IMPORTANT:
THESE INSTRUCTIONS ARE TO REMAIN
WITH THE HOMEOWNER
These instructions are supplementary to the Installation
and Operating Instructions supplied with the fi replace
and should be kept together. Refer to the Installation
and Operating Instructions for proper gas supply, safety
requirements and operating instructions.
180411-20
TC30
TRANQUILITY
BURNER KIT
INSTRUCTIONS
PART#
TC30.NG04C
For TC30 Series C
TC30.NG04C
5056.42904
Advertisement
Table of Contents
Related Manuals for Town & Country Fireplaces TC30.NG04C
Summary of Contents for Town & Country Fireplaces TC30.NG04C
- Page 1 Operating Instructions supplied with the fi replace and should be kept together. Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions. TC30 TRANQUILITY BURNER KIT INSTRUCTIONS PART# TC30.NG04C For TC30 Series C 180411-20 TC30.NG04C 5056.42904...
-
Page 2: Contents Of Package
Bend fl ex lines into the approximate shape. (Fig #1) Place covers under the burner tray. (Fig #2 & 3) NOTE: Shutter must be fully closed for Natural gas, half open for Propane. Fig #2 Fig #3 Fig #1 TC30.NG04C 180411-20... - Page 3 (Fig #4) Attach the manifold supply tube and the pilot supply tube to the bulk head fi ttings and tighten. (Fig. #5) Ensure that there are no leaks. Fig #5 TC30.NG04C 180411-20...
- Page 4 Red end to the connector marked by the red dot, white end to the connector marked by the white dot(Fig. #6 & 7) BULKHEAD PLATE Fig #7 MODULE WHITE END TO RED END TO WHITE DOT RED DOT TC30.NG04C 180411-20...
- Page 5 Position upper rear panel on the top of the lower rear panel and behind the right panel. While supporting the upper rear panel install and secure the left panel in the same manner as the right panel. (Fig #9) TC30.NG04C 180411-20...
- Page 6 Bend the retaining clip down over the upper back panel. (Fig #10) NOTE: The clips can be adjusted side to side to minimize any gaps between the panels. Slide covers out and attach to base with one screw each. (Fig #11) Fig #11 TC30.NG04C 180411-20...
- Page 7 (Fig #12) Fig #13 11. Place sand in tray. Brush sand smooth and level to just below top of raised burner ports. Gently blow excess sand from around ports. (Fig #13) 12. Remove tapered plugs from ports. TC30.NG04C 180411-20...
- Page 8 (Fig #14) NOTE: Lift pebble assembly from bottom. Do not lift by top rocks. Hollowed out rock must cover the pilot. Fig #15 14. Install glass door. Unit is ready for lighting. TC30.NG04C 180411-20...
-
Page 9: Propane Conversion
Fig #18 converted appliance is checked as specifi ed in the manufacturer's instructions supplied with the kit. 4. Remove the 2 screws holding the pilot assembly in place with a stubby screwdriver. (Fig #18) TC30.NG04C 180411-20... - Page 10 (Fig. #19) 6. Slide the pilot adjustment band over and ensure that the hole in the orifi ce band is showing. Fig. #20a shows NG position Fig #20a TC30.NG04C 180411-20...
- Page 11 At this point a groove on the screw body will be visible just above the valve body. Insert a thin tool (knife blade or fi ne screwdriver blade) into the groove and gently pry the screw up. Minimum rate screw TC30.NG04C 180411-20...
- Page 12 Ensure that the screw is fully seated. (Fig. #22) Minimum rate screw Fig #23 10. Pull off the aluminum cap from the top of the pressure regulator. (Fig. #23) TC30.NG04C 180411-20...
- Page 13 (3.45 kPa) de conversion par une organi- 11.0 in/wc / 11.0 po/c.e. zation qui accepte la responsi- (.95 kPa) bilité pour une installation en bon état. # 48 (1.93 mm) Max.: 35,000 (10.3) Min.: 27,000 (7.91) 080411 6-TC30 5052.52085 TC30.NG04C 180411-20...
-
Page 14: Gas Pressure Check
Correct gas pressure requirement: Supply Pressure Natural Gas Propane Min. Pressure 5.0" WC 12.5" WC (For purpose of input adjustment) Max. Pressure 13.9" WC 13.9" WC Manifold Pressure Maximum 3.8" WC 11" WC Minimum 2.1" WC 5.5" WC TC30.NG04C 180411-20... -
Page 15: Burner Flame Adjustment
Proper air shutter setting is required, fully closed for natural gas and half open for propane. The fl ame should be just orange and “lazy” . It should NEVER be set to create sooting on internal parts and window glass. TC30.NG04C 180411-20... -
Page 16: Replacement Parts
TAPERED PLUGS (not shown) PROPANE CONVERSION KIT ...(not shown) SAND (not shown) #2..PEBBLE ASSEMBLY #3..MAIN SUPPLY TUBE #4..PILOT TUBE #5..PILOT ASSEMBLY, CONVERTIBLE #6..ORIFICE NG #32 #7..PROPANE CONVERSION KIT (not shown) #8..SAND (not shown) TC30.NG04C 180411-20... - Page 17 TC30.NG04C 180411-20...
- Page 18 TC30.NG04C 180411-20...
- Page 19 TC30.NG04C 180411-20...
- Page 20 Technical support: 1-250-748-1184 Web site: www.townandcountryfi replaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
