TABLE OF CONTENTS READ DTCS ..........60 Overview ..........60 INTRODUCTION ........3 Ford/Lincoln/Mercury ......62 WARRANTY ..........3 GM/GMC..........63 SAFETY DEFINITIONS ........ 4 DATA STREAM ......... 68 SAFETY PRECAUTIONS ......4 Overview ..........68 GENERAL INFORMATION ......6 SPECIAL TESTS ........
Page 3: Introduction
INTRODUCTION The Mac Tools™ MDT 10 is a professional scan tool built into a durable AndroidTM tablet. Up to four hours of battery run time. Extremely fast boot time and Swift On function. Wi-Fi and web browser allow full internet access.
Page 4: Safety Definitions
SAFETY DEFINITIONS DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. WARNING indicates a potentially hazardous situation which if not avoided, could result in death or serious injury. CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
Page 5 • To reduce risk of injury, charge only Mac Tools rechargeable batteries for the handset product with the supplied charger. Other types of batteries may burst causing injury to persons and damage.
Page 6: General Information
GENERAL INFORMATION Introduction ss02588 2:59 Active Search Google for ... 1001 101001 CHECK 0101 Diagnostic Read DTCs Data Stream Special Tests Information 2013 335I (E92/E93) All System DTC Maintenance Tests Scan Browser Settings xDrive3.0 TIRE PRESSURE MONITOR CHECK Automated System View Data Stream System Wiring Test...
Page 7: Handset
• System Wiring Diagrams provides OEM specific, Full color, Full system diagrams. 6. Android Applications Button • Displays the Apps screen. 7. Camera Button • Opens the camera application. 8. Screen Shot Button • Press to take a picture of the current screen. 9.
Page 8: Handset Ports
Handset Ports ss02587 Handset Ports 1. Mini USB 2. VCI Port 3. Ethernet Connector 4. Audio port 5. USB Type “A” port 6. HDMI Port 7. Power port 8. Power Button 9. Speakers 10. Docking Station Port MACTOOLS.COM...
Page 9: Handset Back
Handset Back ss02589 Handset Back 1. Light • The light has two functions • Camera Flash mode • Flash Light mode 2. Camera • Rear Facing Camera is 5MP. 3. Microphone • Rear Facing Microphone. 800.MACTOOLS...
Page 10: Vehicle Communication Interface (Vci)
Vehicle Communication Interface (VCI) The Vehicle Communication Interface (VCI) translates vehicle diagnostic data link information for the handset using Wi-Fi wireless technology or a linked cable. The wireless capability of the tool is designed to communi- cate with the VCI when it is within a range of roughly 30 feet, even though it is possible to go farther. Every shop has different noise that can interfere and hamper the distance of a wireless network.
Page 11: Add-On Hardware Modules (Optional)
Add-on Hardware Modules (Optional) TPMS Tire Pressure Reset (TPR) Tool The Tire Pressure Reset (TPR) is a fast, simple, easy-touse TPMS activation tool that can be used with the handset or as a stand-alone tool. It works on vehicle TPMS sensors and automatically adjusts activation output power to eliminate cross-activation of near sensors.
Page 12: Setup
The handset will display DTCs from OBDI or OBDII systems. Real-time sensor data can be viewed in data stream mode. The user can also obtain diagnostic information regarding repairs. With the purchase of the Tech-Scope, the user is able to test sensors and systems for proper function. Browser mode allows the user to connect to the internet to find websites that may help with the repair of the vehicle.
Page 13: Battery Charging
Battery Charging Connect the handset to AC power and fully charge the battery. ss02584 Power Port 1. Handset 2. AC Power cord When the handset is turned on, the level of battery charge is indicated in the upper right corner of the screen. NOTE: The tool can be used while charging.
Page 14: Registration
ss02386 You’ve got the right tool! English Español French Select a language. REGISTRATION It is important to register the handset right away. To register, it will need a Wi-Fi internet connection. To connect to Wi-Fi, refer to steps 2 through 6. Register now enables the unit. Register later causes the device to go into a 30-day trial mode.
Page 15 ss02388 You’ve got the right tool! Setup Wi-Fi Register my Device Now Add Wi-Fi Network Register my Device Later This is needed for networks that do not broadcast their SSID Demo Mode Wi-Fi is not enabled Please enable Wi-Fi Next: Your Name Wi-Fi 3.
Page 16 ss02391 Select Wi-Fi Shop Connected Office Saved BACK NEXT 6. If an internet connection could not be established, follow the prompts on the screen and try again. ss02392 You’ve got the right tool! Setup Wi-Fi Register my Device Now Shop Register my Device Later Secured with WPA2 Office...
Page 17 Demo Mode City Service Center City Service Center 1/1/2016 cityshop@gmail.com 3135551234 1234 Main St. Detroit, MI 48202 United States Activate Now 10. MDT 10 is ready to use. ss02396 2:59 Active Search Google for ... 1001 101001 CHECK 0101 Diagnostic...
Page 18: 30 Day Trial
1. OWNERSHIP. The Software Product is licensed (not sold) to you. The Software Product shall remain the property of Bosch. Bosch I Agree 2. MDT 10 is ready to use. ss02398 2:59 Active Search Google for ...
