Datalogic TC1100 Reference Manual

Hide thumbs Also See for TC1100:
Table of Contents

Advertisement

Quick Links

TC1100
Installation Manual

Advertisement

Table of Contents
loading

Related Manuals for Datalogic TC1100

Summary of Contents for Datalogic TC1100

  • Page 1 TC1100 Installation Manual...
  • Page 3 TC1100 REFERENCE MANUAL...
  • Page 4 ALL RIGHTS RESERVED Datalogic reserves the right to make modifications and improvements without prior notification. Datalogic shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from the use of this material.

  • Page 5: Table Of Contents

    RS232 Interface .................... 6 WEDGE Interface ..................6 PEN Emulation Interface................7 Inputs ......................7 Outputs ......................8 External Beeper Connection ................. 9 TC1100 CCD Scan Engine ................. 10 2.2.1 Mechanical Installation................10 2.2.2 Electrical Connections................. 11 RS232 Interface ..................12 WEDGE Interface ..................
  • Page 6 Parity......................42 Data Bits ..................... 42 Stop Bits...................... 43 Handshaking ....................43 ACK/NACK Protocol..................44 FIFO......................44 Inter-Character Delay.................. 45 Rx Timeout....................45 WEDGE PARAMETERS ................46 Keyboard Nationality................... 47 Caps Lock ....................48 Num Lock....................48 Inter-Character Delay.................. 49 Inter-Code Delay..................
  • Page 7 Beeper Tone ....................76 Beeper Type ....................77 Beeper Length .................... 77 PDF Decoding Recognition Intensity ............77 DECODING PARAMETERS............... 78 Ink-Spread ....................79 Overflow Control ..................79 Interdigit Control..................80 Decoding Safety..................80 Puzzle Solver™ ..................81 CODE SELECTION ..................82 EAN/UPC Family ..................
  • Page 8 5.4.2 Enter Sleep Timeout ................. 110 5.4.3 Standby..................... 110 Reading Parameters ................. 110 5.5.1 Operating Modes ..................110 5.5.2 Reads per Cycle ..................112 Decoding Parameters ................112 5.6.1 Ink-Spread ....................112 5.6.2 Overflow Control ..................113 5.6.3 Interdigit Control..................113 Configuration Editing COmmands.............

  • Page 9: Introduction

    Configuration for Wedge Interface Users For Wedge Interface Users, configuration can be accomplished either by reading the barcode labels available in this manual with the TC1100 (see chapter 4 ) or by reading the Return to RS232 Interface barcode and then configuring through the RS232 Interface.

  • Page 10: Status Indicators

    5. STATUS INDICATORS The reader has two LED indicators signaling several operating conditions which are described in the tables below. Led2 Led1 TC1100 Scan Engine TC1100 Scanner POWER UP POWER ON / LED2 Meaning Power supply ON Power supply OFF...

  • Page 11: Available Models

    INTRODUCTION AVAILABLE MODELS The TC1100 reader is available in models that differ in regard to the following characteristics: • Barcode type • Enclosure The following models are therefore available: • TC1100-0100 = CCD Scan Engine for linear codes • TC1100-0200 = CCD Scan Engine for linear and PDF417 codes •...

  • Page 12: Installation

    TC1100 INSTALLATION TC1100 CCD SCANNER 2.1.1 Mechanical Installation The diagram below gives the overall dimensions of the reader and may be used for its installation. 68.6 [0.94] [2.70] 31.6 10.4 [0.41] [1.25] [in.] Optical Axis Figure 1 - Overall Dimensions...

  • Page 13: Electrical Connections

    INSTALLATION 2.1.2 Electrical Connections The TC1100 Scanner is equipped with a 25-pin female D-Sub connector for connection to the power supply and input/output signals. The details of the connector pins are indicated in the following table: Figure 2 - 25-pin Female D-sub Connector...

  • Page 14: Rs232 Interface

    TC1100 RS232 Interface The TC1100 Scanner can communicate with the Host using the RS232 signals provided on the 25-pin connector. The pins are indicated in Table 1 and in the following diagram: It is always advisable to use shielded cables. The overall maximum cable length must be less than 15 m (49.2 ft).

  • Page 15: Pen Emulation Interface

    It is always advisable to use shielded cables. Inputs There is an input available on the TC1100 Scanner relative to the External Trigger. The pins are indicated in Table 1. These inputs are optocoupled and can be driven by both an NPN or PNP type command. The connections are indicated in the...

  • Page 16: Outputs

    Figure 9 - Input PNP Command Using TC1100 Power Outputs There is an output available on the TC1100 Scanner relative to the Good Read event. The pins are indicated in Table 1. The connections are indicated in the following diagram:...

  • Page 17: External Beeper Connection

    BZ1 (see below) R2 (10K) BEEPER (pin 8) Q1 (BC337) R1 (1K) GND (pin 25) Figure 11 - TC1100 Scanner Beeper Connection The following list indicates several piezoelectric buzzers that can be used in the circuitry above (part BZ1). Manufacturer Type MURATA...

