Section 3—Inspection and Installation

3.3 RADAR INSTALLATION

1. The Talon is shipped with the handle (corded or
cordless) attached. For dash mounting, remove the
handle by pressing the blue release button (latch) on the
bottom of the indicator and sliding the handle
backwards.
2. Locate the dash bracket and mounting pod. Fasten the
mounting pod to the dash bracket, then slide the Talon
onto the pod by placing it in front of the pod and sliding
backwards. The mounting pod may be turned 90° on the
mount and the Talon slid onto it from the side. Position
the radar and mount in a suitable location on the dash
within view of the driver and in a safety zone during
airbag deployment. Normally this will be to the left or
right of the steering wheel as space permits.
3. Connect the Talon's power cable to the proper power
source. See Section 3.2.1.
4. Momentarily press the PWR switch on the rear panel of
the Talon. (Refer to Section 4.1 for location and
function of the switches.) The Talon will proceed
through an indicator test, internal test and several other
reliability tests. Select the Stationary mode of operation
by pressing the MODE switch, if required. (If
"PATROL" is displayed, press the MODE switch.)
Only "TARGET" will be displayed in the stationary
mode.
5. Momentarily press the AUD (audio) switch. The
TARGET window will display "Aud" and a number
from 0 to 5 indicating the audio level. With "Aud"
displayed, press the RNG (range) switch until level 4 or
5 is displayed. Also, with "Aud" displayed, press the
MODE switch, which will unsquelch the audio.