Page 19: Provide Power To Vci
2. MDT 10 is ready to use. ss02400 2:59 Demo Search Google for ... 1001 101001 CHECK 0101 Diagnostic Read DTCs Data Stream Special Tests Information All System DTC Maintenance Tests Browser Settings Scan No Vehicle Selected CHECK Automated System...
Page 20 ss02591 VCI Connected to Vehicle 1. OBDII/DLC Cable 2. DLC 3. VCI Manual Pairing The first use will automatically pair. 1. Connect the VCI to the vehicle DLC. 2. Turn on handset and wait for it to display the home screen. 3.
Page 21 VCI Connection Manager icon VCI Connection Manager Icon Definitions No VCI is paired with the handset. VCI is paired on the hardware level, but software check had failed. VCI cannot be used without software update. VCI is connected via Wi-Fi. Software check is successful, VCI is ready for use, but Wi-Fi signal is degraded.
Page 22: Cable Connection
Restarting the tool: ss02585 1. Press and release the power button. ss02403 2:59 Active Search Google for ... 1001 101001 CHECK 0101 Diagnostic Read DTCs Data Stream Special Tests Information Power off Diagnostic Tool will shut down. All System DTC Maintenance Tests Scan Browser...
Page 23: Test Startup And Vehicle Connection
The same principle applies to switching vehicles as it did for wireless. Return to the home screen and then unplug and switch. ss02592 USB Cable 1. OBDII/DLC Cable 2. DLC Connector 3. USB Cable 4. Handset Wireless Range The wireless internet capability of the tool is designed to communicate with the router when it is within a range of roughly 90 feet, depending on the shop environment, even though it is possible to go farther.
Page 24: Application Settings
ss02404 2:59 Active Search Google for ... 1001 101001 CHECK 0101 Diagnostic Read DTCs Data Stream Special Tests Information All System DTC Maintenance Tests Scan Browser Settings No Vehicle Selected CHECK Automated System View Data Stream System Wiring Test Veiw Saved Tests Recordings Diagrams OBD-II...
Page 25: Software Information
Software Information From the Settings screen select Software Information. The current software versions will be displayed. Select View Open Source Software Details to view more in-depth information. ss02406 Current Settings 2005 Application Settings CoreManager 2.5.0.98 Chevrolet Windows DBCoordinatorAPI 2.5.0.98 Software Information DBCoordinatorCore 2.5.0.98 Database Schema 61 Software Update...
Page 26 Subscription The tool must be registered to see this tab. 1. From the Settings screen select Subscription. • Heavy duty vehicle function is locked and must be unlocked. • Need to obtain subscription code. • After one year, the user will be required to renew the subscriptions to receive product updates. ss02408 Current Settings...
Page 27 User Details 1. From the Settings screen select User Details. ss02411 Current Settings 2004 Application Settings Subaru John Owner’s First Name Software Information Smith Owner’s Last Name Dealership Distributor Name Software Update john.smith@gmail.com Email Subscriptions 3135551234 Phone User Details 1234 Main St Address 1 Contact Us Address 2 (optional)
Page 28 Language 1. From the Settings screen select Language 2. Follow the prompts on the screen • English • Spanish • French (when available) ss02413 Current Settings 2004 Application Settings Subaru English Espanol Software Information Software Update Subscriptions User Details Contact Us Langauge Direct-Hit®...
Page 29 Service 1. From the Settings screen select Service 2. Select Restart Communications ss02415 Current Settings 2004 Application Settings Subaru Software Information Software Update Subscriptions User Details Contact Us Langauge Direct-Hit® Service Restart Communications 3. Handset will Restart Communications ss02416 Current Settings 2004 Application Settings...
Page 30: Global Obdii Applications
GLOBAL OBDII APPLICATIONS Overview Global OBDII (also referred to as Generic OBDII) provides limited engine control and monitors the diagnostic control network of the vehicle. When a fault in the control network occurs, a DTC is recorded in the vehicle computer.
Page 31 ss02418 Current Generic OBDII READINESS MODE 1 Readiness (Mode 1) DATA STREAM MODE 1 Monitor Description Status FREEZE FRAME MODE 2 Catalyst Monitor Ready DTC’s MODES 3,4,7,A Misfire Monitor Not Supported O2 SENSORS MODE 5 2nd Air Monitor Ready NON-CONTINUOUS TESTS Evaporative Emissions Monitor Ready MODE 6...
Page 32: Data Stream
Data Stream Mode 1 views live vehicle sensor data. The data stream function shows live sensor and solenoid data streaming from the vehicle’s ECU (electronic control unit). ss02419 Current Generic OBDII READINESS MODE 1 DATA STREAM MODE 1 FREEZE FRAME MODE 2 DTC’s MODES 3,4,7,A O2 SENSORS MODE 5 NON-CONTINUOUS TESTS...
Page 33 Data Stream Button Definitions Enlarge Screen View Function To view the data in the enlarge view, press the Enlarge button. Select Function: 1. Choose only the data you want to view by checking the box in front of each desired data item.
