INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
These instructions are supplementary to the Installation and
Operating Instructions supplied with the replace and should be
kept together. Refer to the Installation and Operating Instructions for
proper gas supply, safety requirements and operating instructions.
Visit www.townandcountryfireplaces.net for the most recent version of this manual
200317-24
TC30
TRANQUILITY
BURNER KIT
INSTRUCTIONS
PART# TC30.NG04D
For TC30 Series D
Fireplaces
TC30_NG04D
5056.42904D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC30.NG04D and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TC30.NG04D

Summary of Contents for Town & Country Fireplaces TC30.NG04D

  • Page 1 Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions. TC30 TRANQUILITY BURNER KIT INSTRUCTIONS PART# TC30.NG04D For TC30 Series D Fireplaces Visit www.townandcountryfireplaces.net for the most recent version of this manual 200317-24 TC30_NG04D...

  • Page 2: Contents Of Package

    Contents of Package Figure 1: TC30 Tranquility burner kit parts. A. Burner assembly (including pilot & gas lines) B. Panel, base (attached to burner assembly). C. Pebble assembly D. Hardware - tapered plugs, screws, brush, panel clips. E. Side cover - left hand side. F.
  • Page 3 Tranquility Burner Installation If converting to propane see conversion instructions on page 13 before proceeding with Tranquility Burner Kit. Figure 2: 4 holes in replace oor to be plugged. 1. Plug the 4 vacant holes in the bottom of the rebox with 1/2” screws, as they are not required to attach this style of burner (Figure 2).

  • Page 4: Rear Panel

    Figure 5: Left hand side cover. Figure 6: Right hand side cover. 4. Place side covers between the burner tray and its base (Figure 5 and Figure 6) before the burner tray is inserted into the rebox. These will remain in the retracted position until later in the instal- lation process.
  • Page 5 Interface module Figure 8: Gas and pilot supply tubes. 6. Attach the main gas supply line and the pilot gas supply line to the bulk head ttings and tighten (Figure 8). Ensure that there are no leaks. 7. Feed the ignition and sensor wires through the bulkhead plate and gasket to the rebox (Figure 9).
  • Page 6 Flame sensor wire (white) Ignition wire (red) Interface module Figure 10: Interface module. 8. Attach the ignition and sensor wires to the interface module as indicated in Figure 10. 9. Once the gas and electrical lines are connected to the bulkhead and the interface module, rein- stall the valve control center’s access cover (Figure 3 on page 3).
  • Page 7 Figure 12: Panel retainer removal. 10. Remove the two screws (Figure 11) which secure the panel retainer to the ceiling. Remove the panel retainer and keep for reinstallation (Figure 12). 11. Attach a panel clip on each of the side panels (Figure 13). These clips will t over the upper rear panel, holding it in place.
  • Page 8 NOTE: Remove this tag and plastic tie before installing upper rear panel Figure 14: Right side panel partially installed. 12. Remove tag and plastic tie from the ue damper before installing the upper rear panel. 13. Install one of the side panels until it’s nearly up against the rebox wall. Leave enough room between the panel and wall so that the upper rear panel can be slipped in behind the side panel.
  • Page 9 Figure 16: Left hand side panel installed. 15. Install the other side panel (Figure 16) and bend its retaining clip over the upper rear panel as in the previous step. 16. Reinsert the two screws previously removed from the panel retainer but do not tighten. Reinstall the panel retainer and t slots to hook onto the two screws.
  • Page 10 Figure 18: Securing side covers. 17. Move the two side covers previously placed between the burner and its base, out to the side panels. Line the screw holes in the side covers up with the screw holes in the burner tray base. Use supplied self taping screws to secure the covers to the base (Figure 18).
  • Page 11 Figure 20: Applying sand to burner tray. 20. Remove tapered plugs from ports. 21. Remove pebble assembly from packaging by placing hand on top and tipping upside down. Note that the rock in the lower left is hollow underneath and will t over top of the pilot assembly (Figure 21).
  • Page 12 Rock set location pins Figure 22: Location pins for rock set. 23. Install glass door. Unit is ready for lighting. Figure 23: Rock set in place. Note: The base panel (Figure 24) is not used with the Tranquility burner and is a left over item. Figure 24: Base panel.

  • Page 13: Propane Conversion

    Propane Conversion WARNING This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer's instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly, a fire, explosion or production of carbon monoxide may result causing property damage, personal injury or loss of life.
  • Page 14 Ignition and sensor wires Pilot gas supply Main gas supply connection connection (Do not disconnect) Figure 26: Connections at bulkhead. 4. Disconnect the pilot gas supply line at the bulkhead (Figure 26). DO NOT disconnect the main gas supply line from the bulkhead. Flame sensor wire (white) Ignition wire (red)
  • Page 15 Pilot assy. bracket Pilot gas line Air shutter Ori ce Figure 28: Removing front burner tray screws. Figure 29: Underside of burner. 6. Remove the 2 front and 1 rear screws holding the burner tray in place (Figure 28). 7. Gently lift up the burner tray from its supports while sliding it to the left to disengage the burner tube from the ori ce.
  • Page 16 Figure 33: Removing pilot assembly. Figure 32: Air shutter half opened for propane gas. 9. Loosen the primary air shutter screw (Figure 31), open shutter half way and re-tighten (Figure 32). 10. Remove the 2 screws holding the pilot assembly in place with a short screwdriver (Figure 33). 11.
  • Page 17 Hole in band Figure 35: Band in natural gas position. Figure 36: Band in liquid propane position. 12. Slide the pilot adjustment band over and ensure that the hole in the ori ce band is showing. Figure 35 shows the pilot in the natural gas position. Figure 36 shows the pilot in propane gas position.

  • Page 18: Gas Pressure Check

    Gas Pressure Check Note: To test the gas pressure, turn off the gas supply before removing the plug from the sup- ply pressure test port or manifold pressure test port. Verify gas pressures with the fireplace lit and on the highest setting. Remove the plug from the pressure test port.

  • Page 19: Burner Flame Adjustment

    Burner Flame Adjustment The air shutter on the burner tube controls the primary combustion air. It is set to the closed position at the factory for natural gas fuel. Some adjustment may be necessary to obtain desired ame and to eliminate carbon deposits. Evaluate ame appearance after the replace has reached operating temperature.

  • Page 20: Replacement Parts

    DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. #5 PILOT ASSEMBLY, CONVERTIBLE ..TCRP.5005025 #1 TRANQUILITY BURNER KIT ....TC30.NG04D #6 ORIFICE, NATURAL GAS (#32) ....5021.332A #2 PEBBLE ASSEMBLY ......... TC36.9499 #7 SAND ..........TC36.SAND22 #3 MAIN SUPPLY TUBE ........5019.223 #8 PROPANE CONVERSION KIT ....
  • Page 21 TC30_NG04D 200317-24 5056.42904D...
  • Page 22 5056.42904D TC30_NG04D 200317-24...
  • Page 23 TC30_NG04D 200317-24 5056.42904D...
  • Page 24 © 2017 Copyright Paci c Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer. Web site: www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
