Draining the internal water circuit and hoses for disinfection (cont.)
4. Connect a hose to each port (Figure 25).
5. Close the connector ends of all three hoses:
a. If you have Colder style connector hoses, attach the service tool
adapter hose (8001-999-017) (Figure 26). Complete this for all three
hoses.
b. If you have Clik-Tite hoses, make sure that the connector ends are
connected and closed (A), and clamps are open (B). Complete this for all
three hoses (Figure 27).
Figure 25
Figure 26

Disinfecting the internal water circuit and hoses

1. Use personal protection equipment as recommended by the BruClean TbC
disinfectant manufacturer's instructions for use.
2. Put 2 BruClean TbC tablets into the reservoir.
3. Using appropriate measuring equipment, fill the empty reservoir with 1
gallon (3.8 L) of sterile-distilled water.
Note: Always allow the disinfectant tablets to completely dissolve
before starting the 20 minute disinfection cycle.
4. Place the reservoir into the controller.
5. Disconnect the bottom hose from the bottom right port (Figure 29).
6. Connect the bottom hose end to the hydraulic connector in the lid of the
reservoir (Figure 30).
7. Plug the power cord into a wall outlet.
8001-069-002 Rev B.2 Refer to the Altrix Precision Temperature Management System Operations Manual for additional information.
6. To fully drain the hoses, raise all the hoses (Figure 28) above the
connection ports on the controller.
Note: For best performance, hang the hoses to keep them raised. Do not
lower the hoses until you have completed the disinfection and rinsing
process.
7. Allow the controller and hoses to drain for a minimum of two minutes.
8. Push down on the drain plug to close the drain.
Figure 27
Figure 29
Figure 28
Figure 30
