Quick start guide for
Altrix Precision Temperature Management System
Product functions
(continued)
8001-069-002 Rev B.2
Icon
Refer to the Altrix Precision Temperature Management System Operations Manual for additional information.
Function
Water temperature on target,
solid green when active, does not
breathe
Patient temperature on target
Patient probe A port, stabilized
Patient probe B port, stabilized
External device, patient probe A
External device, patient probe B
Stand-by
Icon Function
Water flow detected, ports 1, 2, or 3
are active, solid green when active,
does not breathe
Cooling therapy
Warming therapy
Current therapy duration
Total duration
Visual and audible tests
Target patient or water
temperature
card 7A
