Board Description
3.11
Debug Interface
3.12
Expansion Slot
3-6
6198C–ATARM–15-Dec-06
! One ¼ VGA display LCD with Touchscreen and white LED backlight
! 20-pin JTAG/ICE interface connector
! DBGU COM Port
! One DataFlash, SD/MMC card slot
! All I/Os of the AT91SAM9261 are routed to peripheral extension footprint connectors
(J16 and J17). This allows the developer to check the integrity of the components and
to extend the features of the board by adding external hardware components or
boards.
AT91SAM9261-EK Evaluation Board User Guide