Page 34 Data Stream Button Definitions Use English/Standard Units Selecting English/Standard Units will switch from Metric Units to English/Standard Units. Freeze Frame Mode 2 views data captured when a fault occurred. Freeze frame shows a data stream snapshot that was auto- matically recorded by the ECU when one or more DTCs occurred. ss02422 Current Generic OBDII...
Page 35: Dtcs Modes
DTCs Modes Modes 3, 4, 7, and A read and clear DTCs. ss02423 Current Generic OBDII READINESS MODE 1 DATA STREAM MODE 1 FREEZE FRAME MODE 2 DTC’s MODES 3,4,7,A O2 SENSORS MODE 5 NON-CONTINUOUS TESTS MODE 6 TAP ‘DTCs MODES 3, 4, 7, A’ TO REOPEN SPECIAL TESTS MODE 8 VEHICLE INFO MODE 9 1.
Page 36 OBDII DTC Nomenclature ss01521 P-0102 Fault (00-99) 1 - Fuel & Air Metering 2 - Fuel & Air Metering (Injector Circuit) 3 - Ignition Systems or Misfire 4 - Auxilary Emission Control 5 - Vehicle Speed Control and idle Control System 6 - Computer Output Circuit 7 - Transmission 8 - Transmission...
Page 37 DTCs Modes 3, 4, 5, A Button Definitions Clear DTCs Button The Clear DTCs button is used to clear codes and remove all but permanent DTCs on the selected controller. To clear codes, complete the following: NOTE: Clearing DTCs will erase current Mode 1 Readi- ness monitor information and require the user go through necessary drive cycles over again.
Page 38: Oxygen (O2) Sensors
Oxygen (O2) Sensors Mode 5 views O2 sensor monitor test results. ss02425 Current Generic OBDII READINESS MODE 1 Oxygen Sensor Tests (Mode 5) DATA STREAM MODE 1 Description Value Units FREEZE FRAME MODE 2 Bank 1 Sensor 1 DTC’s MODES 3,4,7,A High Sensor Voltage For Switch Time Calculation 0.000 0.003...
Page 39 Non-Continuous Tests Mode 6 views onboard monitoring test results for noncontinuous monitor systems. ss02425 Current Generic OBDII READINESS MODE 1 Oxygen Sensor Tests (Mode 5) DATA STREAM MODE 1 FREEZE FRAME MODE 2 DTC’s MODES 3,4,7,A Component parameters may not be valid if Readiness Status is ‘Not O2 SENSORS MODE 5 Ready’.
Page 40: Special Tests
Non-Continuous Tests Button Definitions Menu Button Tapping the Menu button displays a pop-up link that takes the user to more buttons. View Help Selecting View Help will open an online opera- tors manual. Use Metric Units Selecting Metric Units will switch from English/ Standard Units to Metric Units Use English/Standard Units Selecting English/Standard Units will switch...
Page 41 ss02429 Current SPECIAL TESTS ALL TESTS All Special Tests Search All Special Tests DPF TESTS DPF Tests EVAP TESTS Diesel Particulate Filter Regeneration EVAP Tests Evaporative System Leak Check When available, this selection will automatically take the user to the special test screen where the test group menu will be displayed.
Page 42: Vehicle Info
Vehicle Info Mode 9 views Vehicle Identification Numbers (VINs), calibration ID(s), and verification number(s). ss02430 Current Generic OBDII READINESS MODE 1 Vehicle Informationation (Mode 9) DATA STREAM MODE 1 FREEZE FRAME MODE 2 DTC’s MODES 3,4,7,A Make sure the key is ON and the Engine is OFF. O2 SENSORS MODE 5 CANCEL NON-CONTINUOUS TESTS...
Page 43 Vehicle Info Button Definitions Menu Button Tapping the Menu button displays a pop-up link that takes the user to more buttons. View Help Selecting View Help will open an online opera- tors manual. Use Metric Units Selecting Metric Units will switch from English/ Standard Units to Metric Units Use English/Standard Units Selecting English/Standard Units will switch...
Page 44: Selecting Vehicle
SELECTING VEHICLE WARNING Before performing any diagnostic functions, refer to the Safety Precautions and the warnings provided by the vehicle manufacturer. In addition, follow any warnings and instructions provided on the handset. Note: Select Demo to generate simulated data for demonstration purposes. ss02432 2:59 Active...
Page 45 ss02434 VEHICLE BAY SEARCH BY VIN RECENT FAVORITES Enter New Vehicle Start AutoID OBD-II Heavy Duty Start Auto ID Make sure the key is ON and the Engine is OFF. Cancel Demo Mode 4. The vehicle must have the key on, engine off (KOEO). ss02435 VEHICLE BAY SEARCH BY VIN...
Page 46 ss02437 YEAR MAKE MODEL SUBMODEL ENGINE CONTROLLER MAINTENANCE ELECTRONIC ENGINE GLOBAL OBDII TRANSMISSION TESTS SHIFTER OCCUPANT WIRELESS CTRL FINAL DRIVE RESTRAINT AUDIO MODULE (TPMS) CONTROL MODULE CONTROL ELECTRIC DRIVERS DOOR FCM CENTRAL HANDS FREE CABIN COMP NODE OVERHEAD MODULE GATEWAY MODULE MODULE HEATED SEAT...
