TECO speecon 7200ma Instruction Manual page 68

Parameter
Function
No.
Sn-40
Control Function
Sn-41 Selection At PG
PG Speed
Open Circuit
Control
Operation Selection
Sn-42 At PG Large Speed
Operation Selection
Sn-43 At PG Overspeed
Detection Deviation
Operation Mode
Sn-44 Selection During
Auto_Run
Mode
Auto_Run Mode
Sn-45
Operation Selection1
Auto_Run Mode
Sn-46
Operation Selection2
Auto_Run Mode
Sn-47
Operation Selection3
Auto_Run Mode
Sn-48
Operation Selection4
Auto_Run Mode
Sn-49
Operation Selection5
Auto_Run Mode
Sn-50
Operation Selection6
LCD display
Name
(English)
PG Speed Sn-40= 0
PG Invalid
Operation
Sn-41= 0
1st. Dec. Stop
Sn-42= 0
1st. Dec Stop
Deviation
Sn-43= 0
1st. Dec. Stop
Sn-44= 0
Auto_Run Invalid
Auto_Run
Sn-45= 0
Auto_Run Stop
Sn-46= 0
Auto_Run Stop
Sn-47= 0
Auto_Run Stop
Sn-48= 0
Auto_Run Stop
Sn-49= 0
Auto_Run Stop
Sn-50= 0
Auto_Run Stop
Description
0 : without speed control
1 : with speed control
2 : with speed control but no
integration control during Acc/Dec.
3 : with speed control and integration
control during Acc/Dec.
0 : deceleration to stop (Bn-02)
1 : coast to stop
2 : deceleration to stop (Bn-04)
3 : continue to run
0 : deceleration to stop (Bn-02)
1 : coast to stop
2 : deceleration to stop (Bn-04)
3 : continue to run
0 : deceleration to stop (Bn-02)
1 : coast to stop
2 : deceleration to stop (Bn-04)
3 : continue to run
0 : Auto_Run mode not effective
1 :Auto_Run mode for one single
cycle. (continuing running from
the unfinished step if restarting)
2 :Auto_Run mode be performed
periodically (continuing running
from the unfinished step if restarting)
3 :Auto_Run mode for one single
cycle, then hold the speed of final
step to run. (continuing running from
the unfinished step if restarting)
4 :Auto_Run mode for one single
cycle. (starting a new cycle if
restarting)
5 :Auto_Run mode be performed
periodically (starting a new cycle
if restarting)
6 :Auto_Run mode for one single
cycle, then hold the speed of final
step to run. (starting a new cycle if
restarting)
0 : stop (Bn-02)
1 : forward
2 : reverse
66
Factory
Ref.
Page
Setting
96
0
96
0
96
0
96
0
0 97
0
0
0
97
0
0
0