  • Page 18: Tc1100 Ccd Scan Engine

    TC1100 TC1100 CCD SCAN ENGINE 2.2.1 Mechanical Installation The diagram below gives the overall dimensions of the TC1100 Scan Engine and may be used for its installation. [2.48] Veritcal Optical Axis 25.7 [1.01] 12.2 [0.48] [2.48] 40.5 [1.59] [0.10] Ø2.7 [Ø0.11] n°4...

  • Page 19: Electrical Connections

    INSTALLATION 2.2.2 Electrical Connections The TC1100 Scan Engine is equipped with two 8-pin DF13 connectors for connection to the power supply and input/output signals. The details of the connector pins are indicated in the following table: Figure 13 - 8-pin Connectors...

  • Page 20: Rs232 Interface

    TC1100 RS232 Interface The TC1100 Scan Engine can communicate with the Host using the RS232 signals provided on the J1 connector. The pins are indicated in Table 1 and in the following diagram: It is always advisable to use shielded cables. The overall maximum cable length must be less than 15 m (49.2 ft).

  • Page 21: Pen Emulation Interface

    Figure 16 – Pen Emulation Interface Connection to Host Inputs There is an input available on the TC1100 Scan Engine relative to the External Trigger. The pins are indicated in Table 2. These inputs are optocoupled and can be driven by both an NPN or PNP type command. The connections are indicated in the...

  • Page 22: Outputs

    Figure 20 - Input PNP Command Using TC1100 Power Outputs There is an output available on the TC1100 Scan Engine relative to the Good Read event. The pins are indicated in Table 2. The connections are indicated in the following diagram:...

  • Page 23: External Beeper Connection

    R2 (10K) BEEPER (J1 pin 4) Q1 (BC337) R1 (1K) GND (J2 pin 2) Figure 22 - TC1100 Scan Engine Beeper Connection The following list indicates several piezoelectric buzzers that can be used in the circuitry above (part BZ1). Manufacturer Type...

  • Page 24: Positioning

    TC1100 POSITIONING The TC1100 scanner is able to decode barcode labels at a variety of angles, however significant angular distortion may degrade reading performance. When mounting the TC1100 take into consideration these three ideal label position angles: Pitch 0°, Skew 10° to 30° and Tilt 0°. Follow the suggestions for the best orientation: The Pitch angle is represented by the value P in Figure 23.

  • Page 25: Gfc-Tc1100 Accessory

    Tilt angle. Figure 25 - Tilt angle GFC-TC1100 ACCESSORY The GFC-TC1100 is an 80° deflection mirror that is mounted directly to the TC1100 Scanner or Scan Engine. Figure 26 - GFC-TC1100 The overall dimensions are provided in the figure below and can be used for its...
  • Page 26 [3.33] Figure 27 - GFC-TC1100 Overall Dimensions To fix a TC1100-1xx Scanner to the GFC-TC1100, use the 4 M 2.5x5 mm screws supplied with the GFC Kit. Refer to the figure below. Figure 28 – Fixing TC1100 Scanner to GFC-TC1100...
  • Page 27 INSTALLATION To fix a TC1100-0xxx Scan Engine to the GFC-TC1100, use the 4 M 2.5x10 mm screws together with the 4 plastic spacers and nuts supplied with the GFC Kit. Refer to the figure below. Figure 29 – Fixing TC1100 Scan Engine to GFC-TC1100 The 80°...

  • Page 28: Software Configuration Strings

    TC1100 SOFTWARE CONFIGURATION STRINGS DEFAULT CONFIGURATION RS232 INTERFACE 9600 baud, parity disabled, 8 data bits, 1 stop bit, handshaking disabled, ACK/NACK from Host disabled, 100 ms RX timeout, FIFO enabled, inter-character delay disabled WEDGE INTERFACE USA keyboard, caps lock off, delays disabled, control character emulation = ctrl+shift+key;...
  • Page 29 Check digit not transmitted, variable length code; 1-99 characters • PDF417 (TC1100-x200 only) disabled codes EAN 128, ISBT128,Code 93, Codabar, pharmaceutical codes, Delta IBM, Code 16K, Code 49, (MSI/Plessey, Telepen, Pharmacode only TC1100-x100), (Codablock-A, Codablock-F Standard and EAN only TC1100-x200)

  • Page 30: Tc1100 Configuration

    TC1100 TC1100 CONFIGURATION TC1100 is factory set for RS232 Interface applications. The easiest way to configure TC1100 is by using the DL Sm@rtSet™ utility program installed from the CD included with this manual. Otherwise you can configure the scanner using the serial...