Page 47: Manual Entry
Manual Entry The handset must be turned on, be paired with the VCI which is connected to the vehicle and currently dis- playing the home screen. Once those conditions are met, complete the following: ss02432 2:59 Active Search Google for ... 1001 101001 CHECK...
Page 48 ss02442 YEAR MAKE MODEL SUBMODEL ENGINE CONTROLLER ACURA ACURA ALFA ROMEO BUICK CADILLAC CHEVROLET CHRYSLER DODGE FIAT FORD FORD HONDA HONDA HYUNDAI INFINITI JEEP LEXUS LEXUS 2015 Selected Cancel 4. Select the make of vehicle. ss02443 YEAR MAKE MODEL SUBMODEL ENGINE CONTROLLER 2015 Acura...
Page 49 ss02445 YEAR MAKE MODEL SUBMODEL ENGINE CONTROLLER To confirm via VIN, use the digit 3.5, GAS, J35Y4, 3.5, GAS, J35Y4, Naturally Aspirated, Naturally Aspirated, SOHC SOHC VIN- VIN- 2015 Acura Selected Cancel MDX Base 7. Select the engine. Note: Some vehicles may not require this selection. ss02446 YEAR MAKE...
Page 50: Recent
ss02447 2:59 Active Search Google for ... 1001 101001 CHECK 0101 Diagnostic Read DTCs Data Stream Special Tests Information ACURA 2015 ACURA MDX (Base) All System DTC Maintenance Tests Browser Settings 3.5 Gas Scan ENGINE CHECK System Wiring Automated System View Data Stream Test Veiw Saved Tests...
Page 51 ss02448 VEHICLE BAY RECENT FAVORITES SEARCH BY VIN 2008 Chrysler 2015 Acura 1999 Chevrolet 2003 Cadillac Enter New Vehicle Crossfire C2500 2WD Limited 3.2 Base 2.0 LS 5.7 Luxury Sport 3.2 Start AutoID ENGINE TRANSMISSION ENGINE OBD-II Heavy Duty Demo Mode 2.
Page 52 ss02450 YEAR MAKE MODEL SUBMODEL ENGINE CONTROLLER MAINTENANCE ELECTRONIC ENGINE GLOBAL OBDII TRANSMISSION TESTS SHIFTER OCCUPANT WIRELESS CTRL FINAL DRIVE RESTRAINT AUDIO MODULE (TPMS) CONTROL MODULE CONTROL ELECTRIC DRIVERS DOOR FCM CENTRAL HANDS FREE CABIN COMP NODE OVERHEAD MODULE GATEWAY MODULE MODULE HEATED SEAT...
Page 53: Favorites
Favorites ss02432 2:59 Active Search Google for ... 1001 101001 CHECK 0101 Diagnostic Read DTCs Data Stream Special Tests Information All System DTC Maintenance Tests Browser Settings Scan No Vehicle Selected CHECK Automated System View Data Stream System Wiring Test Veiw Saved Tests Recordings Diagrams...
Page 54 ss02454 YEAR MAKE MODEL SUBMODEL ENGINE CONTROLLER MAINTENANCE ELECTRONIC TRANSMISSION ENGINE GLOBAL OBDII TESTS SHIFTER OCCUPANT WIRELESS CTRL FINAL DRIVE RESTRAINT AUDIO MODULE (TPMS) CONTROL MODULE CONTROL ELECTRIC FCM CENTRAL HANDS FREE DRIVERS DOOR CABIN COMP NODE OVERHEAD MODULE GATEWAY MODULE MODULE HEATED SEAT...
Page 55: Obd-Ii
OBD-II ss02432 2:59 Active Search Google for ... 1001 101001 CHECK 0101 Diagnostic Read DTCs Data Stream Special Tests Information All System DTC Maintenance Tests Scan Browser Settings No Vehicle Selected CHECK Automated System View Data Stream System Wiring Test Veiw Saved Tests Recordings Diagrams...
Page 56: Heavy Duty
Heavy Duty ss02432 2:59 Active Search Google for ... 1001 101001 CHECK 0101 Diagnostic Read DTCs Data Stream Special Tests Information All System DTC Maintenance Tests Browser Settings Scan No Vehicle Selected CHECK Automated System View Data Stream System Wiring Test Veiw Saved Tests Recordings...
Page 57 ss02459 VEHICLE BAY RECENT FAVORITES SEARCH BY VIN Select Option Looks lik Enter New Vehicle Engine J1939 You can always use the Vehicle Identification Number. Start AutoID Engine MID 128 J1587/1708 Transmission MID: 130 J1587/1708 OBD-II Brake MID: 136 J1587/1708 Heavy Duty Instrument Cluster MID: 140 J1587/1708 Vehicle Management MID: 142 J1587/1708...
