Parameter
Function
No.
Scanning Times
Sn-11
at Input Terminal
Operation
Control
Mode Sn-12
Selection
Output Voltage
Sn-13
Limit Selection
Stall Prevention
Sn-14 During Acc.
Function Selection
Stall Prevention
Sn-15 During Dec.
Function Selection
Stall Prevention
Sn-16 During Running
Protection
Function Selection
Charac-
teristic.
selection
Sn-17
Operation Selection
Sn-18
At Power Loss
Sn-19
LCD display
Name
(English)
Sn-11= 0
Scan Time 5 ms
Overtorque
Sn-12= 0
Detection
Overtorque Invalid
Selection
Sn-13= 0
V Limit Invalid
Sn-14= 1
Acc. Stall Valid
Sn-15= 1
Dec. Stall Valid
Sn-16= 1
Run Stall Valid
Fault Retry Sn-17= 0
Setting Retry No O/P
Sn-18= 0
PwrL_to_ON Stop O/P
Zero Speed
Braking Sn-19= 0
Operation Z_braking Invalid
Selection
Description
0 : scan and confirm once per 5 ms
1 : continuously scan and confirm twice
per 10 ms
0 : Overtorque detection function is
not effective.
1 : Overtorque is detected only at
frequency_agree; the motor will
sustain operation even after the
overtorque has been detected
2 : Overtorque is detected only at
frequency_agree; the motor will
stop after the baseblock time when
the overtorque has been detected.
3 : Overtorque is detected during
running (ACC, DEC included).
The motor will sustain operation
even after the overtorque has been
detected.
4 : Overtorque is detected during
running (ACC, DEC included).
The motor will stop after the
baseblock time when the
overtorque has been detected.
0 : V/F output voltage is limited
1 : V/F output voltage is not limited
0 : invalid (Too much a torque may
cause the stall)
1 : valid (stop acceleration if current
exceeds Cn-25 setting)
0 : invalid (installed with external
brake unit)
1 : valid (no external brake unit used)
0 : invalid
1 : valid –Deceleration time1 for stall
prevention during running (no
external brake unit used)
2 : valid –Deceleration time2 for stall
prevention during running (no
external brake unit used)
0 : Do not output fault retry.
(The fault contact does not operate.)
1 : Output fault retry.
(The fault contact operates.)
0 : stop running
1 : continue to run
(analog) Speed reference is 0 during
running on, the braking function
selection
0 : invalid
1 : valid
63
Factory
Ref.
Page
Setting
0 76
0 76
0 76
1 77
1 77
1 77
0 77
0 78
0 78
