EMBER LED LIGHT REPLACEMENT

Tools Required: Philips head screwdriver
Needle-nose pliers
WARNING: If the firebox was operating prior to servic-
ing, allow at least 10 minutes for the heating elements to
cool off to avoid accidental burning of skin.
WARNING: Disconnect power before attempting any
maintenance to reduce the risk of electric shock or damage
to persons.
1. Remove the front glass or any accessories that are
around the fireplace and will inhibit your ability to fully
access the unit.
2. Locate and remove the screw behind each of the front
legs of the firebox. (Figure 3)
!
IMPORTANT: Only handle the log-set by the plastic
grate, not the logs themselves.
3. Slide the log set assembly forward and lift the log set
assembly and the ember mat out. (Figure 3)
!
NOTE: The log set assembly has a wire attached to
the unit which can be temporarily disconnected for easier
access.
4. Locate the two ember LED light assemblies and the
connector at the left hand side. (Figure 3)
5. Disconnect the connector.
6. Squeeze the mounting tabs located along the board
with the needle-nose pliers, to release the tabs and lift
off.
7. Replace the LED light assemblies with the new assem-
blies.
8. Re-assemble the unit in reverse order from the instruc-
tions above.

FLAME BASE LED REPLACEMENT

Tools Required: Philips head screwdriver
WARNING: If the firebox was operating prior to servic-
ing, allow at least 10 minutes for the heating elements to
cool off to avoid accidental burning of skin.
WARNING: Disconnect power before attempting any
maintenance to reduce the risk of electric shock or damage
to persons.
1. Remove the front glass or any accessories that are
around the fireplace and will inhibit your ability to fully
access the unit.
2. Locate and remove the screw behind each of the front
legs of the firebox. (Figure 3)
!
IMPORTANT: Only handle the log-set by the plastic
grate, not the logs themselves.
3. Slide the log set assembly forward and lift the log set
assembly and the ember mat out. (Figure 3)
!
NOTE: The log set assembly has a wire attached to
the unit which can be temporarily disconnected for easier
access.
4. On either side of the firebox gently remove the brick
panels by placing you finger in the gap and pulling
forward. The brick panels are held in place by magnets
and need minimal force to be removed.
5. Locate the two brackets securing the flame panel in the
unit at the bottom and remove the 4 screws. (Figure 3)
6. Gently lift the flame panel out, set aside in a safe loca-
tion.
7. Remove the back log assembly by removing the two
screws along the front of the log and the screw on
either end.
8. Lift the back log assembly out of the unit.
9. Locate the flame base LED assembly and remove the
light strip by pressing in the tab in the center of the
stand offs to release the center pin out the back and lift
the light strip off. (Figure 3)
10. DIsconnect the light strip by pulling the connector out of
the assembly on the left hand side.
11. Connect the new light strip.
12. Re-assemble the unit in reverse order from the instruc-
tions above.

BACK LOG LED REPLACEMENT

Tools Required: Philips head screwdriver
Needle-nose pliers
WARNING: If the firebox was operating prior to servic-
ing, allow at least 10 minutes for the heating elements to
cool off to avoid accidental burning of skin.
WARNING: Disconnect power before attempting any
maintenance to reduce the risk of electric shock or damage
to persons.
1. Remove the front glass or any accessories that are
around the fireplace and will inhibit your ability to fully
access the unit.
2. Locate and remove the screw behind each of the front
legs of the firebox. (Figure 3)
!
IMPORTANT: Only handle the log-set by the plastic
grate, not the logs themselves.
3. Slide the log set assembly forward and lift the log set
assembly and the ember mat out. (Figure 3)
!
NOTE: The log set assembly has a wire attached to
the unit which can be temporarily disconnected for easier
access.
4. On either side of the firebox gently remove the brick
panels by placing you finger in the gap and pulling
forward. The brick panels are held in place by magnets
and need minimal force to be removed.
5. Locate the two brackets securing the flame panel in the
unit at the bottom and remove the 4 screws. (Figure 3)
6. Gently lift the flame panel out, set aside in a safe loca-
tion.
7. Remove the back log assembly by removing the two
screws along the front of the log and the screw on
9
