3.10
User Interface
Four user input pushbuttons
Two user green LEDs
One yellow power LED (can be also software controlled)
One ¼ VGA display LCD with Touchscreen and white LED backlight
3.11
Debug Interface
20-pin JTAG/ICE interface connector
DBGU COM Port
3.12
Expansion Slot
One DataFlash, SD/MMC card slot
All I/Os of the AT91SAM9G10 are routed to peripheral extension footprint connectors (J16 and J17).
This allows the developer to check the integrity of the components and to extend the features of the
board by adding external hardware components or boards.
3-6
6479A–ATARM–26-May-09
AT91SAM9G10-EK Evaluation Board User Guide
