Operating Guide
ECL Comfort 210, 296 and 310, return temperature
limitation
1.0 Table of Contents
1.0 Table of Contents ............................................. 1
1.1
Important safety and product information. . . . . . . . . . . . . . . . . . . . 2
2.0 Settings........................................................... 5
2.1
system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.0 Miscellaneous .................................................. 7
3.1
Several controllers in the same system . . . . . . . . . . . . . . . . . . . . . . . . 7
© Danfoss | 2017.08
VI.GU.W2.02 | 1
Advertisement
Related Manuals for Danfoss ECL Comfort 210
Summary of Contents for Danfoss ECL Comfort 210
-
Page 1: Table Of Contents
Operating Guide ECL Comfort 210, 296 and 310, return temperature limitation 1.0 Table of Contents 1.0 Table of Contents ..........1 Important safety and product information....2 2.0 Settings............ -
Page 2: Important Safety And Product Information
/ slave system. The return temperature limitation functionality can be realized with ECL Comfort 210, ECL Comfort 296 and ECL Comfort 310. For information on general functions please consult the installation guide for the application key in question. - Page 3 ECL Comfort 210, 296 and 310, return temperature limitation Automatic update of controller software (firmware): The software of the controller is updated automatically when the key is inserted (as of controller version 1.11 (ECL 210 / 310) and version 1.58 (ECL 296)). The following animation will be shown when the...
- Page 4 ECL Comfort 210, 296 and 310, return temperature limitation Disposal Note This product should be dismantled and its components sorted, if possible, in various groups before recycling or disposal. Always follow the local disposal regulations. VI.GU.W2.02 4 | © Danfoss | 2017.08...
-
Page 5: Settings
ECL Comfort 210, 296 and 310, return temperature limitation 2.0 Settings 2.1 Return temperature limitation in a master / slave system The circuit 1 menu for return temperature limit parameters contains an additional parameter "DHW, ret. T limit" (= Domestic Hot Water, return temperature limit). - Page 6 ECL Comfort 210, 296 and 310, return temperature limitation MENU > Settings > Return temperature limitation in a master / slave system Temp. Setting in ‘Demand offset’ 11017 Demand offset Circuit Setting range Factory setting OFF / 1 ... 20 K Des.
-
Page 7: Miscellaneous
ECL Comfort 210, 296 and 310, return temperature limitation 3.0 Miscellaneous 3.1 Several controllers in the same system When ECL Comfort controllers are interconnected by means of the ECL 485 communication bus (cable type: 2 x twisted pair), the master controller will broadcast the following signals to the slave controllers: •... - Page 8 ECL Comfort 210, 296 and 310, return temperature limitation Situation 2: SLAVE controller: How to react on a DHW tank heating / charging activity sent from the MASTER controller The slave receives information about a DHW tank heating / charging activity in the master controller and can be set to close the selected heating circuit.
- Page 9 ECL Comfort 210, 296 and 310, return temperature limitation Situation 3: SLAVE controller: How to make use of the outdoor temperature signal and send information about the desired flow In the MASTER controller, the address in ‘ECL 485 addr. (master / slave temperature back to the MASTER controller address)’...
