Danfoss VLT Micro Drive Quick Manual page 17

Quick Guide
1 1
16-6* Inputs/Outputs
16-60 Digital Input 18,19,27,33
0–1111
16-61 Digital Input 29
0–1
16-62 Analog Input 53 (volt)
16-63 Analog Input 53 (current)
16-64 Analog Input 60
Table 1.11
1.6 Troubleshooting
No Description
.
2 Live zero error
4
Mains phase loss
7 DC overvoltage1)
8 DC undervoltage1)
9 Inverter overloaded
10 Motor ETR overtemperature
11 Motor thermistor overtem-
perature
12 Torque limit
13 Overcurrent
14 Earth fault
16 Short-circuit
17 Control word timeout
25 Brake resistor short-circuited
27 Brake chopper short-circuited
28 Brake check
29 Power board overtemp
30 Motor phase U missing
31 Motor phase V missing
32 Motor phase W missing
38 Internal fault
44 Earth fault
47 Control Voltage Fault
51 AMT check U
52 AMT low I
nom
2.3 Current limit
2
[59]
63 Mechanical Brake Low
80 Drive Initialized to Default Value
84 The connection between drive
and LCP is lost
85 Button disabled
86 Copy fail
87 LCP data invalid
88 LCP data not compatible
89 Parameter read-only
3.5 Parameter database busy
4
[90]
91 Parameter value is not valid in
this mode
1-14
VLT
16-65 Analog Output 42 [mA]
16-68 Pulse Input [Hz]
16-71 Relay Output [bin]
16-72 Counter A
16-73 Counter B
16-8* Ser. Com Bus/FC Port
16-86 FC Port REF 1
Warning
X
X
1)
X
X
X
X
X
X
X
X
X
X
and I
nom nom
X
MG02B722 - VLT
®
Micro Drive Quick Guide
0x8000–0x7FFFF
16-9* Diagnosis Readouts
16-90 Alarm Word
0–0XFFFFFFFF
16-92 Warning Word
0–0XFFFFFFFF
16-94 Ext. Status Word
0–0XFFFFFFFF
Alarm Trip Error Cause of Problem
Lock
X Signal on terminal 53 or 60 is less than 50% of value set in
6-10 Terminal 53 Low Voltage, 6-12 Terminal 53 Low Currentand
6-22 Terminal 54 Low Current.
X X Missing phase on the supply side, or a voltage imbalance that is
too high. Check supply voltage.
X Intermediate circuit voltage exceeds the limit.
X Intermediate circuit voltage drops below the "voltage warning
low" limit.
X More than 100% load for too long.
X Motor is too hot due to more than 100% load for too long.
X The thermistor or the thermistor connection is disconnected.
Torque exceeds the value set in either par. 4-16 or 4-17.
X X Inverter peak current limit is exceeded.
X X Discharge from output phases to ground.
X X Short-circuit in the motor or on the motor terminals.
X No communication to the adjustable frequency drive.
X X Brake resistor is short-circuited, thus the brake function is
disconnected.
X X Brake transistor is short-circuited, thus the brake function is
disconnected.
X Brake resistor is not connected/working
X X Heatsink cut-out temperature has been reached.
X X Motor phase U is missing. Check the phase.
X X Motor phase V is missing. Check the phase.
X X Motor phase W is missing. Check the phase.
X X Contact local Danfoss supplier.
X X Discharge from output phases to ground.
X X 24 V DC may be overloaded.
X Wrong setting for motor voltage and/or motor current.
X Motor current is too low. Check settings.
VLT overload.
X Actual motor current has not exceeded the "release brake"
current in the "start delay" time window.
X All parameter settings are initialized to default settings.
X No communication between LCP and adjustable frequency drive
X See parameter group 0-4* LCP
X An error occurred while copying from adjustable frequency drive
to LCP or vice versa.
X Occurs when copying from LCP if the LCP contains erroneous
data - or if no data was uploaded to the LCP.
X Occurs when copying from LCP if data are moved between
adjustable frequency drives with major differences in software
versions.
X Occurs when trying to write to a read-only parameter.
X LCP and RS485 connection are trying to update parameters
simultaneously.
X Occurs when trying to write an illegal value to a parameter.
®
is a registered Danfoss trademark
18-** Extended Motor Data
18-8* Motor Resistors
18-80 Stator Resistance (High
resolution)
0.000–99.990 ohm * 0.000 ohm
18-81 Stator Leakage Reactance
(High resolution)
0.000–99.990 ohm * 0.000 ohm
