OPERATION

Figure 1
Touch Panel and Remote Controls
WARNING: The Revillusion
CAUTION: Except for installation and cleaning described in this manual, an authorized service representative should
perform any other servicing.
The manual controls for the Revillusion
The selected setting displays on the left side of the panel.
A multi-function remote control also is provided. The remote control has a range of approximately 30 ft (9 m). To operate
correctly, the remote control must be pointed toward the front of the built-in electric firebox.
Icon Function
Power/
A
Standby
B
Heat
C
Temp Down
D
Temp Up
Change Fahrenheit (
0
Celsius ( C)
0
Built-in Electric Firebox must be installed properly before it is used.
TM
Built-in Electric Firebox are located on the front panel. Touch an icon to activate.
TM
Description
Press to activate the current standby state (On/Off).
• Standby State On
Press to turn everything Off. Press again to activate the previous state.
• Standby State Off
Press to activate the previous state.
- If the flame effect was On, the previous heat setting will be activated (On or Off).
- If the flame effect was Off, the previous heat setting will be activated (High or Low).
Press again to turn everything Off.
• Heat On
Press to turn heat On (indicated by 1 short beep and the icon appearing on the display).
Displays current heater temperature setting. Use the Temp Up/Down icon to change the
heater temperature setting.
• Heat Off
Press to turn heat Off (indicated by 1 short beep).
!
NOTE: After the heater is switched off, the fan will continue on for 60 seconds before
turning off.
Press multiple times to lower the heater temperature in 1
current temperature; lowest temperature is 41
the heat is enabled.
Press multiple time to raise the heater temperature in 1
current temperature; highest temperature is 99
the heat is enabled.
F) to
Press both Temp+ (
0
) and Temp– ( ) on the unit.
Figure 3
A
H
C
F
E
F (1 C) increments. Displays
0 0
F (5 C). This feature is active whenever
0
F (1 C) increments. Displays
0 0
F (37 C). This feature is active whenever
0 0
B
D
I
G
J
