Kustom Signals Talon Radar Operator's Manual page 10

Speed Range:
Stationary:
Moving:
Patrol:
Target
Opposite Dir.:
Same Direction:
Indicators:
Stationary:
Moving:
Section 2—Specifications
Meets IACP/NHTSA specifications.
Stationary: Target channel sensitivity
of 10 dB from 35 to 90 mph (56 to
144 km/h); 5 dB from 60 to 90 mph
(96 to 144 km/h).
Moving (Opposite direction): within
10 dB for targets between 40 to 90
mph (64 to 144 km/h). Maximum
closing rate 210 mph (336 km/h).
Moving (Same direction): 10 dB for
target difference speeds of 5 to 25
mph (8 to 40 km/h).
10 to 210 mph (16 to 255 km/h).
10 to 80 mph (16 to 128 km/h)
Typical patrol speeds to 120 mph
(193 km/h).
Maximum target speed is a function
of combined patrol and target speeds
to 210 mph (336 km/h).
Minimum difference: 3 mph (5 km/h)
Maximum difference: 0.65 x Patrol
Speed
"TARGET" window displayed.
"PATROL" and "TARGET" both
displayed in window.
2.4
