TECO speecon 7200ma Instruction Manual page 69

Parameter
Function
No.
Auto_Run Mode
Sn-51
Operation Selection7
Auto_Run Mode
Sn-52
Operation Selection8
Auto_Run Mode
Sn-53
Operation Selection9
Auto_Run Mode
Sn-54
Operation Selection10
Auto_Run Mode
Sn-55
Operation Selection11
Auto_Run
Mode
Auto_Run Mode
Sn-56
Operation Selection12
Auto_Run Mode
Sn-57
Operation Selection13
Auto_Run Mode
Sn-58
Operation Selection14
Auto_Run Mode
Sn-59
Operation Selection15
Auto_Run Mode
Sn-60
Operation Selection16
Sn-61 Applied Torque
Sn-62
Sn-63 Parameter Copy
Sn-64 PID Function
Brake Resistor
Sn-65
Motor Parameters
Sn-66
*2
Sensorless
Vector
Control Mode
Control Sn-67
*1 The default setting will depend upon the different inverter capacity.
*2 Sensorless vector control will be available soon in all UL type 7200MA inverters.
LCD display
Name
(English)
Sn-51= 0
Auto_Run Stop
Sn-52= 0
Auto_Run Stop
Sn-53= 0
Auto_Run Stop
Sn-54= 0
Auto_Run Stop
Sn-55= 0
Auto_Run Stop
Sn-56= 0
Auto_Run Stop
Sn-57= 0
Auto_Run Stop
Sn-58= 0
Auto_Run Stop
Sn-59= 0
Auto_Run Stop
Sn-60= 0
Auto_Run Stop
Sn-61= 0
Mode Const. Tq. Load
Language Sn-62= 0
Selection Language: English
Sn-63=0
Not Load
Sn-64=0
PID Invalid
Sn-65=0
Protection Protect Invalid
Sn-66=0
Autotuning
AUTO TUNE SEL
Selection
Sn-67=0
Selection
CNTRL MODE SEL
Description
0 : stop (Bn-02)
1 : forward
2 : reverse
0 : constant torque
1 : variable(quadratic) torque
0 : English
1 : Traditional Chinese
0 : not loaded (copied)
1 : upload from digital operator to
inverter
2 : download from inverter to digital
operator
3 : inspect the EEPROM of digital
operator
4 : inspect the EEPROM of inverter
0 : PID invalid
1 : PID valid
0 : Braking resistor protection invalid
1 : Braking resistor protection valid
0 : Autotuning invalid
1 : Autotuning valid
0 : V/F control mode (include V/F
control with pulse generator
feedback)
1 : Sensorless Vector Control Mode
67
Factory
Ref.
Page
Setting
0
0
0
0
0
97
0
0
0
0
0
0 98
0 99
0 99
0 99
0 100
0 100
0 100
