Available settings are explained as follows:
Item
Enable Data Flow Monitor
Refresh Seconds
Refresh
Index
IP Address
TX rate (kbps)
RX rate (kbps)
Sessions
Action
Current /Peak/Speed
VigorBX 2000 Series User's Guide
Description
Check this box to enable this function.
Use the drop down list to choose the time interval of
refreshing data flow that will be done by the system
automatically.
Click this link to refresh this page manually.
Display the number of the data flow.
Display the IP address of the monitored device.
Display the transmission speed of the monitored device.
Display the receiving speed of the monitored device.
Display the session number that you specified in Limit
Session web page.
Block - can prevent specified PC accessing into Internet
within 5 minutes.
Unblock –The device with the IP address will be blocked for
five minutes. The remaining time will be shown on the
session column. Click it to cancel the IP address blocking.
Current means current transmission rate and receiving rate
for WAN interface.
Peak means the highest peak value detected by the router in
data transmission.
Speed means line speed specified in WAN>>General Setup.
If you do not specify any rate at that page, here will display
Auto for instead.
