Kustom Signals Eagle 3 Quick Reference Manual

4
Eagle 3 Fork Test
The Advanced Fork Test guides the operator through a
simple yet thorough tuning fork test. The operator may use
the eFork in the remote control or traditional tuning forks.
The Front antenna sequence tests Moving Opposite while the
Rear antenna sequence tests for Moving Same Direction.
When prompted, "Flo" is for the low fork speed and "FHi"
is for the high fork speed. The calculated results will be
displayed with a clear pass or fail message. Front & Rear
antenna remote buttons will send high and low fork signals
manually.
Eagle 3 Quick Reference Guide
KSI Part # 006-1003-10 Rev 2
Eagle 3 Quick Reference Guide
1 Eagle 3 Front Panel Controls
S1 - Press to enter Menu screens and displays.
In Menus, pressing increments Menu screens.
S2 - Initiates the display, internal and tuning fork
tests. Press to bypass Automatic Fork Test. In
Menus, pressing will save selection and return to
Main Enforcement screen.
S3 - Programmable soft key short cut to favorite
menu or GPS marker. Un-pair remote in remote
menu. Patrol Speed Blanking with a locked
target.
S4 - Control for power on / off. Power off to save
current menu selections.