  • Page 31: Command Syntax

    SOFTWARE CONFIGURATION STRINGS Command Syntax The command syntax is given below with an example: Command(s) <CR> The new setting will be definitive (stored in FLASH EPROM) Example: Multiple command programming sequence: AC410132 Carriage return character (0D Hex.) Exit and save new configuration Matrix 2/5 3 bars: no check digit, variable length code from 1 to 32 characters Baud rate = 19200...
  • Page 32 TC1100 SERIAL CONFIGURATION STRINGS ENTER/EXIT CONFIGURATION COMMANDS DESCRIPTION STRING Enter Configuration Exit and Save Configuration $+$*<CR> Restore Default $+$!<CR> Transmit Software Release (not for PEN emulation) Get Configuration from Reader (not for PEN emulation) $+$&<CR> These commands do not require $-.
  • Page 33 SOFTWARE CONFIGURATION STRINGS RS232 DESCRIPTION STRING Baud rate 1200 2400 4800 9600 19200 38400 Parity none even Data bits Stop bits Handshaking disable RTS/CTS XON/XOFF RTS always On ACK/NACK Protocol disable enable FIFO disable enable Inter-character delay (ms) CK00 - CK99 RX Timeout (100 ms) CL00 - CL99 WEDGE...
  • Page 34 TC1100 WEDGE (continued) DESCRIPTION STRING Caps Lock caps Lock ON caps Lock OFF Num Lock Toggle Num Lock Num Lock Unchanged CK00 - CK99 Delays Inter-Character (ms) FG00 - FG99 Inter-Code (s) Control Character Emulation Ctrl + Shift + Key...
  • Page 35 = ASCII character. b, c, x = HEX values representing an ASCII character. a = ASCII character of the DATALOGIC STANDARD Code Identifier from the table on page 60. b = Hex value of the first Custom Code Identifier character from 00 to FE ;...
  • Page 36 = a number from the Hex/Numeric Table e, f, g = HEX values representing an ASCII character a = ASCII character of the DATALOGIC STANDARD Code Identifier from the table on page 60. d = a number in the range 01-32 from the Hex/Numeric Table...
  • Page 37 SOFTWARE CONFIGURATION STRINGS READING PARAMETERS DESCRIPTION STRING Operating Modes serial on-line on-line See par. 5.5.1 for details automatic automatic/lighting system standby Test Mode disable #+DStat0<CR> enable #+DStat1<CR> Beeper Intensity very low intensity low intensity medium intensity high intensity Beeper Tone Tone 1 Tone 2 Tone 3...
  • Page 38 TC1100 CODE SELECTION (continued) DESCRIPTION STRING EAN 8/EAN 13 without ADD ON with ADD ON 2 ONLY with ADD ON 5 ONLY with ADD ON 2 AND 5 UPC A/UPC E without ADD ON with ADD ON 2 ONLY with ADD ON 5 ONLY...
  • Page 39 SOFTWARE CONFIGURATION STRINGS CODE SELECTION (continued) DESCRIPTION STRING disable Code 2/5 family AC11 xxxx Interleaved 2/5 no check digit control AC12 xxxx check digit control and transmission AC13 xxxx check digit control without transmission Normal 2/5 5 bars no check digit control AC21 xxxx AC22 xxxx check digit control and transmission...
  • Page 40 ISBT 128 enable ISBT 128 Code 93 disable Code 93 family enable Code 93 control without transmission of check digit Codablock-A disable (TC1100-x200 only) enable Codablock-F disable the family (TC1100-x200 only) enable Standard enable EAN disable the family (TC1100-x100 only)
  • Page 41 Type 1 check Type 2 check Code 16K disable enable Code 49 disable enable PDF417 disable (TC1100-x200 only) enable Pharmacode disable (TC1100-x100 only) forward code TX direction AQ1xxyy reverse code TX direction AQ2xxyy overflow ratio AQAzz xx = ASCII numbers that define the minimum acceptable code length;...

  • Page 42: Barcode Configuration

    The Barcode Configuration is suggested only when using the WEDGE or PEN Emulation interface. CAUTION INITIAL SETUP The following procedure allows preparing your TC1100 to read barcodes by using the default settings. RESTORE DEFAULT Read the restore default parameters code below.
  • Page 43 BARCODE CONFIGURATION WEDGE IBM AT or PS/2 PCs IBM XT PC Notebook IBM SURE1 IBM Terminal 3153...
  • Page 44 TC1100 WEDGE (continued) IBM Terminals 31xx, 32xx, 34xx, 37xx: To select the interface for these IBM Terminals, read the correct KEY TRANSMISSION code. Select the KEYBOARD TYPE if necessary (default = advanced keyboard). KEY TRANSMISSION MODE make-only keyboard make-break keyboard...
  • Page 45 BARCODE CONFIGURATION WEDGE (continued) ALT MODE The ALT-mode selection allows barcodes sent to the PC to be interpreted correctly independently from the Keyboard Nationality used. You do not need to make a Keyboard Nationality selection. (default = Num Lock Unchanged). Make sure the Num Lock key on your keyboard is ON.
  • Page 46 TC1100 WEDGE (continued) DIGITAL TERMINALS VT2xx/VT3xx/VT4xx APPLE APPLE ADB Bus YOUR READER IS NOW READY TO READ BARCODES. To change the default settings see par. 4.2.

  • Page 47: Changing Default Settings

    BARCODE CONFIGURATION CHANGING DEFAULT SETTINGS Once your reader is setup, you can change the default parameters to meet your application needs. Refer to the preceding paragraph for initial configuration in order to set the default values and select the interface for your application. In this manual, the configuration parameters are divided into logical groups making it easy to find the desired function based on its reference group.