Page 58 J1587/1708 DTC Nomenclature MID - Message Identification The MID Identifies the Component Example: MID 128 = Engine MID 130 = Transmission MID 136 = Brakes (ABS) PID - Parameter Identification The PID Identifies the data from a components electrical parts Example: PID 084 = Road Speed (MPH) PID 100 = Engine Oil Pressure (PSI) PID 177 = Transmission Oil Temperature (Degrees)
Page 59 J1939 DTC Nomenclature SA - Source Address The SA field contains the ECU that is sending the message Example: SA 0 = Engine SA 3 = Transmission SA 11 = Brakes System Controller SPN - Suspect Parameter Number The SPN is used to identify the item for which diagnostics are being reported Example: SPN 156 = Injector Timing Rail 1 Pressure SPN 031 = Transmission Range Position SPN 639 = J1939 Network...
Page 60: Read Dtcs
READ DTCS Overview The Read DTCs function allows reading, clearing, printing, and sharing (wireless or email) of vehicle DTCs. Onboard Code Assist information may also be available, for selection when DTCs are found. This information contains pertinent details regarding the selected DTC. For more detailed comprehensive information, go to Service and Settings, Direct-Hit®...
Page 61 Read DTCs Button Definitions Ford/Lincoln/Mercury Self Diagnostics button displays a pop up menu allowing the user to choose between specific special tests. GM/GMC Status button displays a pop up menu allowing the user to view the status on DTCs Clear DTCs Button The Clear DTCs button is used to clear codes and remove all but permanent DTCs on the selected controller.
Page 62: Ford/Lincoln/Mercury
Ford/Lincoln/Mercury When connected to a Ford/Lincoln/Mercury vehicle a pop up menu allowing the user to choose between specific special tests. ss02463 2:59 Active Search Google for ... 1001 101001 CHECK 0101 Diagnostic Read DTCs Data Stream Special Tests Information Ford 2012 Ford Mustang...
Page 63: Gm/Gmc
GM/GMC When connected to a GM/GMC vehicle a pop up menu appears, allowing the user to choose between specific special tests. ss02466 2:59 Active Search Google for ... 1001 101001 CHECK 0101 Diagnostic Read DTCs Data Stream Special Tests Information Chevrolet 2009 Chevrolet...
Page 64 Manual DTCs Certain vehicles do not support standard DTC protocol and will require a manual process for retrieving and clearing codes. ss02469 Current Diagnostic Trouble Codes CHECK 2002 Subrau 1) Take out diagnosis connector from side of drive’s seat heater unit. 2) Turn ignition switch Off.
Page 65 ss02472 Current Diagnostic Trouble Codes CHECK 2002 Subrau 1) Take out diagnosis connector from side of drive’s seat heater unit. 2) Turn ignition switch Off. 3) Connect diagnosis connector terminal 6 to diagnosis terminal. 4) Turn ignition switch On. 5) ABS warning light is set in the diagnostic mode and blinks to identify trouble code. 6) After the start code (11) is shown, the diagnostic trouble codes (DTC) will be shown in order of 4.
Page 66 ss02475 Current B1213 Less Than Two Keys Programmed To Passive Anti-Theft System 2008 Repair Hotline Code Assist Ford DESCRIPTION 800.288.6210 Code Criteria Description Element Action IDENTIFI DIRECT-HIT CODE ASSIST Frequently Reported Fixes Ignition Key(s) Replaced Google Frequently Reported Fixes Vehicle Theft Deterrent (VTD) Performed PCM Pin System Learn Procedure...
Page 67 • Input the username and password acquired from Identifix® by selecting the empty field. • Using the virtual keyboard enter the required information for both fields. • Select GO. 800.MACTOOLS...
Page 68: Data Stream
DATA STREAM Overview The data stream function shows live sensor and solenoid data streaming from the vehicle ECU (electronic control unit). Connect the VCI with the vehicle at key on engine off or key on engine running to see live dynamic data, instead of static live data.
Page 69 ss02478 Current 1001 101001 Data Stream 0101 2003 All Data Groups Cadillac Volkswagen/Audi Group System Status Volkswagen/Audi Group Enter a Group Between: 0 and 255 Select Customize System Status Cancel Ignition System Status Select Customize Knock Control Ignition Select Customize 4.
Page 70 ss02480 Current 1001 Data Stream 101001 0101 All Data Items 2003 Vehicle Speed Intake Air Temperature Cadillac 12 mph 111 °F Engine Coolant Temperature Fuel Tank Pressure 68 °F -5.7 inH2O Mileage Since DTC Cleared Calculated converter Temperature 37900 miles 574 °F Mileage Since MIL Request Fuel Level...
Page 71 ss02483 Current Data Stream 1001 101001 0101 All Data Items 2003 Cadillac Vehicle Speed Intake Air Temperature °F 1 of 15 190 / 200 frames BUFFERING DATA... Note: The far left 2-data tiles will be enlarged to select the specific data tiles to be enlarged. To see more graphs use your finger to swipe the screen.
Page 72 Full Screen View Function To view the data full screen, press Full Screen button. ss02484 Current 1001 Data Stream 101001 0101 All Data Items 2003 Cadillac Vehicle Speed Intake Air Temperature °F 1 of 15 190 / 200 frames BUFFERING DATA... To view the data in Full Screen view, press the Zoom In button.
Page 73 Display Types To change data item display types, select the data item menu button located in upper right ss02488 Current 1001 Data Stream 101001 0101 All Data Items 2003 Vehicle Speed Engine Coolant Mileage Since DTC Mileage Since MIL Cadillac Temperature Cleared Request...
