Alarms
Icon Name
Water temperature
deviation
No water
No water flow
Check water flow on
any port
Power loss
Check patient probe
(A or B)
Probe or adapter
malfunction (A or B)
Adapter cable
disconnected (A or B)
Patient temperature
deviation
Normothermia
deviation
Therapy pause
Battery low
Patient temperature
output (A or B)
Remove from use
(RFU)
8001-069-002 Rev B.2
If any of the alarm conditions persist, call maintenance.
If the page indicators appear on the alarm screen, there are multiple active alarms. Only the highest alarm is displayed.
Alarm
Message
priority
Medium Water temperature is ±0.8°C (1.4°F)
outside of target temperature
Medium No water
Medium No flow detected
Medium Reduced flow detected
Medium Not applicable
Medium Abnormal change in patient
temperature
Medium No temperature signal detected
Medium Adapter cable not detected
Medium Patient temperature is ±0.5°C (0.9°
F) outside of target temperature
Low Patient temperature is outside of
36.0°C (96.8°F) to 38.0°C (100.4°F)
Medium Therapy is currently paused
Low Battery is low
Low Patient temperature output is
inaccurate on the external device,
or outside supported range
Medium The system has powered off due to
a malfunction
Refer to the Altrix Precision Temperature Management System Operations Manual for additional information.
Therapy
Check
interrupted
No Temporary condition upon startup, addition f thermal transfer device, or
addition of water
Yes Check for leaks
Add a minimum of 2 liters of sterile distilled water
Yes Check for leaks and obstructions at connections, hoses, and thermal
transfer devices
No Tap Confirm, if the water port was removed intentionally Check for leaks
and obstructions at connections, hoses, and thermal transfer devices
Yes Check power cord connection
Yes Check probe condition, location, and connections
Yes Check probe or adapter cable condition, location, and connections
Yes Reinsert the adapter cable. If damaged, replace the adapter cable
No Check patient condition, placement of thermal transfer devices, and all
connections
No Check patient condition, placement of thermal transfer devices, and all
connections
Yes To resume, press and hold the play/pause for 2 seconds
No Maintenance is recommended. If battery is not replaced, the product may
not function on the next startup.
No Check output adapter cable connection. Tap Confirm to reactivate the
output port.
Yes Remove the product from use immediately. Notify the appropriate
personnel.