  • Page 48: Rs232 Parameters

    RS232 PARAMETERS ARITY ANDSHAKING ACK/NACK P ROTOCOL FIFO NTER HARACTER ELAY IMEOUT Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE, available at the top of each page.

  • Page 49: Baud Rate

    Enter configuration Exit and Save Configuration RS232 150 baud 300 baud 600 baud 1200 baud 2400 baud 4800 baud 9600 baud 19200 baud 38400 baud...

  • Page 50: Parity

    Enter configuration Exit and Save Configuration RS232 ARITY none even parity odd parity 7 bits 8 bits 9 bits...

  • Page 51: Stop Bits

    Enter configuration Exit and Save Configuration RS232 1 stop bit 2 stop bits ANDSHAKING disable hardware (RTS/CTS) software (XON/XOFF) RTS always ON See par. 5.1.1 for details.

  • Page 52: Ack/Nack Protocol

    Enter configuration Exit and Save Configuration RS232 ACK/NACK P ROTOCOL disable enable See par. 5.1.2 for details. FIFO disable enable See par. 5.1.3 for details.

  • Page 53: Inter-Character Delay

    Enter configuration Exit and Save Configuration RS232 NTER HARACTER ELAY delay between characters transmitted to Host Read 2 numbers from the table where : 00 = DELAY disabled 01-99 = DELAY from 1 to 99 milliseconds delay disabled IMEOUT timeout control in reception from Host Read 2 numbers from the table where: 00 = TIMEOUT disabled 01-99 = TIMEOUT from .1 to 9.9 seconds...

  • Page 54: Wedge Parameters

    WEDGE PARAMETERS EYBOARD ATIONALITY NTER HARACTER ELAY NTER ELAY EYBOARD ETTING ONTROL HARACTER MULATION Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE, available at the top of each page.

  • Page 55: Keyboard Nationality

    Enter configuration Exit and Save Configuration WEDGE EYBOARD ATIONALITY Belgian English French German Italian Spanish Swedish...

  • Page 56: Caps Lock

    Enter configuration Exit and Save Configuration WEDGE caps lock OFF caps lock ON Select the appropriate code to match your keyboard caps lock status. Note: For IBM AT and PC Notebook interface selections, the caps lock status is automatically recognized, therefore this command is not necessary. toggle num lock num lock unchanged This selection is used together with the Alt Mode interface selection for AT or Notebook PCs.

  • Page 57: Inter-Character Delay

    Enter configuration Exit and Save Configuration WEDGE NTER HARACTER ELAY delay between characters transmitted to Host Read 2 numbers from the table where : 00 = DELAY disabled DELAY from 1 to 99 milliseconds 01-99 = delay disabled NTER ELAY delay between codes transmitted to Host Read 2 numbers from the table where: 00 =...

  • Page 58: Keyboard Setting

    Enter configuration Exit and Save Configuration WEDGE EYBOARD ETTING ALPHANUMERIC KEYBOARD SETTING The reader can be used with terminals or PCs with various keyboard types and nationalities through a simple keyboard setting procedure. The type of computer or terminal must be selected before activating the keyboard setting command.
  • Page 59 WEDGE 01 : Shift 02 : Alt 03 : Ctrl 04 : Backspace 05 : SPACE 28 : 7 51 : N 06 : ! 29 : 8 52 : O 07 : " 30 : 9 53 : P 08 : # 31 : : 54 : Q...

  • Page 60: Control Character Emulation

    Enter configuration Exit and Save Configuration WEDGE ONTROL HARACTER MULATION Ctrl + Shift + Key Ctrl + Key...

  • Page 61: Pen Emulation

    PEN EMULATION PERATING INIMUM UTPUT ULSE ONVERSION TO VERFLOW UTPUT EVEL EVEL NTER LOCK ELAY Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE, available at the top of each page.

  • Page 62: Operating Mode

    PEN EMULATION The operating mode parameters are complete commands and do not require reading the Enter and Exit configuration codes. PERATING interpret mode Interprets commands without sending them to the decoder. transparent mode Sends commands to the decoder without interpreting them.

  • Page 63: Minimum Output Pulse

    Enter configuration Exit and Save Configuration PEN EMULATION INIMUM UTPUT ULSE high resolution code emulation 200 µs 400 µs 600 µs 800 µs 1 ms 1.2 ms low resolution code emulation See par. 5.2.1 for details.

  • Page 64: Conversion To Code 39

    Enter configuration Exit and Save Configuration PEN EMULATION ONVERSION disable conversion to Code 39 Transmits codes in their original format. enable conversion to Code 39 Converts codes read into Code 39 format.

  • Page 65: Overflow

    Enter configuration Exit and Save Configuration PEN EMULATION VERFLOW narrow medium wide See par. 5.2.2 for details. UTPUT EVEL normal (white = logic level 0) inverted (white = logic level 1) See par. 5.2.3 for details.

