3--5

DA101 Analog Output Modules

3--5--1 Dimensions
3--5--2 Wiring
Terminal Allocations
All dimensions given below are in millimeters.
Point Output
1 Voltage output
Current output
2 Voltage output
Current output
3 Voltage output
Current output
4 Voltage output
Current output
Not used.
Polarity Terminal
+ 0
-- 1
+ 2
-- 3
+ 4
-- 5
+ 6
-- 7
+ 8
-- 9
+ 10
-- 11
+ 12
-- 13
+ 14
-- 15
16
Section 3--5
