6.1
JTAGSEL S5
Footprint
Selector
AT91SAM9261-EK Evaluation Board User Guide
For JTAG selection, the S5 footprint must never be soldered, else the chip can be
damaged.
By default, the JTAGSEL input pin integrates a pull-down resistor (ICE mode).
To select JTAG mode, the designer should connect the JTAGSEL input pin to VDDBU
power.
Section 6
Errata
6-1
6198C–ATARM–15-Dec-06