  • Page 66: Idle Level

    Enter configuration Exit and Save Configuration PEN EMULATION EVEL normal (black level) inverted (white level) See par. 5.2.3 for details. NTER LOCK ELAY delay between character blocks transmitted to Host Read 2 numbers from the table where : 00 = DELAY disabled 01-99 = DELAY from .1 to 9.9 seconds delay disabled...

  • Page 67: Data Format

    DATA FORMAT NOT FOR PEN INTERFACES DENTIFIER USTOM DENTIFIER EADER ERMINATOR IELD DJUSTMENT IELD HARACTER ENGTH HARACTER EPLACEMENT HARACTER Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE, available at the top of each page.
  • Page 68 DATA FORMAT CODE IDENTIFIER TABLE CODE AIM STANDARD DATALOGIC STANDARD Custom 2/5 interleaved ] I y 2/5 industrial ] X y 2/5 normal 5 bars ] S y 2/5 matrix 3 bars ] X y EAN 8 ] E 4...
  • Page 69 (check digit tested or not, check digit tx or not, etc.). • When customizing the Datalogic Standard code identifiers, 1 or 2 identifier characters can be defined for each code type. If only 1 identifier character is required, the second character must be selected as FF (disabled).

  • Page 70: Code Identifier

    Enter configuration Exit and Save Configuration DATA FORMAT DENTIFIER disable Datalogic standard AIM standard custom...

  • Page 71: Custom Code Identifier

    DENTIFIER define custom code identifier(s) Read the above code. (Code Identifiers default to Datalogic standard, see table on previous page). Select the code type from the code table in Appendix A for the identifier you want to change. You can define 1 or 2 identifier characters for each code type. If only 1 identifier character is required, the second character must be selected as FF (disabled).

  • Page 72: Header

    Enter configuration Exit and Save Configuration DATA FORMAT EADER no header one character header two character header three character header four character header five character header six character header seven character header eight character header After selecting one of the desired Header codes, read the character(s) from the HEX table. Valid characters for all readers are in the range: 00-FE Example:...

  • Page 73: Terminator

    Enter configuration Exit and Save Configuration DATA FORMAT ERMINATOR no terminator one character terminator two character terminator three character terminator four character terminator five character terminator six character terminator seven character terminator eight character terminator After selecting one of the desired Terminator codes, read the character(s) from the HEX table. Valid characters for all readers are in the range: 00-FE Example:...

  • Page 74: Field Adjustment

    Enter configuration Exit and Save Configuration DATA FORMAT IELD DJUSTMENT disable field adjustment Field adjustment allows a number of characters n, to be added to or subtracted from the barcode read. The adjustment can be different for each enabled code type. To define the field adjustment: Read the enable field adjustment code: enable field adjustment...

  • Page 75: Field Adjustment Character

    Enter configuration Exit and Save Configuration DATA FORMAT IELD DJUSTMENT HARACTER Read the field adjustment character code: field adjustment character Read the hexadecimal value corresponding to the character you want to use for field adjustment. 00-FE Valid characters for all readers are in the range: Example: To define the field adjustment character = A : field adjustment character...

  • Page 76: Character Replacement

    Enter configuration Exit and Save Configuration DATA FORMAT HARACTER EPLACEMENT disable character replacement This parameter allows up to three characters to be replaced from the barcode read. These substitutions are stored in memory. To define each character replacement: Read one of the following character replacement codes: first character replacement second character replacement third character replacement...
  • Page 77 DATA FORMAT Example: The following strings define: First Character Replacement: substitution in Code 39 barcodes of all occurrences of the 0 character with the 1 character. Second Character Replacement: substitution in Code 39 barcodes of all occurrences of the A character with the B character. first character ASCII characters corresponding to ASCII characters corresponding to...

  • Page 78: No Read Character

    Enter configuration Exit and Save Configuration DATA FORMAT HARACTER disable enable Read the “ enable ” code above: Read the hexadecimal value corresponding to the character you want to use for no read character. Valid characters for all readers are in the range: 00-FE Example: To define the no read character = A :...

  • Page 79: Power Save

    POWER SAVE LEEP TATE NTER LEEP IMEOUT TANDBY Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE, available at the top of each page.

  • Page 80: Read Rate

    Enter configuration Exit and Save Configuration POWER SAVE 67 reads per sec. 135 reads per sec. 270 reads per sec. A lower read rate reduces power consumption but can lengthen reading response time. LEEP TATE disable enable See par. 5.4.1 for details.

  • Page 81: Enter Sleep Timeout

    Enter configuration Exit and Save Configuration POWER SAVE NTER LEEP IMEOUT enter sleep timeout Read 2 numbers in the range 00-99: 00 = Enter Sleep state immediately 01-99 = corresponds to a max. 9.9 sec. delay before entering the Sleep state. enter sleep timeout = 0.6 sec See par.

  • Page 82: Reading Parameters

    READING PARAMETERS PERATING EEPER NTENSITY EEPER EEPER EEPER ENGTH PDF D ECODING ECOGNITION INTENSITY Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE, available at the top of each page.

  • Page 83: Operating Mode

    Enter configuration Exit and Save Configuration READING PARAMETERS PERATING serial on-line on-line automatic automatic / lighting system standby The following two commands carry out their specific function and then exit the configuration environment. enable test mode disable test mode See par. 5.5.1 for details.

