Protect users against supply voltage.
•
Protect the motor against overloading according
to national and local regulations.
•
The ground leakage current exceeds 3.5 mA.
•
The [Off/Reset] key is not a safety switch. It does
not disconnect the adjustable frequency drive
from line power.
1.2 Introduction
1.2.1 Available Literature
NOTE!
This Quick Guide contains the basic information necessary
for installing and running the adjustable frequency drive.
If more information is needed, the literature below can be
downloaded from:
http: //www.danfoss.com/BusinessAreas/DrivesSolutions/
Documentations
VLT Micro Drive FC 51 Design Guide
VLT Micro Drive FC 51 Quick Guide
VLT Micro Drive FC 51 Programming Guide
FC 51 LCP Mounting Instruction
FC 51 De-coupling Plate Mounting Instruction
FC 51 Remote Mounting Kit Mounting Instruction
FC 51 DIN Rail Kit Mounting Instruction
FC 51 IP21 Kit Mounting Instruction
FC 51 Nema1 Kit Mounting Instruction
Line Filter MCC 107 Installation Instruction
Table 1.1
1.2.2 Approvals
Table 1.2
1-2
®
VLT
Micro Drive Quick Guide
Title
Literature
MG02K
MG02B
MG02C
MI02A
MI02B
MI02C
MI02D
MI02E
MI02F
MI02U
MG02B722 - VLT
1.2.3 IT Line Power
NOTE!
IT Line Power
Installation on an isolated line power source, i.e., IT line
power.
Max. supply voltage allowed when connected to line
power: 440 V.
As an option, Danfoss offers recommended line filters for
improved harmonics performance.
