Town & Country Fireplaces TC30.NG04D Instructions Manual

Tranquility burner kit series d
Hide thumbs Also See for TC30.NG04D:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction and Installation Manual
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
These instructions are supplementary to the Installation
and Operating Instructions supplied with the fireplace
and should be kept together. Refer to the Installation
and Operating Instructions for proper gas supply, safety
requirements and operating instructions.
270315-16
TC30
TRANQUILITY
BURNER KIT
INSTRUCTIONS
PART#
TC30.NG04D
For TC30 Series D
Fireplaces
TC30_NG04D
5056.42904D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC30.NG04D and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TC30.NG04D

Summary of Contents for Town & Country Fireplaces TC30.NG04D

  • Page 1 Operating Instructions supplied with the fireplace and should be kept together. Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions. TC30 TRANQUILITY BURNER KIT INSTRUCTIONS PART# TC30.NG04D For TC30 Series D Fireplaces 270315-16 TC30_NG04D 5056.42904D...

  • Page 2: Contents Of Package

    Contents of Package BuRNeR assemBly PaNel, Base PeBBle assemBly 2.2 lBs. saND COveR RHs COveR lHs BaG TaPeReD PluGs (NOT sHOwN) Tranquility Burner Installation If converting to propane see conversion instructions on page #6 before proceeding. NOTE: Plug the 4 vacant holes in the bottom of the firebox with 1/2” screws, as they are not required to attach this style of burner.
  • Page 3 Position lower rear porcelain panel Fig #4 centered at the rear of the firebox. Place burner assembly into the firebox against the rear panel. (Fig #4) attach the manifold supply tube and the pilot supply tube to the bulk head fittings and tighten.
  • Page 4 2 SCREWS 4. secure the electrical bulkhead plate Fig #6 (Fig.#6) and gasket to the firebox. (2 screws) attach the ignition and sensor wires to the module. (Fig.#7) BULKHEAD PLATE Fig #7 IGNITION FLAME INTERFACE WIRE SENSOR MODULE (RED) WIRE (WHITE) TC30_ng04D_270315-16 5056.42904D...
  • Page 5 Remove panel retainer clips from upper Fig #8 heat shield. Install right porcelain panel tilting in from front corner. secure the right panel with one of the previously removed panel retainer clips. (Fig #8) Fig #9 Bend up retaining clip on the left panel. Position upper rear panel on the top of the lower rear panel and behind the right panel.
  • Page 6 Bend the retaining clip down over the Fig #10 upper back panel. (Fig #10) NOTE: The clips can be adjusted side to side to minimize any gaps between the panels. slide covers out and attach to base with one screw each. (Fig #11) Fig #11 TC30_ng04D_270315-16...
  • Page 7 10. Insert tapered plugs into raised burner Fig #12 ports to prevent sand from entering ports. (Fig #12) Fig #13 11. Place sand in tray. Brush sand smooth and level to just below top of raised burner ports. Gently blow excess sand from around ports.
  • Page 8 13. Remove pebble assembly from Fig #14 packaging by placing hand on top and tipping upside down. Gently place pebble assembly onto sand base using pins to locate position. (Fig #14) NOTE: Lift pebble assembly from bottom. Do not lift by top rocks. Hollowed out rock must cover the pilot.

  • Page 9: Propane Conversion

    Propane Conversion If the unit is to be used on propane conver t as follows using the components supplied with this burner: CAUTION The gas supply and electrical power shall be shut off before proceeding with the conversion. Note: maIN BuRNeR (1.90 mm) Factory supplied components must ORIFICe (5022.76) be used to ensure correct input.
  • Page 10 with a 7/16” wrench loosen the pilot head Fig #19 on the pilot assembly using a wrench to hold the bracket steady. (Fig. #19) 6. slide the pilot adjustment band over and ensure that the hole in the orifice band is showing.
  • Page 11 Fig #20b Fig. #20b shows LP position Re-attach the pilot assembly. HOLE For complete valve installation instructions, refer to the instruction book included in the SIT conversion kit. Fill in the date and t h e n a m e t h e person who performed the conversion in the white...

  • Page 12: Gas Pressure Check

    Gas Pressure Check Note: To test the gas pressure, turn off the gas supply before removing the plug from Fig #27a the supply pressure test port or manifold pressure test port. Verify gas pressures with the fireplace lit and on the highest setting. suPPly PRessuRe maNIFOlD...

  • Page 13: Burner Flame Adjustment

    Burner Flame Adjustment The air shutter on the burner tube controls the primary combustion air. It is set to the closed position at the factory for natural gas fuel. some adjustment may be necessary to obtain desired flame and to eliminate carbon deposits. evaluate flame appearance after the fireplace has reached operating temperature.

  • Page 14: Replacement Parts

    (wHeN ORDeRING, INCluDe PaRT NumBeR wITH DesCRIPTION) ITEM ..DESCRIPTION ............. PART NO. ITEM ..DESCRIPTION ............PART NO. #5..PILOT ASSEMBLY, CONVERTIBLE .. TCRP.5005025 #1..TRANQUILITY BURNER KIT ..... TC30.NG04D #6..ORIFICE, NATURAL GAS (#32) ....5021.332A #2..PEBBLE ASSEMBLY ......TC36.9499 #7..
  • Page 15 TC30_ng04D_270315-16 5056.42904D...
  • Page 16 © 2015 Copyright Pacific energy Fireplace Products lTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer. Web site: www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