  • Page 84: Beeper Intensity

    Enter configuration Exit and Save Configuration READING PARAMETERS EEPER NTENSITY * very low intensity low intensity medium intensity high intensity * This sets the beeper OFF for data entry, while for all other beeper signals it has the meaning very low intensity. EEPER tone 1 tone 2...

  • Page 85: Beeper Type

    Enter configuration Exit and Save Configuration READING PARAMETERS EEPER monotone bitonal EEPER ENGTH long short PDF D ECODING ECOGNITION NTENSITY high...

  • Page 86: Decoding Parameters

    DECODING PARAMETERS PREAD VERFLOW ONTROL NTERDIGIT ONTROL ECODING AFETY ™ UZZLE OLVER Before changing these parameter values read the descriptions in par. 5.6. CAUTION Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Default value Read the Exit and Save Configuration code ONCE, available at the top of each page.

  • Page 87: Ink-Spread

    Enter configuration Exit and Save Configuration DECODING PARAMETERS PREAD disable enable See par. 5.6.1 for details. VERFLOW ONTROL disable enable See par. 5.6.2 for details.

  • Page 88: Interdigit Control

    Enter configuration Exit and Save Configuration DECODING PARAMETERS NTERDIGIT ONTROL disable enable See par. 5.6.3 for details. ECODING AFETY one read two reads (decoding safety disabled) three reads four reads Required number of good reads before accepting code.

  • Page 89: Puzzle Solver

    Enter configuration Exit and Save Configuration DECODING PARAMETERS ™ UZZLE OLVER disable enable In the case of damaged or poorly printed codes, this parameter allows reading multiple parts of the single code to reconstruct it. To read codes using this technology, simply move the illuminated bar over the code so that each line of the code is scanned.

  • Page 90: Code Selection

    CODE SELECTION EAN/UPC F AMILY FAMILY 39 F AMILY 128 F AMILY ODABAR AMILY ODABLOCK ODABLOCK LESSEY ELEPEN ELTA HARMACODE PDF417 Read the Enter Configuration code ONCE, available at the top of each page. Read configuration codes from the desired groups. = Read the code and follow the procedure given = Default value Read the Exit and Save Configuration code ONCE, available at the top of...
  • Page 91 Enter configuration Exit and Save Configuration CODE SELECTION DISABLE ALL CODE FAMILIES The reader allows up to 5 code selections. This does not limit the number of CODES enabled to 5, as it depends on the code family. NOTE SINGLE •...

  • Page 92: Ean/Upc Family

    Enter configuration Exit and Save Configuration CODE SELECTION EAN/UPC F AMILY disable the family Read the desired family code Note: Since the EAN/UPC without ADD ON code selection is enabled by default, to correctly enable another selection, first disable the family. EAN 8/EAN 13/UPC A/UPC E with and without ADD ON WITHOUT ADD ON EAN 8/EAN 13/UPC A/UPC E...
  • Page 93 Enter configuration Exit and Save Configuration CODE SELECTION WITH ADD ON 2 AND 5 EAN 8/EAN 13/UPC A/UPC E EAN 8/EAN 13 UPC A/UPC E WITH ADD ON 2 ONLY EAN 8/EAN 13 UPC A/UPC E WITH ADD ON 5 ONLY EAN 8/EAN 13 UPC A/UPC E...
  • Page 94 Enter configuration Exit and Save Configuration CODE SELECTION EAN/UPC CHECK DIGIT TX SELECTIONS For each code type in this family you can choose to transmit the check digit or not CHECK DIGIT TRANSMISSION NO CHECK DIGIT TRANSMISSION EAN 8 EAN 8 EAN 13 EAN 13 UPC A...
  • Page 95 Enter configuration Exit and Save Configuration CODE SELECTION CONVERSION OPTIONS UPC E to UPC A conversion UPC E to EAN 13 conversion UPC A to EAN 13 conversion EAN 8 to EAN 13 conversion enable only ISBN conversion enable only ISSN conversion enable both ISBN and ISSN conversion disable both ISBN and ISSN conversion...

  • Page 96: 2/5 Family

    Enter configuration Exit and Save Configuration CODE SELECTION 2/5 F AMILY disable the family Read the desired family code Read a check digit selection Interleaved 2/5 CHECK DIGIT TABLE no check digit control Normal 2/5 (5 Bars) check digit control and transmission Industrial 2/5 (IATA) Check digit control without transmission Matrix 2/5 (3 Bars)

  • Page 97: Code 39 Family

    Enter configuration Exit and Save Configuration CODE SELECTION 39 F AMILY disable the family Read the desired family code Read a check digit selection CHECK DIGIT TABLE Standard Code 39 no check digit control check digit control Full ASCII Code 39 and transmission check digit control without transmission...
  • Page 98 Enter configuration Exit and Save Configuration CODE SELECTION The pharmaceutical codes below are part of the Code 39 family but have no check digit selections. Code CIP39 French pharmaceutical code Code 32 Italian pharmaceutical code CODE LENGTH (optional) The code length selection is valid for the entire Code 39 family set code length Read the code + 4 numbers for the code length where: First 2 digits = minimum code length.

