Quick Guide

1.8 General Technical Data

Protection and features
•
Electronic thermal motor protection motor protection against overload.
•
Temperature monitoring of the heatsink ensures that the adjustable frequency drive trips in case of overtem-
perature.
•
The adjustable frequency drive is protected against short-circuits between motor terminals U, V, W.
•
If a motor phase is missing, the adjustable frequency drive trips and issues an alarm.
•
If a line phase is missing, the adjustable frequency drive trips or issues a warning (depending on the load).
•
Monitoring of the intermediate circuit voltage ensures that the adjustable frequency drive trips if the intermediate
circuit voltage is too low or too high.
•
The adjustable frequency drive is protected against ground faults on motor terminals U, V, W.
Line power supply (L1/L, L2, L3/N)
Supply voltage
Supply voltage
Supply frequency
Max. temporary imbalance between line phases
True Power Factor
Displacement Power Factor (cosφ) near unity
Switching on input supply L1/L, L2, L3/N (power-ups)
Environment according to EN60664-1
The unit is suitable for use on a circuit capable of delivering not more than 100,000 RMS symmetrical Amperes, 240/480 V
maximum.
Motor output (U, V, W)
Output voltage
Output frequency
Switching on output
Ramp times
Cable lengths and cross-sections:
Max. motor cable length, shielded/armored (EMC-compliant installation)
Max. motor cable length, unshielded/unarmored
Max. cross-section to motor, line power*
Connection to load sharing/brake (M1, M2, M3)
Max. cross-section to load sharing/brake (M4, M5)
Maximum cross-section to control terminals, rigid wire
Maximum cross-section to control terminals, flexible cable
Maximum cross-section to control terminals, cable with enclosed core
Minimum cross-section to control terminals
* See tables for line power supply for more information!
Digital Inputs (Pulse/Enocder Inputs):
Programmable digital inputs (pulse/encoder)
Terminal number
Logic
Voltage level
Voltage level, logic'0' PNP
Voltage level, logic'1' PNP
Voltage level, logic '0' NPN
Voltage level, logic '1' NPN
Maximum voltage on input
®
VLT Micro Drive Quick Guide
®
MG02B722 - VLT is a registered Danfoss trademark
200–240 V ±10%
380–480 V ±10%
3.0% of rated supply voltage
≥0.4 nominal at rated load
maximum 2 times/min.
overvoltage category III/pollution degree 2
0–100% of supply voltage
plus
0–200 Hz (VVC ), 0–400 Hz (u/f)
0.25 in [6.3 mm] insulated Faston plugs
16mm
1.5mm 2 /16 AWG (2 x 0.75mm
1mm
0.5mm
18, 19, 27, 29, 33,
1 1
50/60 Hz
(>0.98)
Unlimited
0.05–3,600 s
50 ft [15 m]
164 ft [50 m]
2
/6AWG
2 )
2 /18 AWG
2
/20AWG
2
0.25mm
5 (1)
PNP or NPN
0–24V DC
< 5V DC
> 10V DC
> 19V DC
< 14V DC
28V DC
1-19
