Draytek VIGORBX 2000 SERIES User Manual page 750

palive
For Dial-Out Settings
ctype
dialto
ltype
oname
opwd
pauth
ovj
okey
ometh
sch
738
It means to enable PING to keep alive.
-1 – disable the function.
1,2,3,4 – Enable the function and PING IP 1.2.3.4 to keep alive.
It means "Type of Server I am calling".
"ctype=t" means PPTP.
"ctype=s" means IPSec.
"ctype= l" means L2TP(IPSec Policy None).
"ctype= l1" means L2TP(IPSec Policy Nice to Have).
"ctype= l2" means L2TP(IPSec Policy Must).
It means Server IP/Host Name for VPN. (such as draytek.com or
123.45.67.89).
It means Link Type.
"ltype=0" means "Disable".
"ltype=1" means "64kbps".
"ltype=2" means "128kbps".
"ltype=3" means "BOD".
It means Dial-Out Username.
"oname=admin" means to set Username = admin.
It means Dial-Out Password
"opwd=1234" means to set Password = 1234.
It means PPP Authentication.
"pauth=pc" means to set PPP Authentication = PAP&CHAP.
"pauth=p" means to set PPP Authentication = PAP Only
It means VJ Compression.
"ovj=on/off" means to enable/disable VJ Compression.
It means IKE Pre-Shared Key.
"okey=abcd" means to set IKE Pre-Shared Key = abcd.
It means IPSec Security Method.
"ometh=ah/" means AH.
"ometh=espd/espda/" means ESP DES without/with
Authentication.
"ometh=esp3/esp3a/" means ESP 3DES without/with
Authentication.
"ometh=espa/espaa" means ESP AES without/with Authentication.
It means Index(1-15) in Schedule Setup.