  • Page 99: Code 128 Family

    Enter configuration Exit and Save Configuration CODE SELECTION 128 F AMILY disable the family Read the desired family code Code 128 control without transmission of check digit EAN 128 control without transmission of check digit Add GS Before Code Code EAN 128 uses the ASCII <GS> character to separate a variable length code field from the next code field.
  • Page 100 Enter configuration Exit and Save Configuration CODE SELECTION ISBT 128 Enabling ISBT 128 automatically disables Puzzle Solver. CODE LENGTH (optional) The code length selection is valid for the entire Code 128 family set code length Read the code + 4 numbers for the code length where: First 2 digits = minimum code length.

  • Page 101: Code 93

    Enter configuration Exit and Save Configuration CODE SELECTION disable the code Code 93 control without transmission of check digit disable the code Code 16K To read stacked codes, simply move the illuminated bar over the code so that each line of the code is scanned.

  • Page 102: Codabar Family

    Enter configuration Exit and Save Configuration CODE SELECTION ODABAR AMILY disable the family Read the desired equality control code Read a start/stop transmission selection START/STOP CHARACTER TRANSMISSION Standard Codabar no transmission no start/stop character equality control Standard Codabar start/stop character equality control transmission The Codabar ABC code below uses a fixed start/stop character transmission selection.
  • Page 103 Enter configuration Exit and Save Configuration CODE SELECTION Codabar ABC Forced Concatenation enable Codabar ABC with forced concatenation non start/stop character equality control but transmission CODE LENGTH (optional) The code length selection is valid for the entire Codabar family set code length Read the code + 4 numbers for the code length where: First 2 digits = minimum code length.

  • Page 104: Codablock-A

    Enter configuration Exit and Save Configuration CODE SELECTION ODABLOCK ONLY FOR TC1100-X200 disable the code Codablock-A Notes: • Enabling Codablock-A automatically disables the entire Code 39 family and vice-versa. • Enabling Codablock-A automatically disables Puzzle Solver. To read stacked codes, simply move the illuminated bar over the code so that each line of the code is scanned.

  • Page 105: Msi

    Enter configuration Exit and Save Configuration CODE SELECTION ONLY FOR TC1100-X100 disable the family Enable the code by selecting one of the check digit selections. no check digit control MOD10 check digit control no check digit transmission MOD10 check digit control...

  • Page 106: Plessey

    Enter configuration Exit and Save Configuration CODE SELECTION LESSEY ONLY FOR TC1100-X100 disable the family Enable the code by selecting one of the check digit selections. Standard Plessey no check digit control check digit control check digit transmitted check digit control...

  • Page 107: Telepen

    Enter configuration Exit and Save Configuration CODE SELECTION ELEPEN ONLY FOR TC1100-X100 disable the family Enable the code by selecting one of the check digit selections. Numeric Telepen no check digit control check digit control check digit transmitted check digit control...

  • Page 108: Delta Ibm

    Enter configuration Exit and Save Configuration CODE SELECTION ELTA disable the family Enable the code by selecting one of the check digit selections. no check digit control Type 1 check digit control Type 2 check digit control...

  • Page 109: Code 49

    To read stacked codes, simply move the illuminated bar over the code so that each line of the code is scanned. During this process a series of brief "ticks" indicates that reading is proceeding correctly. HARMACODE ONLY FOR TC1100-X100 disable the code Enable the code by selecting one of the code tx direction. Code Tx Direction...

  • Page 110: Pdf417

    Read the code below: set overflow ratio Then, read 2 numbers in the range 02-10 . PDF417 ONLY FOR TC1100-X200 disable the code PDF417 To read stacked codes, simply move the illuminated bar over the code so that each line of the code is scanned.

  • Page 111: References

    REFERENCES REFERENCES RS232 PARAMETERS 5.1.1 Handshaking Hardware handshaking: (RTS/CTS) The RTS line is activated by the decoder before transmitting a character. Transmission is possible only if the CTS line (controlled by the Host) is active. Signals at EIA levels Transmitted data Transmitted data Host busy Figure 31 - RTS/CTS Handshaking...

  • Page 112: Ack/Nack From Host Protocol

    TC1100 5.1.2 ACK/NACK from Host Protocol This parameter sets a transmission protocol in which the Host responds to the reader after every code transmitted. The Host sends an ACK character (06 HEX) in the case of good reception or the NACK character (15 HEX) requesting re-transmission, in the case of bad reception.

  • Page 113: Pen Parameters

    REFERENCES PEN PARAMETERS 5.2.1 Minimum Output Pulse This parameter sets the duration of the output pulse corresponding to the narrowest element in the barcode. In this way the code resolution is controlled by the signal sent to the decoder, independently of the physical resolution of the code read. The shortest pulse (200 µs) corresponds to a high resolution code emulation and therefore a shorter transfer speed to the decoder (for decoders able to work on high resolution codes).

