 PDF created with FinePrint pdfFactory Pro trial version www.pdffactory.com...
  • Page 23 Installations Table for Connector’s Location Description: Use the information in the following table to change the connector. Connectors Functions LCD Inverter Connector TFT Panel Connector Primary IDE Connector Floppy Disk Connector Secondary IDE Connector Parallel Port Connector COM2 RS-232/422/485 Serial Port Connector LVDS Panel Connector USB0 / USB1 Port Connector CN10...
  • Page 24 Installations ® LCD Inverter Connector (5-pins): CN1 Pin # Assignment Ground LCD BKL Ground +12V — Figure: PDF created with FinePrint pdfFactory Pro trial version www.pdffactory.com...
  • Page 25 Installations ® TFT Panel Connector (40-pins Male): CN2 Pin # Assignment Pin # Assignment Ground Ground Ground Ground Ground Ground — Figure: PDF created with FinePrint pdfFactory Pro trial version www.pdffactory.com...
  • Page 26 Installations ® Primary IDE Connector (40-pins 2.54mm Pitch Pin-Header with Housing): CN3 Pin # Assignment Pin # Assignment Reset IDE Ground Host Data 7 Host Data 8 Host Data 6 Host Data 9 Host Data 5 Host Data 10 Host Data 4 Host Data 11 Host Data 3 Host Data 12...
  • Page 27 Installations ® Floppy Disk Connector (34-pins 2.54mm Pitch Pin-Header with Housing): CN4 Pin # Assignment Pin # Assignment Ground Drive Density Selection Ground Ground Ground Index Ground Motor Enable 0 Ground Drive Select 1 Ground Drive Select 0 Ground Motor Enable 1 Ground Direction Ground...
  • Page 28 Installations ® Secondary IDE Connector (40-pins 2.54mm Pitch Pin-Header with Housing): CN5 Pin # Assignment Pin # Assignment Reset IDE Ground Host Data 7 Host Data 8 Host Data 6 Host Data 9 Host Data 5 Host Data 10 Host Data 4 Host Data 11 Host Data 3 Host Data 12...
  • Page 29 Installations ® Parallel Port Connector (26-pins 2.54mm Pitch Pin-Header with Housing): CN6 Pin # Assignment Pin # Assignment Line Printer Strobe Auto Feed PD 0, Parallel Data 0 Error PD 1, Parallel Data 1 Initialize PD 2, Parallel Data 2 Select PD 3, Parallel Data 3 Ground...
  • Page 30 Installations Note: How to connect RS485 device with COM port ribbon cable? Our Industrial Board encloses a COM port ribbon cable for internal connection. RS422/485 device must connect to downside D-Sub with 5-pins cable and signal indication as below. 1: TXD- 2: TXD+ 3: RXD- 4: RXD+...
  • Page 31 Installations ® USB0 / USB1 Port Connector (9-pins Pin-Header): CN9 Pin # Assignment Pin # Assignment USB0 N USB1 N USB0 P USB1 P Ground Ground — Figure: ® System Fan Power Connector: CN10 Pin # Assignment Ground +12V Fan Status Signal —...
  • Page 32 Installations ® USB2 / USB3 Port Connector (9-pins Pin-Header): CN12 Pin # Assignment Pin # Assignment USB0 N USB1 N USB0 P USB1 P Ground Ground — Figure: ® IrDA Connector: CN13 Pin # Assignment FIRTX IRRX Ground IRTX — Figure: PDF created with FinePrint pdfFactory Pro trial version www.pdffactory.com...
  • Page 33 Installations ® System Panel Indicate Connector: CN14 Pin # Assignment Pin # Assignment SPEAKER PWR LED PWLED+ PWLED- KEYLOCK SPKR HDD LED KBLOCK HDLED+ Ground HDLED- RESET PWR ON RESET+ PWRBT+ RESET- PWRBT- — Figure: ® CD_IN Connector (4-pins Male): CN15 Pin # Assignment CD_IN_Left...
  • Page 34 Installations ® LAN1 Connector (RJ-45 Phone-jacket): CN16 Pin # Assignment Pin # Assignment Transmit output (+) Transmit output (-) Receive input (-) Receive input (+) — Figure: ® Audio Connector (9-pins): CN17 Pin # Assignment Pin # Assignment MIC IN AU_GND MIC BIAS AU VCC5...
  • Page 35 Installations ® CRT VGA Port Connector (D-SUB 15-pins Female): CN19 Pin # Assignment Pin # Assignment Red Color Signal Green Color Signal Blue Color Signal Ground Ground Ground Ground Ground VGA DDA H-Sync. V-Sync. SPCLK — Figure: ® External Keyboard Connector (6-pins): CN20 Pin # Assignment Mouse Clock...
  • Page 36 Installations ® PS/2 Keyboard/Mouse Connector (Mini Din 6 Pins): CN21 Pin # Assignment Pin # Assignment Keyboard Data Mouse Data Ground Keyboard Clock Mouse Clock — Figure: ® CPU Fan Power Connector: CN22 Pin # Assignment Ground +12V Fan Status Signal —...

