IMPORTANT:
THESE INSTRUCTIONS ARE TO REMAIN
WITH THE HOMEOWNER
These instructions are supplementary to the Installation
and Operating Instructions supplied with the fi replace
and should be kept together. Refer to the Installation
and Operating Instructions for proper gas supply, safety
requirements and operating instructions.
290411-16
TC36
TRANQUILITY
BURNER KIT
INSTRUCTIONS
PART# TC36.NG04C
For TC36 Series C
TC36.NG04C
5056.427C4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC36.NG04C and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TC36.NG04C

Summary of Contents for Town & Country Fireplaces TC36.NG04C

  • Page 1 Operating Instructions supplied with the fi replace and should be kept together. Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions. TC36 TRANQUILITY BURNER KIT INSTRUCTIONS PART# TC36.NG04C For TC36 Series C 290411-16 TC36.NG04C 5056.427C4...

  • Page 2: Contents Of Package

    Bend fl ex lines into the approximate shape. (Fig #1) Place covers under the burner tray. (Fig #2a & 2b) NOTE: Shutter must be fully closed for Natural gas, fully open for Propane. Fig #1 Fig #2a Fig #2b TC36.NG04C 290411-16...
  • Page 3 Replace screws to plug vacant holes. Fig #4 Remove the two screws from lower sides of air channel. Install lower back panel using the two screws previously removed. Place burner assembly into the fi rebox against the rear panel. (Fig #4) TC36.NG04C 290411-16...
  • Page 4 (2 screws) Attach the ignition and sensor wires to the module. Red end to the connector marked by the red dot, white end to the connector BULKHEAD PLATE marked by the white dot(Fig. #6 & 7) TC36.NG04C 290411-16...
  • Page 5 Fig #7 MODULE WHITE END TO RED END TO WHITE DOT RED DOT Fig #8 Remove panel retainer from upper heat shield. Install right porcelain panel, tilting in from front corner. (Fig #8) TC36.NG04C 290411-16...
  • Page 6 Fig #9 back panel and behind right panel. (Fig #9) While supporting the upper rear panel, Fig #10 install and secure the left panel in the same manner as the right panel. (Fig #10) Re-install panel retainers. TC36.NG04C 290411-16...
  • Page 7 10. Slide covers out and attach to base Fig #11 with one screw each. Fig #12 11. Insert tapered plugs into raised burner ports to prevent sand from entering ports. (Fig #12) TC36.NG04C 290411-16...
  • Page 8 Gently place pebble assembly onto sand base using pins to locate position. (Fig #14) NOTE: Lift pebble assembly from bottom. Do not lift by top rocks. Hollowed out rock must cover the pilot. Fig #14 TC36.NG04C 290411-16...
  • Page 9 15. Install glass door. Unit is ready for Fig #15 lighting. TC36.NG04C 290411-16...

  • Page 10: Propane Conversion

    Loosen the primary air shutter screw, After conversion confi rm proper manifold open shutter fully and re-tighten. pressure. (Fig. #17) Fig #18 4. Remove the pilot assembly using a stubby screwdriver to remove the 2 screws holding it in place. (Fig #18) TC36.NG04C 290411-16...
  • Page 11 Fig #23 Replace the minimum rate screw with the one provided in the propane con- version kit supplied with this fi replace. Ensure that the screw is fully seated. (Fig. #23) TC36.NG04C 290411-16...
  • Page 12 Peel off the protective backing and apply the conversion label directly over the gas specifi cations on the rating label. Fig #26 13. Re-attach the access panel to the side of the fi rebox with the screws previously removed. (Fig. #26) TC36.NG04C 290411-16...

  • Page 13: Gas Pressure Check

    Correct gas pressure requirement: Supply Pressure Natural Gas Propane Min. Pressure 5.0" WC 12.5" WC (For purpose of input adjustment) Max. Pressure 13.9" WC 13.9" WC Manifold Pressure Maximum 3.8" WC 11" WC Minimum 2.1" WC 5.5" WC TC36.NG04C 290411-16...

  • Page 14: Burner Flame Adjustment

    The shutter may also be opened to lessen the fl ame height. Fig #30 NOTE: Proper air shutter setting is required. The fl ame should be just orange and “lazy” . It should NEVER be set to create sooting on internal parts and window glass. TC36.NG04C 290411-16...

  • Page 15: Replacement Parts

    (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM ..DESCRIPTION ..........PART NO. ITEM ..DESCRIPTION ..........PART NO. #5..PILOT ASSEMBLY, CONVERTIBLE .. TCRP.5005025 #1..TRANQUILITY BURNER KIT ..... TC36.NG04C #6..ORIFICE, NATURAL GAS (#30) ..5022.13 #2..PEBBLE ASSEMBLY ......TC36.9499 #7..PROPANE CONVERSION KIT ... TC36.LPCE01 #3..
  • Page 16 Technical support: 1-250-748-1184 Web site: www.townandcountryfi replaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