  • Page 114: Output And Idle Levels

    TC1100 5.2.3 Output and Idle Levels The following state diagrams describe the different output and idle level combinations for Pen Emulation: idle OUTPUT: Normal black space IDLE: Normal white barcode output OUTPUT: Normal black idle IDLE: Inverted space white barcode output...

  • Page 115: Data Format

    REFERENCES DATA FORMAT 5.3.1 Header/Terminator Selection The header/terminator selection is not effected by the reading of the restore default code. In fact, header and terminator default values depend on the interface selection: RS232: no header, terminator CR-LF WEDGE: no header, terminator ENTER These default values are always restored through the reading of RS232 or WEDGE interface selection code, see chapter 3.

  • Page 116: Set Custom Extended Header/Terminator Keys

    TC1100 5.3.2 Set Custom Extended Header/Terminator Keys The extended Header/Terminator keys for Wedge Interface users can be customized by defining them through a simple keyboard setting procedure. For example, the Numeric Keypad keys can be set for use as Headers or Terminators by substituting the default extended keys using this procedure.
  • Page 117 REFERENCES Set Custom Extended Header/Terminator Keys $+FB1$- Enter the code above. • If the first 4 KEYS (Shift, Alt, Ctrl, and Backspace) are not available on your keyboard, you can only substitute them with keys not used, or substitute them with each other. •...

  • Page 118: Power Save

    ON-LINE: the TC1100 reader is connected to an external Presence Sensor using EXT TRIG+ and EXT TRIG- inputs. During the active phase of the presence sensor, the TC1100 tries to acquire and correctly decode the code. If the operation is successful, the barcode characters are transmitted on the serial interface in the format defined by the current configuration.
  • Page 119 In this mode the illuminator is always ON and TC1100 is continuously scanning. The reading phase is enabled when a barcode enters the reading zone of the camera and is terminated after a fixed number of scans without a code.

  • Page 120: Reads Per Cycle

    TC1100 Since Test Mode is basically a diagnostic mode, it can only be enabled at run time and not saved to a non-volatile memory. For the same reason, this operating mode must be disabled only via RS232 interface by selecting another Operating Mode...

  • Page 121: Overflow Control

    The following commands carry out their specific function and then exit the configuration environment. Command Description Restore TC1100 reader default configuration (see par. 3.1 for default settings). Transmit the TC1100 software release (not for PEN Emulation) Transmit TC1100 reader configuration in readable format (not for PEN Emulation)

  • Page 122: Technical Features

    Delta IBM Code 16K Code 49 Pharmacode (TC1100-x100 only) Codablock-A (TC1100-x200 only) Codablock-F Std (TC1100-x200 only) Codablock-F EAN (TC1100-x200 only) PDF417 (TC1100-x200 only) MECHANICAL FEATURES Dimensions (LxWxH) 60.5 x 63 x 27 mm / 2.38 x 2.48 x 1.06 in...

  • Page 123: Reading Diagrams

    -160 Reading Diagram TC1100-0100 (code 39) 90 100 110 120 130 140 150 160 170 180 0.17 mm (6.6 mils) 0.25 mm (10 mils) 0.38 mm (15 mils) Reading Diagram TC1100-0200 (PDF417) Figure 35 - TC1100 Scan Engine Reading Diagrams...
  • Page 124 (20 mils) -160 Reading Diagram TC1100-1100 (code 39) 90 100 110 120 130 140 150 160 170 180 0.17 mm (6.6 mils) 0.25 mm (10 mils) 0.38 mm (15 mils) Reading Diagram TC1100-1200 (PDF417) Figure 36 - TC1100 Scanner Reading Diagrams...

  • Page 125: Acode Identifier Table

    CODE IDENTIFIER TABLE CODE IDENTIFIER TABLE 2/5 Interleaved 2/5 Industrial 2/5 normal 5 bars 2/5 matrix 3 bars EAN 8 EAN 13 UPC A UPC E EAN 8 with 2 ADD ON EAN 8 with 5 ADD ON EAN 13 with 2 ADD ON EAN 13 with 5 ADD ON UPC A with 2 ADD ON...
  • Page 126 TC1100 UPC A with 5 ADD ON UPC E with 2 ADD ON UPC E with 5 ADD ON Code 39 Code 39 Full ASCII CODABAR ABC CODABAR Code 128 EAN 128 Code 93 CIP/39 CIP/HR Code 32 ISBT 128...
  • Page 127 CODE IDENTIFIER TABLE CODABLOCK-A CODABLOCK-F Standard CODABLOCK-F EAN Plessey Anker Plessey Standard Delta IBM Telepen Code 16K PDF417 Code 49 Pharmacode...
  • Page 128 TC1100...

  • Page 129: Hex And Numeric Table

    HEX AND NUMERIC TABLE APPENDIX B HEX AND NUMERIC TABLE OPEN THIS PAGE TO READ THE DESIRED HEX AND NUMERIC SELECTIONS...
  • Page 130 HEX AND NUMERIC TABLE HEX / NUMERIC TABLE CHARACTER TO HEX CONVERSION TABLE char char char < > SPACE " & Backspace Cancels an incomplete configuration sequence...