  • Page 37: Section 3 Award Bios Setup

    ECTION BIOS S WARD ETUP 3.1 BIOS Instructions Award’s ROM BIOS provides a built-in Setup program, which allows user to modify the basic system configuration and hardware parameters. The modified data will be stored in a battery-backed CMOS, so that data will be retained even when the power is turned off.

  • Page 38: Main Menu

    Award BIOS Setup 3.2 Main Menu Once you enter the AwardBIOS™ CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions and two exit choices. Use the arrow keys to select among the items and press <Enter>...
  • Page 39 Award BIOS Setup Power Management Setup: Use this menu to specify your settings for power management. See section 5 for the details. PnP / PCI Configuration: This entry appears if your system supports PnP / PCI. See section 6 for the details.

  • Page 40: Standard Cmos Features

    Award BIOS Setup 3.3 Standard CMOS Features The items in Standard CMOS Setup Menu are divided into 10 categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item.
  • Page 41 Award BIOS Setup IDE Secondary Master: Options are in its sub menu (described in 3.4) Press <Enter> to enter the sub menu of detailed options. IDE Secondary Master: Options are in its sub menu (described in 3.4) Press <Enter> to enter the sub menu of detailed options. Drive A/ Drive B: Options None 360K, 5.25 in/1.2M, 5.25 in/720K, 3.5 in/ 1.44M, 3.5 in/2.88M, 3.5 in Select the type of floppy disk drive installed in your system.

  • Page 42: Ide Adapters

    Award BIOS Setup 3.4 IDE Adapters The IDE adapters control the hard disk drive. Use a separate sub menu to configure each hard disk drive. Phoenix - AwardBIOS CMOS Setup Utility IDE Primary Master IDE HDD Auto-Detection Press Enter Item Help ____________________________ ØØ...
  • Page 43 Award BIOS Setup The following options are selectable only if the ‘IDE Primary Master’ item is set to ‘Manual’ Cylinder: Options Min = 0, Max = 65535 Set the number of cylinders for this hard disk. Head: Options Min = 0, Max = 255 Set the number of read/write heads Precomp: Options Min = 0, Max = 65535 **** Warning: Setting a value of 65535 means no hard disk...

  • Page 44: Advanced Bios Features

    Award BIOS Setup 3.5 Advanced BIOS Features This section allows you to configure your system for basic operation. You have the opportunity to select the system’s default speed, boot-up sequence, keyboard operation, shadowing and security. Phoenix - AwardBIOS CMOS Setup Utility Advanced BIOS Features CPU Internal Cache Enabled...
  • Page 45 Award BIOS Setup Processor Number Feature: ® This item will show Pentium III or later CPU new feature. The default is “Enabled”. Enabled---Processor serial number readable. Disabled---Processor serial number disabled Quick Power On Self Test: This category speeds up Power On Self Test (POST) after you power up the computer.
  • Page 46 Award BIOS Setup Swap Floppy Drive: If the system has two floppy drives, you can swap the logical drive name assignments. The choice: Enabled, Disabled. Boot Up Floppy Seek: Seeks disk drives during boot up. Disabling speeds boot up. The choice: Enabled, Disabled. Boot Up NumLock Status: Select power on state for NumLock.
  • Page 47 Award BIOS Setup Security Option: Select whether the password is required every time the system boots or only when you enter setup. System---The system will not boot and access to Setup will be denied if the correct password is not entered at the prompt. Setup---The system will boot, but access to Setup will be denied if the correct password is not entered at the prompt.