Page 74 Display Type Button Definitions Use English/Standard Units Selecting English/Standard Units will switch from Metric Units to English/Standard Units. NOTE: Not all display types are available for all data items Select Function ss02489 Current 1001 Data Stream 101001 0101 All Data Items 2003 Vehicle Speed Engine Coolant...
Page 75 Sort Function ss02491 Current Data Stream 1001 101001 0101 All Data Items 2003 Vehicle Speed Engine Coolant Mileage Since DTC Cadillac Temperature Cleared 67667 miles °F 63042 157372 High Intake Air Temperature Fuel Tank Pressure -0.3 -3.5 °F inH2O -11.7 1 of 1 BUFFERING DATA...
Page 76 Recording ss02493 Current 1001 Data Stream 101001 0101 All Data Items 2003 Vehicle Speed Engine Coolant Mileage Since DTC Mileage Since MIL Cadillac Temperature Cleared Request 125792 30054 miles miles °F 22817 84647 148941 12277 26670 40498 High High Intake Air Temperature Fuel Tank Pressure Calculated Converter Fuel Level...
Page 77 oldest one out of the list. Currently, there is no way to manually delete recordings. • To view recordings, select the Recordings button near the top of the display. 2. Select the desired recording. Playback Instructions ss02496 Current 1001 Recorded Data Stream 101001 0101 2003 Cadillac CTS Luxury Sport ENGINE...
Page 78: Special Tests
SPECIAL TESTS Overview Depending on the vehicle and controller selected, special tests are available. The special test function is a key component to the tool because it allows circuit testing without ever touching a circuit with a DVOM or other electrical testing equipment. This will also protect electrical circuits from being contaminated or damaged from manual testing with electrical troubleshooting equipment.
Page 79 ss02499 Current SPECIAL TESTS 2007 ALL TESTS Engine Tests Jeep ACCESS VIN Compression Test DIESEL CONTROLS Idle Speed Setpoint DPF TESTS EGR TESTS ENGINE TESTS FAN TESTS FUEL TESTS OTHER TESTS OXYGEN SENSOR TESTS RESET TESTS 3. Only the tests meeting the search criteria are displayed. Select the desired test to be executed. Note: Some tests may require a registration like Tire Pressure Sensor Test ss02500 Current...
Page 80 Note: If there is data streaming attached to the Special Test then you will be taken to Special Tests in Data Stream. It is possible to change controllers within the special test menu screen after exiting the current test. All features outside the special test are locked out until the test is terminated to protect the vehicle and the person running the special test.
Page 81 800.MACTOOLS...
Page 82: Diagnostic Information
DIAGNOSTIC INFORMATION Overview Diagnostic Information provides diagnostic, repair, and reset information for the selected vehicle. ss02502 2:59 Active Search Google for ... 1001 101001 CHECK 0101 Diagnostic Read DTCs Data Stream Special Tests Information Jeep 2007 Jeep Wangler All System DTC Maintenance Tests Browser Settings...
Page 83 Code Assist™ Library This function will allow a search for DTCs by letter/number designation. ss02504 Current Code-Assist Library 2007 P Codes Jeep (99) B Codes (13) C Codes U Codes (19) Select DTC Type. 1. Select Code-Assist library from the Diagnostic Information screen. ss02505 Current Code-Assist Library...
Page 84 Identifix Direct-Hit ® ® Identifix® Direct-Hit® requires an account setup with Identifix®. To set up an account, go to www.identifix. com and complete the necessary steps. Once an account is set up with Identifix®: • Select Settings button from the home screen. • Select Direct-Hit®...
Page 85 Repair Trac ® Uses the AutoDetect Results Number Indication feature described above. 1. Select Repair Trac® from the Diagnostic Information screen to view previously reported repairs for the selected vehicle/controller combination. ss02507 Current Repair-Trac® 2007 Systems Jeep Engine Performance Starting and Charging Select the desired system.
Page 86 Symptom List Diagnostic Information provides diagnostic, repair, and reset information for the selected vehicle. 1. Select Symptom List from the Diagnostic Information screen. • Displays a list of symptoms associated with the selected vehicle/controller combination. • Select Symptoms List from the Diagnostic Information menu. ss02509 Current Symptoms List...
Page 87 Drive Cycle The OBDII system has a series of systems that run self-tests. These systems or components have to be made ready either by simply turning on the ignition or by manipulating the system in some manner. This is called Drive Cycle.
Page 88 PCM Connector Pin Information Displays a list of which connector and pin a component or sensor is received through on the PCM. 1. Select PCM Pin Information from the Diagnostic Information screen. ss02513 Current PCM Pin 2003 PCM Pin Pin Number Description C1-1 Ground...
Page 89 Technical Service Bulletin (TSB) References Displays TSBs associated with the vehicle/controller combination. 1. Select TSB Reference from the Diagnostic Information screen. ss02515 Current TSB Reference 2003 TSB Number TSB Description 02-09-41-001 Computers & Controls - DTC’s Set When Replacing Modules 01-07-30-002C Electrical - Malfunction Indicator Lamp ON / Automatic Transmission Stuck in 3rd Gear...
