IMPORTANT:
THESE INSTRUCTIONS ARE TO REMAIN
WITH THE APPLIANCE INSTRUCTIONS
These instructions are supplementary to the Installation and
Operating Instructions supplied with the fireplace and should
be kept together. Refer to the Installation and Operating
Instructions for proper gas supply, safety requirements and
operating instructions.
210705-8
TC36
COUNTRY HOME
BURNER KIT
INSTRUCTIONS
PART#
TC36.NG02
FOR TC36
TC36.NG02
5056.427.2
