5--3--2 Four-word Operation
IR Allocations
Bit
IR 00
00
01
02
03
04
05
06 Writing data
07
08
09
10
11
12
13
14
15
DM Area Allocation
The following example is for four-word operation. We will be using the C500
in this example.
The following table shows the allocations of the IR words allocated to the
Analog Input Module.
During four-word operation, data is transferred between the Module and PLC
according to the settings of these control bits and flags.
Output
IR 01
Point 1 Control Bit
Point 2 Control Bit
Point 3 Control Bit
Point 4 Control Bit
Point 5 Control Bit
Point 6 Control Bit
Point 7 Control Bit
Point 8 Control Bit
Normal/Peak Control Bit
Not used.
Peak Reset Bit
A/D Conversion Bit
PC Write Completed Bit
PC Read Completed Bit
The following table shows the bits used to store the various data resulting
from the binary-converted analog input values.
Input point
1 DM 000
2 DM 001
3 DM 002
4 DM 003
5 DM 004
6 DM 005
7 DM 006
8 DM 007
Input
IR 02
Point 1 Read Flag
Point 2 Read Flag
Point 3 Read Flag
Point 4 Read Flag
Point 5 Read Flag
Point 6 Read Flag
Reading data Point 7 Read Flag
Point 8 Read Flag
Disconnection Flag
Normal/Peak Flag
Not used.
Not used.
A/D Read Completed Flag
A/D Write Completed Flag
Mean value Converted data
(sampling count) (normal)
0 0 0 0 DM 100
0 0 0 0 DM 101
0 0 0 0 DM 102
0 0 0 0 DM 103
0 0 0 5 DM 104
0 0 1 0 DM 105
0 0 2 0 DM 106
0 0 5 0 DM 107
Section 5--3
IR 03
Converted data
(peak value)
DM 200
DM 201
DM 202
DM 203
DM 204
DM 205
DM 206
DM 207