Page 90 Location Used to find where specific components are located. 1. Select Location Info from the Diagnostic Information screen. ss02517 Current Location 2004 FUSE BOX LOCATION Ford Battery junction box is located in the left rear engine compartment. The central junction box is located under the dash panel, near the steering column.
Page 91 Tune Up Specifications Provides specifications for specific components when a tune up is performed. 1. Select Tune Up Specs from the Diagnostic Information screen. ss02519 Current Tune Up Specs 2004 Injector Ford Specification: 11 to 18 Ohms Starter Regulator Timing Spark Plug Firing Order Battery...
Page 92 Battery Disconnect Displays procedures for disconnect the battery on the selected vehicle. 1. Select Battery Disconnect from the Diagnostic Information screen. ss02521 Current Battery Disconnecta 2004 Battery Location Battery Location Ford See Image General Information Before Battery Disconnection Before Battery Connection 122448 2.
Page 93 Read DTCs Button Definitions Menu Button Tapping the Menu button displays a pop-up link that takes the user to help content related to reading DTCs. Note: an active internet connection will be required. View Help Selecting View Help will open an online opera- tors manual.
Page 94: Maintenance Tests
MAINTENANCE TESTS Overview Maintenance Tests provide a way for specific systems to be recalibrated or reset after service. Maintenance test availability will vary from vehicle to vehicle, and will be updated over time. Maintenance tests are the same as special tests, but this is a shortcut to most frequently used tests on the selected vehicle.
Page 95 ss02527 YEAR MAKE MODEL SUBMODEL ENGINE CONTROLLER MAINTENANCE ENGINE GLOBAL OBDII TRANSMISSION TESTS Select a Maintenance Test Catagory WIRELESS CTRL OCCUPANT ELECTRONIC AUTO SWAY BAR AUDIO MODULE (TPMS) CLASSIFICATION SUSPENSION Battery/Charging Brake Service ELECTRIC FCM CENTRAL CABIN COMP NODE CLIMATE OVERHEAD GATEWAY MODULE...
Page 96 ss02497 2:59 Active Search Google for ... 1001 101001 CHECK 0101 Diagnostic Read DTCs Data Stream Special Tests Information Jeep 2007 Jeep Wangler All System DTC Maintenance Tests Scan Browser Settings Unlimited Engine CHECK Automated System View Data Stream System Wiring Test Veiw Saved Tests Recordings...
Page 97 800.MACTOOLS...
Page 98: All System Dtc Scan
ALL SYSTEM DTC SCAN Overview The All System DTC Scan will scan all available controllers on the selected vehicle. Depending on the vehicle, the handset may ask qualifying questions concerning particular controller types for the vehicle being scanned. If unsure what selection to pick find the manufacturer’s Regular Production Option (RPO) Code list sticker on the vehicle, then find the corresponding code for the desired controller.
Page 99 ss02533 Current All System DTC Scan 2004 Volkswagon Raeding DTC’s from INSTRUMENTS (17) AUTO TRANSMISSION (02) 3 DTC(s) found ENGINE (01) 5 DTC(s) found AIRBAG (15) 3 DTC(s) found INSTRUMENTS (17) Reading DTCs ABS (03) SUSPENSION ELECTRONICS (14) STEERING WHEEL (16) ALL WHEEL DRIVE (22) 3.
Page 100 ss02536 Current All System DTC Scan 2004 Volkswagon Report ready for viewing. 100% CENTRAL CONVENIENCE (46) 3 DTC(s) found SOUND SYSTEM (47) 3 DTC(s) found XENON RANGE (55) 3 DTC(s) found RADIO (56) 3 DTC(s) found TV TUNER (57) 3 DTC(s) found AUX FUEL TANK (58) 3 DTC(s) found PARK ASSIST (76)
Page 101 Read DTCs Button Definitions Refresh DTCs Button Tapping the Refresh button initiates a fresh scan of DTCs from the vehicle. Share DTCs Button Tapping the Share button opens the app and initiates one of two options, share by email or Bluetooth email concontaining a list of all the DTCs set.
Page 102: Browser
BROWSER Overview An internet browser window is available for direct internet access. ss02538 2:59 Active Search Google for ... 1001 101001 CHECK 0101 Diagnostic Read DTCs Data Stream Special Tests Information Jeep 2007 Jeep Wangler All System DTC Unlimited Maintenance Tests Scan Browser Settings...
Page 103 ss02540 Video Search FastTouch Repair Inform.. IDENTIFI Fast Touch Websites FIND AND FIX FASTER TECH COMMUNITIES REPAIR INFORMATION autodata LOGIC MOTO 2. Select Repair Information brings up appropriate repair information web page. ss02541 Video Search FastTouch OEM Fast Touch Websites TECH COMMUNITIES REPAIR INFORMATION 3.
Page 104: Automated System Test
AUTOMATED SYSTEM TEST Overview The Automated System Test (AST) will scan all available controllers on the selected vehicle for Modes 1-7. Depending on the vehicle, the handset may ask qualifying questions concerning particular controller types for the vehicle being scanned. If unsure what selection to pick, find the manufacturer’s Regular Production Option (RPO) code list sticker on the vehicle, and then find the corresponding code for the desired controller.
