TECO speecon 7200ma Instruction Manual page 67

Parameter
Function
No.
Multi-Function
Output Terminal
Sn-30
(RA-RB-RC)
Function Selection
Multi-
Multi-Function
function
Output Terminal
Digital Sn-31
(DO1) Function
Output
Selection
Multi-Function
Output Terminal
Sn-32
(DO2) Function
Multi-Function
Analog Output
Sn-33
(AO1) Function
Multi-
function
Analog
Output
Multi-Function
Selection
Analog Output
Sn-34
(AO2) Function
Pulse Output
Sn-35
Sn-36 Inverter Address
RS-485 Comm.
Sn-37
RS-485
Commu-
RS-485 Comm.
nication
Sn-38 Transmission
Function
Parity Setting
RS-485 Comm.
Sn-39
LCD display
Name
(English)
Sn-30= 13
Fault
Sn-31= 01
Running
Selection
Sn-32= 00
Zero Speed
Selection
Sn-33= 00
Term. AO1 Freq. Cmd.
Selection
Sn-34= 01
Term. AO2 O/P Freq.
Selection
Sn-35= 1
Multiplier
Pulse Mul. 6
Selection
Sn-36= 01
Inverter Address
Sn-37= 1
Baud Rate
Baud rate 2400
Setting
Sn-38= 0
Reversed Bit
Sn-39= 0
Fault Stop
1st. Dec. stop
Selection
Description
Terminal (RA-RB-RC or
00~22 R1A-R1B-R1C) as fault
output (factory setting)
Terminal (DO1-DOG) as
00~22 digital output during running
(factory setting).
Terminal (DO2-DOG or
00~22 R2A-R2C) as digital output
at zero speed (factory setting)
0 : Freq. Cmd. (10.V/MAX frequency
command, Cn-02)
1 : Output frequency (10.V/MAX.
output frequency)
2 : Output current (10.V/input rated
current)
3 : Output voltage (10.V/input
voltage, Cn-01)
4 : DC voltage
(10.V/400.V or 10.V/800.V)
5 : External analog input command
VIN (0.~10.V/0.~10.V)
6 : External analog input command
AIN (0.~10.V/4.~20.mA)
7 : Multi-function analog input
(AUX) (10.V/10.V)
8 : PID control input
9 : PID control output1
10:PID control output2
11:Communication Control
When multi-function output terminal
(DO1,DO2) is set as pulse signal
output
0:1F 1:6F 2:10F 3:12F 4:36F
Inverter address can be set as 1~31
0 : 1200 bps
1 : 2400 bps
2 : 4800 bps
3 : 9600 bps
0 : no parity
1 : even parity
2 : odd parity
0 : deceleration to stop (Bn-02)
1 : coast to stop
2 : deceleration to stop (Bn-04)
3 : continue to run
65
Factory
Ref.
Page
Setting
13
00 90
01
00
94
01
1 94
01
1
95
0
0