  • Page 48: Advanced Chipset Features

    Award BIOS Setup 3.6 Advanced Chipset Features This section allows you to configure the system based on the specific features of the installed chipset. This chipset manages bus speeds and access to system memory resources, such as DRAM and the external cache.
  • Page 49 Award BIOS Setup DRAM Clock/Drive Control: Phoenix - AwardBIOS CMOS Setup Utility DRAM Clock/Drive Control Current FSB Frequency 133 MHz Item Help Current DRAM Frequency 133 MHz ____________________________ DRAM Clock By SPD Ø DRAM Timing By SPD Menu Level DRAM CAS Latency Bank Interleave Disabled Precharge to Active (Trp)
  • Page 50 Award BIOS Setup Precharge to Active (Trp): This item refers to the number of cycles required to return data to its original location to close the bank or the number of cycles required to page memory before the next band activate command can be issued. The choice: 2T, 3T.
  • Page 51 Award BIOS Setup AGP Driving Value: This function allows you to manually select the AGP driving value. Options Min = 0000, Max = 00FF AGP Fast Write: Select Enabled to allow Fast Write Protocol for 4X AGP to function. The choice: Enabled, Disabled. AGP Master 1 WS Write / Read: Writes/Read to the AGP (Accelerated Graphics Port) are executed with one wait states.
  • Page 52 Award BIOS Setup Video RAM Cacheable: This option allows the CPU to cache read/writes of the video RAM. The choice: Enabled, Disabled. Disk On Chip Address: Select this item allows the Disk On Chip address at D0000H-D3FFFH. The choice: D0000H-D3FFFH, D4000H-D7FFFH, D8000H-DBFFFH and DC000H-DFFFFH.

  • Page 53: Integrated Peripherals

    Award BIOS Setup 3.7 Integrated Peripherals Phoenix - AwardBIOS CMOS Setup Utility Integrated Peripherals Ø VIA OnChip IDE Device Press Enter Item Help Ø VIA On-Chip PCI Device Press Enter ____________________________ Ø Super IO Device Press Enter Ø Init Display First PCI Slot Menu Level ↑↓→←Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help...
  • Page 54 Award BIOS Setup IDE HDD Block Mode: Block mode is also called block transfer, multiple commands, or multiple sector read/write. If your IDE hard drive supports block mode (most new drives do), select Enabled for automatic detection of the optimal number of block read/writes per sector the drive can support.
  • Page 55 Award BIOS Setup Realtek ALC650: This item allows you to auto or disable to support AC97 Audio. The choice: Auto, Disabled. Onchip USB Controller: Select “Enabled” if your system contains a USB controller and you have USB peripherals. The choice: All Disabled, All Enabled, 1&2 USB Port, 1&3 USB Port and 1 USB Port Onchip EHCI Controller: This item allows you to enabled or disable EHCI Controller.
  • Page 56 Award BIOS Setup Onboard FDC Controller: Select “Enabled” if your system has a floppy disk controller (FDC) installed on the system board and you wish to use it. If you install and-in FDC or the system has no floppy drive, select Disabled in this field. The choice: Enabled, Disabled.
  • Page 57 Award BIOS Setup Parallel Port Mode: Select an operating mode for the onboard parallel (printer) port. Select Normal, Compatible, or SPP unless you are certain your hardware and software both support one of the other available modes. The choice: SPP, EPP, ECP and ECP+EPP. EPP Mode Select: Select EPP port type 1.7 or 1.9.

