Draytek VIGORBX 2000 SERIES User Manual page 178

Enable
Index
Profile
Domain Name
You can set up to 20 LAN DNS profiles.
To create a LAN DNS profile:
1. Click any index, say Index No. 1.
2. The detailed settings with index 1 are shown below.
Available settings are explained as follows:
Item
Enable
Profile
Domain Name
CNAME (Alias Domain
Name)
IP Address List
166
Check the box to enable the selected profile.
Click the number below Index to access into the setting
page.
Display the name of the LAN DNS profile.
Display the domain name of the LAN DNS profile.
Description
Check this box to enable such profile.
Type a name for such profile.
Note: If you type a name here for LAN DNS and click OK to
save the configuration, the name also will be applied to
conditional DNS forwarding automatically.
Type the domain name for such profile.
CNAME is abbreviation of Canonical name record.
Such option is used to record the domain name or the host
alias.
Add – Click it to add a new host with specified reference.
Delete – Click it to remove the setting.
The IP address listed here will be used for mapping with the
domain name specified above. In general, one domain name
maps with one IP address. If required, you can configure two
IP addresses mapping with the same domain name.
Add – Click it to open a dialog to type the host's IP address.
VigorBX 2000 Series User's Guide
