For VigorBX 2000ac series, the web page will be shown as follows:
Info
Available settings are explained as follows:
Item
Enable
LAN
Wireless LAN (2.4GHz)
Wireless LAN (5GHz)
Subnet
134
Settings in this page only applied to LAN port but not WAN port.
Description
Click it to enable VLAN configuration.
P1 – P6 – Check the LAN port(s) to group them under the
selected VLAN.
SSID1 – SSID4 – Check the SSID boxes to group them under the
selected VLAN.
SSID1 – SSID4 – Check the SSID boxes to group them under the
selected VLAN.
Choose one of them to make the selected VLAN mapping to
the specified subnet only. For example, LAN1 is specified for
VLAN0. It means that PCs grouped under VLAN0 can get the
IP address(es) that specified by the subnet.
