Figure 28: SAS cabling showing five storage enclosures below the head server
1 JBOD1
3 JBOD3
5 JBOD5
7 P1 connector on I/O module (SAS IN from
head unit or previous expansion shelf)
12. When the enclosure has completed its power-on sequence, check all enclosure status LEDs to ensure
that the enclosure is operating properly.
13. Power on the HPE StoreOnce 5100 System.
4
5
PS2
6
iLO
1 1 4
HPE StoreOnce 5100 System Capacity Upgrade expansion shelves
6
7
8
2 JBOD2
4 JBOD4
6 SAS connector on RAID controller on
head unit
8 P2 connector on I/O module (SAS OUT to
next expansion shelf)
