Town & Country Fireplaces TC30.NG03D Instructions Manual

Black diamond burner kit for tc30 series d fireplaces
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
These instructions are supplementary to the Installation
and Operating Instructions supplied with the fireplace
and should be kept together. Refer to the Installation
and Operating Instructions for proper gas supply, safety
requirements and operating instructions.
270315-16
TC30
BLACK DIAMOND
BURNER KIT
INSTRUCTIONS
PART#
TC30.NG03D
For TC30 Series D
Fireplaces
TC30_NG03D
5056.42903D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC30.NG03D and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TC30.NG03D

Summary of Contents for Town & Country Fireplaces TC30.NG03D

  • Page 1 Operating Instructions supplied with the fireplace and should be kept together. Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions. TC30 BLACK DIAMOND BURNER KIT INSTRUCTIONS PART# TC30.NG03D For TC30 Series D Fireplaces 270315-16 TC30_NG03D 5056.42903D...

  • Page 2: Contents Of Package

    Contents of Package NOTE: MUST BE USED WITH PORCELAIN PANEL SET PART# TC30.PNLPBKB MANIFOLD ASSEMBLY (including supply tube) BURNER TUBE BURNER SHIELD MEDIA SPACER, Center MEDIA SPACER, Front MEDIA SPACER, Rear HARDWARE PACKAGE 5 lbs. GLASS MEDIA BURNER TRAY PILOT SHIELD (including pilot and pilot supply tube) TC30_NGO3D_270315-16 5056.42903D...
  • Page 3 Black Diamond Burner Installation A porcelain panel set must be used Fig #1 in conjunction with the installation of the burner assembly. See Installation and Operating Instructions manual for details. NOTE: Plug the 4 vacant holes in the bottom of the firebox with 1/2” screws, as they are not required to attach this style of burner.
  • Page 4 2 SCREWS 4. Secure the electrical bulkhead plate Fig #3 (Fig.#3) and gasket to the firebox. (2 screws) Attach the ignition and sensor wires to the module. (Fig.#4). BULKHEAD PLATE Fig #4 IGNITION FLAME INTERFACE WIRE SENSOR MODULE (RED) WIRE (WHITE) TC30_NGO3D_270315-16 5056.42903D...
  • Page 5 4. Install burner shield by tipping the shield Fig #5 into the firebox. Route pilot up through the opening in the burner shield. (Fig. #5) PILOT Fig #6 5. Attach the burner tray to the burner shield using two screws at the back of the tray. (Fig.
  • Page 6 6. Attach pilot shield to burner tray with two Fig #7 screws. (Fig. #7) Fig #8 Front and rear media spacers are now installed. (Fig. #8 & 9) TC30_NGO3D_270315-16 5056.42903D...
  • Page 7 Fig #9 Fig #10 8. Install burner by tilting burner inlet through tray. Ensure that the orifice has entered the inlet tube. (Fig#10). Set the air shutter to fully open for Propane or fully closed for Natural gas. TC30_NGO3D_270315-16 5056.42903D...
  • Page 8 9. Install the center media spacer and secure Fig #11 to the tray with two 1 1/2” screws. (Fig. #11 & 12) Three holes must line up to set each screw. Fig #12 TC30_NGO3D_270315-16 5056.42903D...
  • Page 9 10. Apply just enough glass media to cover Fig #13 the burner assembly. (Fig #13 & 14) NOTE: Too much glass media over the burner will cause sooting with the use of propane gas. Fig #14 TC30_NGO3D_270315-16 5056.42903D...

  • Page 10: Propane Conversion

    Propane Conversion WARNING This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer's instructions and all applicable codes and requirements of the authority having jurisdiction. MAIN BURNER If the information in these ORIFICE (5022.76) instructions is not followed Note: Factory supplied components must be used...
  • Page 11 Slide the pilot adjustment band over and Fig #17 ensure that the hole in the orifice band is showing. (Fig. #17 indicates NG position, Fig. #18 indicates LP position) Fig #18 Remove access panel, 10 screws, and set aside. (Fig. #23) HOLE TC30_NGO3D_270315-16 5056.42903D...
  • Page 12 8) Fill in the date and the name of the person who performed the conversion in the white area on the conversion label. Peel off the protective backing and apply the conversion label directly over the gas specifications on the rating label. Attach the access panel to the side of the firebox with the previously removed Fig #19...

  • Page 13: Gas Pressure Check

    Gas Pressure Check Note: To test the gas pressure, turn off the gas supply before removing the plug from Fig #21a the supply pressure test port or manifold pressure test port. Verify gas pressures with the fireplace lit and on the highest setting. SUPPLY PRESSURE MANIFOLD...

  • Page 14: Burner Flame Adjustment

    Burner Flame Adjustment The air shutter on the burner tube controls the primary combustion air to the gas burner and is preset at the factory for natural gas fuel. Some adjustment may be necessary to obtain desired flame and to eliminate carbon deposits. Evaluate flame appearance after the fireplace has reached operating temperature.

  • Page 15: Replacement Parts

    Replacement Parts (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM .... DESCRIPTION ................PART NO. #1....TC30 BLACK DIAMOND BURNER KIT .......TC30.NG03D #2....BURNER TUBE ..............TC36. 5011835 #3....PILOT ASSEMBLY, CONVERTIBLE ........TCRP.5005025 #4....PILOT SUPPLY TUBE ..............5019.225 #5....ORIFICE, NG (#32) ..............5021.332A #6....
  • Page 16 © 2015 Copyright Pacific Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer. Web site: www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
