APN Name
Modem Initial String2
Modem Dial String
Service Name
PPP Username
PPP Password
PPP Authentication
Index (1-15) in Schedule
Setup
WAN Connection
Detection
After finishing all the settings here, please click OK to activate them.
84
characters.
APN means Access Point Name which is provided and
required by some ISPs. Type the name and click Apply.
The maximum length of the name you can set is 43
characters.
The initial string 1 is shared with APN.
In some cases, user may need another initial AT command to
restrict 3G band or do any special settings.
The maximum length of the string you can set is 47
characters.
Such value is used to dial through USB mode. Please use the
default value. If you have any question, please contact to
your ISP.
The maximum length of the string you can set is 31
characters.
Enter the description of the specific network service.
Type the PPP username (optional). The maximum length of
the name you can set is 63 characters.
Type the PPP password (optional). The maximum length of
the password you can set is 62 characters.
Select PAP only or PAP or CHAP for PPP.
You can type in four sets of time schedule for your request.
All the schedules can be set previously in Application >>
Schedule web page and you can use the number that you
have set in that web page
Such function allows you to verify whether network
connection is alive or not through ARP Detect or Ping Detect.
Mode – Choose ARP Detect or Ping Detect for the system to
execute for WAN detection.
Ping IP – If you choose Ping Detect as detection mode, you
have to type IP address in this field for pinging.
TTL (Time to Live) –If you choose Ping Detect as detection
mode, you have to type a value for TTL.
