Board Description
3.9
Audio Stereo Interface
One AC'97 2.3 compliant Codec (20-bit PCM DAC)
One 32-ohm Stereo Headset line-out
One stereo line input
One stereo electret microphone input
One mono 8-ohm amplified speaker
3.10
User Interface
Two user input pushbuttons
Two user green LEDs
One yellow power LED (can be also software controlled)
One 3.5" ¼ VGA display LCD with Touch Panel and white LED backlight
One ISI connector (camera interface)
3.11
Debug Interface
20-pin JTAG/ICE interface connector
One Serial interface (DBGU COM Port) via RS-232 DB9 male socket
3.12
Expansion Slot
One DataFlash/SD/SDIO/MMC card slot
One SD/SDIO/MMC card slot
All unused I/Os of the AT91SAM9263 are routed to peripheral extension connectors (J24 and J25).
This allows the developer to add external hardware components or boards.
3-6
6325D–ATARM–26-Aug-09
AT91SAM9263-EK Evaluation Board User Guide