Page 105 ss02544 Current Automated System Test 2007 Jeep Reading DTCs form CABIN COMP NODE ENGINE 9 DTC(s) found TRANSMISSION 9 DTC(s) found WIRELESS CTRL MODULE (TPMS) 9 DTC(s) found TIPM CENTRAL GATEWAY 9 DTC(s) found STEERING ANGLE 9 DTC(s) found CABIN COMP NODE Reading DTC’s RADIO OCCUPANT RESTRAINT CONTROL...
Page 106 Summary Report ss02547 Current Automated System Test Report 2007 Summary SUMMARY Jeep DTCs VIN: 1G6DM57N530102274 CONTROLLER: ENGINE CALIBRATION ID(S):BOSCHA1037366956, 4EF7033C DATA STREAM SNAPSHOT DTCs Found Data Items Freeze Frame Data (Mode 2) MODE 1 FREEZE FRAME Oxygen Sensor Tests (Mode 5) Non Continuously Monitored Tests (Mode 6) MODE 5 Passed...
Page 107 Data Stream Snapshot ss02549 Current Automated System Test Report 2007 SUMMARY Data Stream Snapshot Jeep DTCs Global OBDII DATA STREAM SNAPSHOT MODE 1 Engine Coolant Temperature Distance Since DTC Clear Fuel Rail Pressure Gauge FREEZE FRAME 31042 70.1 °F miles MODE 5 MODE 6 Distance MIL Active...
Page 108 Freeze Frame ss02551 Current Automated System Test Report 2007 SUMMARY Mode 2 Freeze Frames Jeep DTCs Freeze Frame 0 - P0123 DATA STREAM SNAPSHOT MODE 1 FREEZE FRAME MODE 5 MODE 6 1. Select a frame. ss02552 Current Automated System Test Report 2007 SUMMARY...
Page 109 Mode 5 (Oxygen sensor tests) Mode 5 views O2 sensor monitor test results. ss02553 Current Automated System Test Report 2007 SUMMARY Oxygen Sensor Tests (Mode 5) Jeep DTCs Description Value Units DATA STREAM SNAPSHOT Bank 1 Sensor 1 MODE 1 High Sensor Voltage For Switch Time Calculation 0.000 0.003...
Page 110 Automated System Test (AST) Button Definitions Refresh DTCs Button Tapping the Refresh button initiates a fresh scan of DTCs from the vehicle. Share DTCs Button Tapping the Share button opens the app and initiates one of two options, share by email or Bluetooth email containing a list of all the DTCs set.
Page 111: View Saved Tests
VIEW SAVED TESTS Overview The View Saved Tests functions allows the capability to recall previously run tests. ss02555 2:59 Active Search Google for ... 1001 101001 CHECK 0101 Diagnostic Read DTCs Data Stream Special Tests Information Jeep 2007 Jeep Wangler All System DTC Unlimited Maintenance Tests...
Page 112 ss02557 File picker storage emulated data com.bosch.mrst_launcher.control.fragment files reports dtcReport-20160314124713.html 14/03/2016 12:47 pm 2.94KB dtcReport-20160314124722.html 14/03/2016 12:47 pm 2.94KB dtcReport-20160314124806.html 14/03/2016 12:48 pm 2.94KB File name Pick file 3. Select Specfic file and hit Pick File. ss02558 Marvel’s Captain America... Webpage not available 192.19.253.11:8081/ma...
Page 113 800.MACTOOLS...
Page 114: View Data Stream Recordings
VIEW DATA STREAM RECORDINGS Overview The View Data Stream Recordings allows the capability to review previously recorded data. ss02559 2:59 Active Search Google for ... 1001 101001 CHECK 0101 Diagnostic Read DTCs Data Stream Special Tests Information Jeep 2007 Jeep Wangler All System DTC Unlimited...
Page 115 ss02561 Current Recorded Data Stream 1001 101001 0101 2003 Cadillac CTS Luxury Sport ENGINE Vehicle Speed Engine Coolant Mileage Since DTC Mileage Since MIL Temperature Cleared Request 40622 35592 miles miles °F 7855 41578 79187 30762 36191 39732 High High Intake Air Temperature Fuel Tank Pressure Calculated Converter...
Page 116: System Wiring Diagrams
SYSTEM WIRING DIAGRAMS Overview System Wiring Diagrams provides OEM specific, Full color, Full system diagrams. SS02594 2:59 Active Search Google for ... 1001 101001 CHECK 0101 Diagnostic Read DTCs Data Stream Special Tests Information NISSAN 2015 NISSAN TITAN All System DTC Maintenance Tests Browser Settings...
Page 117 ss02596 Fast Touch Websites -Wiring Diagrams - / 0 http://si0vmc1235.de.bosch.com/nawd-client/app/app/#/11aa3a9c-59bc-81d5-94d0-87fa7e39c396/circuitdiagrams/a1 Selected vehicle: Wiring Diagrams 2015 / Nissan / Titan / 5.6L (Naturally Aspirated) Wiring Diagrams Wiring diagram - Air Conditioning: Automatic A/C Circuit HOT AT HOT IN ON ALL TIMES OR START Page 1/2 FUSE...
Page 118: Customer Support