  • Page 58: Power Management Setup

    Award BIOS Setup 3.8 Power Management Setup The Power Management Setup allows you to configure you system to most effectively save energy while operating in a manner consistent with your own style of computer use. Phoenix - AwardBIOS CMOS Setup Utility Power Management Setup ACPI Function Enabled...
  • Page 59 Award BIOS Setup HDD Power Down: When “Enabled” and after the set time of system inactivity, the hard disk drive will be powered down while all other devices remain active. The choice: Disabled, 1~15Min. Suspend Mode: When “Enabled” and after the set time of system inactivity. All devices except the CPU will be shut off.
  • Page 60 Award BIOS Setup Ac Loss Auto Restart The system will stay of power on after a power interrupts. The choice: Auto, Off. IRQ/Event Activity Detect: Phoenix - AwardBIOS CMOS Setup Utility IRQ/Event Activity Detect Item Help LPT & COM None ____________________________ HDD &...
  • Page 61 Award BIOS Setup PowerOn By PCI Card: An input signal from PME on the PCI card awakens the system from a soft off state. The choice: Enabled, Disabled. Wake Up On LAN/Ring: When set to Enabled, any event occurring to the LAN/Modem Ring will awaken the system, which has been powered down.
  • Page 62 Award BIOS Setup IRQs Activity Monitoring: Phoenix - AwardBIOS CMOS Setup Utility IRQs Activity Monitoring Primary INTR Item Help IRQ3 (COM 2) Enabled ____________________________ IRQ4 (COM 1) Enabled Ø IRQ5 (LPT 2) Enabled Menu Level IRQ6 (Floppy Disk) Enabled IRQ7 (LPT 1) Enabled IRQ8...

  • Page 63: Pnp/Pci Configurations

    Award BIOS Setup 3.9 PnP/PCI Configurations This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system, which allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components.
  • Page 64 Award BIOS Setup Resource Controlled By: The Award Plug and Play BIOS has the capacity to automatically configure all of the boot and Plug and Play compatible devices. However, this capability means absolutely nothing unless you are using a Plug and Play ®...

  • Page 65: Pc Health Status

    Award BIOS Setup 3.10 PC Health Status Phoenix - AwardBIOS CMOS Setup Utility PC Health Status Current System Temp. 34°C/93°F Item Help Current CPU Temp. 40°C/104°F ____________________________ Current System Fan Speed 5010RPM Ø Current CPU Fan Speed 5213RPM Menu Level Vcore (V) 1.72V +3.3V (V)
  • Page 66 Award BIOS Setup Vcore (V) Show you the voltage level of CPU (Vcore). +3.3V/+5V/+12V/-12V/-5V/5VSB(V): Show you the voltage of +3.3V/+5V/+12V/-12V/-5V/5VSB(V). VBAT (V) Show you the voltage level of the battery. Shutdown Temperature: This item allows you to set up the CPU shutdown Temperature. This item is ®...

  • Page 67: Frequency/Voltage Control

    Award BIOS Setup 3.11 Frequency/Voltage Control Phoenix - AwardBIOS CMOS Setup Utility Frequency/Voltage Control Auto Detect DIMM/PCI CLK Enabled Item Help Spread Spectrum Disabled ____________________________ CPU Clock 133MHz Ø Menu Level ↑↓→←Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values F6: Fail-safe defaults F7: Optimized Defaults...

  • Page 68: Load Fail-Safe Default

    Award BIOS Setup 3.12 Load Fail-Safe Defaults When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Load Fail-Safe Defaults (Y/N)? N Pressing “Y” loads the BIOS default values for the most stable, minimal-performance system operations.

  • Page 69: Supervisor/User Password Setting

    Award BIOS Setup 3.14 Supervisor/User Password Setting You can set either supervisor or user password, or both of then. The differences between are: Set Supervisor Password: can enter and change the options of the setup menus. Set User Password: just can only enter but do not have the right to change the options of the setup menus.

  • Page 70: Exit Selecting

    Award BIOS Setup 3.15 Exit Selecting Save & Exit Setup Pressing <Enter> on this item asks for confirmation: Save to CMOS and EXIT (Y/N)? Y Pressing “Y” stores the selections made in the menus in CMOS – a special section of memory that stays on after you turn your system off. The next time you boot your computer, the BIOS configures your system according to the Setup selections stored in CMOS.

  • Page 71: Warranty Policy

    Warranty Policy Warranty Policy Thank you for choosing ADLINK. To understand your rights and enjoy all the after-sales services we offer, please read the following carefully. Before using ADLINK’s products, please read the user manual and follow the instructions exactly. When sending in damaged products for repair, please attach an RMA application form.
  • Page 72 Warranty Policy Customers are responsible for the fees regarding transportation of damaged products to our company or to the sales office. To ensure the speed and quality of product repair, please download an RMA application form from our company website www.adlinktech.com. Damaged products with RMA forms attached receive priority.
