1.1 Important safety and product information

1.1.1 Important safety and product information
This Installation Guide is associated with ECL Application Key A368
(order code no. 087H3803).
The ECL Application Key A368 contains 6 subtypes, all applicable in
ECL Comfort 310:
• A368.1: Heating and DHW control. Pump for refill water control
• A368.2: Heating and DHW control. Supply temperature can
determine desired flow temperature. Pump for refill water
control
• A368.3: Heating and DHW control and 2 pumps for refill water
control. Pressure monitoring
• A368.4: Heating and DHW control and 2 pumps for refill water
control. Supply temperature can determine desired flow
temperature. Pressure monitoring
• A368.5: Heating and DHW control. 2 pumps and flow meter
for refill water control. Pressure and secondary temperature
monitoring
• A368.6: Heating and DHW control. Pump for refill water control.
Secondary temperature monitoring
See the Mounting Guide (delivered with the application key) for
application examples and electrical connections.
The described functions are realized in ECL Comfort 310 for
advanced solutions, e.g. M-bus, Modbus and Ethernet (Internet)
communication.
The Application Key A368 complies with ECL Comfort 310
controllers as of software version 1.11 (visible at start-up of the
controller and in 'Common controller settings' in 'System').
The applications A368.3, A368.4 and A368.5 work with the Internal
I/O module ECA 32 (order code no. 087H3202).
ECA 32 is placed in the base part for ECL Comfort 310.
Up to two Remote Control Units, ECA 30 or ECA 31, can be
connected for remote monitoring and setting.
ECL Comfort 310 is available as:
• ECL Comfort 310, 230 volt a.c. (087H3040)
• ECL Comfort 310B, 230 volt a.c. (087H3050)
• ECL Comfort 310, 24 volt a.c. (087H3044)
The base part for ECL Comfort 310, 230 volt and 24 volt:
• 087H3230
The B-types have no display and dial.
The B-types are operated by means of the remote control unit
ECA 30 / 31:
• ECA 30 (087H3200)
• ECA 31 (087H3201)
Additional documentation for ECL Comfort 310, modules and
accessories is available on http://heating.danfoss.com/.
