2 Site preparation overview
The ÄKTAprocess system is shipped in a crate with the following dimensions.
Contents
ÄKTAprocess 6 mm, 10
mm 3/8" and 1/2" system
(Cabinet 10)
ÄKTAprocess 1" SS and PP
system
(Cabinet 30)
Note:

Environmental requirements

The installation site must comply with the following specifications:
Parameter
Ambient temperature, operation
Relative humidity
Altitude
8
WARNING
Heavy object. Because of the significant weight of the product,
great care must be taken not to cause squeezing or crushing in-
juries during movement. At least two, but preferably three or more,
people are recommended when moving the unit.
NOTICE
Operator console
•
Do not use the operator console to push or drag the system
•
Do not lean on the console
The console arm is only designed to support the weight of the
operator console.
Dimensions (mm)
2070 x 1730 x 1110 mm (W x H x D)
2680 x 1930 x 1310 mm (W x H x D)
If the floor quality does not allow rolling ÄKTAprocess on its own wheels, it
can be moved with a pallet jack or forklift under the bottom of the system skid.
Specification
2°C to 30°C
20% to 95%, non-condensing
Up to 2000 m
