Features

1.1 Features
The C6000™ simulators support the following features:
• TMS320C6000 CPU full instruction set architecture execution
• Support for C62x™, C64x™, C64x+™, C672x™, and C67x™. Support for all devices is based on
these cores.
• Port Connect, which also supports external peripheral simulation
• Pin Connect, which also supports external interrupt simulation
• Analysis events support for debug and analysis
• RTDX™ support
• DSP/BIOS™ real-time analysis support
• CPU resource conflict detection
• Rewind support
• Watchpoint support
• Interrupt latency detection
• Compiled simulation
1.2

Supported Processors and Simulator Configurations

Table 1-1 lists the devices supported by the C6000 Instruction Set Simulator with the corresponding
configuration to be selected under the Factory Board menu of Code Composer Studio Setup.
Processor
TMS320C62x
TMS320C64x
TMS320C67x
TMS320C6211
TMS320C6411
(2)
TMS320C6412
TMS320C6414
TMS320C6415
(2)
TMS320C6416
TMS320C6711
TMS320C6712
(2)
TMS320C6713
(2)
TMS320DM642
TMS320C6201
TMS320C6202
TMS320C6203
(1)
Big Endian and Little Endian (default) configurations are available in the product.
(2)
Device Functional Simulators are also available for these Device Cycle Accurate Simulators and can be used by changing the
Simulator Type entry in the Code Composer Studio Setup processor properties window from Cycle Accurate to Functional.
(3)
Map 0 and Map 1 (default) configurations are available.
10 Introduction to the TMS320C6000 Simulator
Table 1-1. Processors Supported by the C6000 Simulator
Code Composer Studio IDE Import Configuration
C62xx CPU Cycle Accurate Simulator
C64xx CPU Cycle Accurate Simulator
C67xx CPU Cycle Accurate Simulator
C6211 Device Cycle Accurate Simulator
C6411 Device Cycle Accurate Simulator
C6412 Device Cycle Accurate Simulator
C6414 Device Cycle Accurate Simulator
C6415 Device Cycle Accurate Simulator
C6416 Device Cycle Accurate Simulator
C6711 Device Cycle Accurate Simulator
C6712 Device Cycle Accurate Simulator
C6713 Device Cycle Accurate Simulator
DM642 Device Cycle Accurate Simulator
C6201 Device Simulator
C6202 Device Simulator
C6203 Device Simulator
(1)
(3)
(3)
(3)
Submit Documentation Feedback
www.ti.com
CPU Modeled
TMS320C62x
TMS320C64x
TMS320C67x
TMS320C62x
TMS320C64x
TMS320C64x
TMS320C64x
TMS320C64x
TMS320C64x
TMS320C67x
TMS320C67x
TMS320C67x
TMS320C64x
TMS320C62x
TMS320C62x
TMS320C62x
SPRU600I – April 2007
