2. SPECIFICATIONS

2.0 GENERAL

Type:
Frequency:
Tuning Forks
System Accuracy:
Operating Voltage:
Low Voltage
Threshold
Section 2--Specifications
One-piece, Moving/Stationary True
Doppler radar system
Ka-Band 33.4-36.0 GHz +100 MHz
Forks stamped "KSI Ka-Band" are
for units with microwave frequency
35.5 GHz. Forks for any other Ka-
Band frequency will have that
frequency clearly labeled on the fork.
Stationary +1 mph (+2km/h)
Moving +1/-2 mph (+2/-3 km/h)
Corded: 10.8 to 16.5 VDC, 800 mA
max
There are conditions when the Talon
will operate normally and not display
a low voltage alert when the external
battery voltage drops substantially
below the specified 10.8 VDC.
Cordless: 6.5 to 9.0 VDC
Corded: Approximately 10.8 VDC
Cordless: Approximately 6.5 VDC
2.1
7.2 VDC nominal NiMH
