Electrical requirements

Parameter
Supply voltage
Frequency
Minimum power supply fuse rating
Number of wall outlets
The system power cord is connected in one of the following ways:
•
•
Note:
The mains power supply cable is shielded ÖLFLEX™ of type:
•
•
If the cable needs to be replaced due to damage, the same type of cable or equivalent
must be used.
All live and neutral wiring must have a cross section area equal to or greater than the
specification in the following table:
ÄKTAprocess Site Preparation Guide 29-1396-55 AA
WARNING
Protective ground. The product must always be connected to a
grounded power outlet.
A fixed power supply by means of a permanent connection with a safety switch (UL
or CE classified systems)
A connector compliant with IEC 60309-2 (CE classified systems only)
GE does not offer a UPS (Uninterrupted Power Supply) as an accessory. How-
ever, the system is prepared for UPS operation.
CE-classified: 150CY Quattro (3 x 2.5 mm
UL-classified: CRF (3 x 14AWG)
2 Site preparation overview
Specification
6 mm, 10 mm 3/8" and 1/2" (Cabinet
•
10): 100, 120, 200 to 208, 230 or 240
V AC
6 mm, 10 mm 3/8" and 1/2" (Cabinet
•
30): 200 to 208, 230 or 240 V AC
50/60 Hz
6 mm, 10 mm 3/8" and 1/2" (Cabinet
•
10):
15/16 A (100, 120 V AC)
-
10 A (200 to 208, 230 or 240 V AC)
-
6 mm, 10 mm 3/8" and 1/2" (Cabinet
•
30): 15/16 A
