Draytek VIGORBX 2000 SERIES User Manual page 260

Extension Number
Display Name
Authentication
Password
Email Address
Voice mail Password
MWI (Message Waiting
Indication)
Allow to access these
Trunks
Default Trunk
MAC address for Auto
Provision
Answer Mode
248
available for general IP phone.
Type the number of extension for such index.
Type a name as a display for this extension profile.
Check this box to make the IP PBX executing authentication
while the number is dialed.
Use Display Name as authentication ID – Check this box to
use the Display Name as the authentication ID for such
extension profile.
Type a number for the IP PBX to execute authentication.
When an IP phone connects to network, IP PBX will use such
password for authentication.
Enable PPTP VPN Dial-In for this Number /Password -
Check this box to enable remote user can use this account
setting as PPTP remote dial-in authentication account.
Type an e-mail address to receive media (voice) file sent by
incoming calls.
Send a test email: Click this button to send a test e-mail to
the mail box you typed here.
Type a password here. When the user want to listen the
voice mail, he/she muse use such password to open it.
There are two types of MWI for users to choose. Please click
the one according to the real application.
Notify User who Subscribed - The user needs to send out
SUBSCRIBE message first. When IPPBX detects new voice
message from some extension number or the condition of
the voice message is changed, it will transfer "NOTIFY"
message to the users within the valid time subscribed.
Force Notify User- The user does not send out SUBSCRIBE
message automatically. The IPPBX will deliver "NOTIFY"
message to the users if there is a new message or the user
registers on IPPBX again.
There are several outside lines (SIP accounts) PSTN for you
to specify for such extension. Please check the one(s) you
want.
Use the drop down list to choose one of the interfaces as
the default trunk.
Type the MAC address to apply the settings of Auto
Provision.
Enable customer survey function – Check the box to
enable such function.
Specify the way to process incoming phone calls.
No answer after ..... – When the incoming phone call is not
picked up, it will be processed by keeping ringing, leaving
voice mail, forwarding to certain extension or group, or
forwarding a PSTN or mobile via SIP Trunk. Please specify
